dahua TNO-C4080T 為TNO-C4080T，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 TNO-C4080T 香港價格連安裝報價。
| Imaging Device | Type Uncooled micro bolometer (640x480) |
|---|---|
| 解像度 | 1280x960, 640x480, 640x360, 320x240 |
| Max. Framerate | H.265/H.264 30fps/25fps(60Hz/50Hz) |
| MJPEG | 30fps |
| Spectral Range | 8~14㎛ |
| NETD | ≤16mK@25°C, F1.0 |
| Pixel Size | 17㎛ |
| Video Out | USB: USB Type C. Preview and installation ONLY. Requires WiFi dongle. |
| Focal Length (mm) | 60 |
| Max Aperture Ratio (F | Wide 1.15 number) |
| Angular Field of View | Horizontal 10.3° |
| Vertical | 7.7° |
| Diagonal | 12.8° |
| iFoV | 0.28 mRad |
| Min. Object Distance | 92m(301.8ft) |
| Focus Control | Fixed |
| 鏡頭類型 | Athermalized Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range Pan | 0°~350° |
| Tilt | 0°~90° |
| Rotate | 0°~350° Operational |
| Digital Noise Reduction | WiseNR |
| Motion Detection | Quantity 8ea |
| Shape | 8point Polygonal zones |
| TNO-C4080T | ' Operational |
| Privacy Masking | Quantity 32ea |
| Color / Option | Gray, Green, Red, Blue, Black, White, Mosaic, Purple, Yellow |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) |
| Serial Interface | RS-485 |
| Alarm Interface | In/Out 2 configurable I/O ports |
| Others | Support extra alarm I/O via optional I/O box |
| Alarm Triggers | Analytics, Network disconnect, Alarm input, Time schedule, MQTT subscription, Case tampering |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP/SFTP, File upload(video clip): FTP/SFTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers,Alarm output, Handover: PTZ preset,send message by HTTP/HTTPS/TCP,Audio clip playback, MQTT: publication |
| 音訊輸入 | Selectable(mic in/line in) |
| Audio Out | Line out |
| Color Pallettes | Whitehot, Blackhot, Rainbow, Rainbow2, Sepia, Red, Iron, Custom Analytics |
| Classified Object Type | Person, Vehicle, Vessel |
| Thumbnail | BestShot |
| Analytics Events | Based on AI Engine Object detection, Virtual line(Crossing/Direction), Motion detection, Virtual area(Loitering/Intrusion/Enter/Exit/Appear/Disappear), Sound classification |
| Normal | Tampering, Audio detection, Shock detection, Temperature change detection |
| Ethernet | Metal shielded RJ-45(10/100/1000BASE-T) |
| 視頻壓縮 | H.265/H.264: Main/Baseline/High, MJPEG |
| 音訊壓縮 | G.711(PCM): 8kHz(64kbps), G.726(ADPCM): 8kHz(16/24/32/40kbps), AAC-LC: 16kHz(48kbps), OPUS: 16kHz(64kbps) |
| Smart Codec | WiseStream(Based on AI engine) |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR |
| Streaming | Unicast Up to 20 users |
| Multicast | Support |
| Multiple Streaming | Up to 5 profiles |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SFTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT, Syslog |
| Application | ONVIF S, G, T, M Programming Interface |
| Direct Cloud Connection | Support Security |
| OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
| User authentication | Digest authentication, Prevent brute-force attack |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP |
| Access Control | IP-based access control, MAC-based access control, Auto logout |
| Data Protect | Encryption credentials, Encrypt compress for live recording file export |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate(Hanwha Vision Root CA) |
| Secure Storage | SDcard partition encrypt(AES-256), Secure element |
| Supply Chain Security | SBOM |
| Security Certificate | Secure element(FIPS 140-3 level3, CC EAL6+), Consumer IoT Security Standard (ETSI EN 303 645) |
| SoC | Type Wisenet 8 |
| Memory | RAM 4GB |
| Flash | 4GB eMMC |
| Edge Storage | Micro SD/SDHC/SDXC Max. 1TB x 1slot |
| Edge Storage(OnCloud) | Micro SD/SDHC/SDXC Max. 1TB x 1slot *Hanwha Vision branded microSD cards have been certified and recommended for OnCloud edge recording. Environmental & Electrical |
| 工作環境 | Temperature -40°C~+60°C(-40°F~+140°F) |
| Humidity | 0~95% RH(non-condensing) |
| Storage Condition | Temperature -50°C~+60°C(-58°F~+140°F) |
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC |
| 功耗 | PoE Max. 7.8W, typical 7.4W 12VDC Max. 8.1W, typical 7.8W |
| 顏色 | White |
| 材質 | Aluminum, PC(Polycarbonate) |
| RAL Code | RAL9003 |
| Product Dimensions | ø107.3 x 275mm( 4.22/10.83") |
| Product Weight | 2100g(4.6 lb) |
| Compatible Conduit Hole | Support conduit compatibility via optional adaptor |
| Compatible Gang Box | Single, Double, 4" Octagon, Square Certifications & Standards |
| EMC | FCC 47 CFR 15 Subpart B Class A,CE/UKCA - EN55032 Class A,EN 50130-4,EN 61000-3- 2,EN 61000-3-3,VCCI CISPR 32 Class A,RCM AS-NZS CISPR 32 Class A,KS C 9832 Class A,KS C 9835,IC Regulation ICES-003 Issue 7 Class A,FCC - IC Regulation ICES 003 Issue 7, RCM - EN IEC 63000:2018 Class A, VCCI - EN IEC 63000:2018 Class A |
| Safety | UL 62368-1, CAN/CSA C22.2 NO. 62368-1 |
| Environment | IEC/EN 63000, IEC 60529 IP66, IEC 60529 IP67, IEC 62262 IK10, NEMA TS 2-2013 (2.2.7, 2.2.8, 2.2.9), NEMA 250 type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, MIL-STD-810H 501.7, MIL-STD-810H 502.7, MIL-STD-810H 505.7, MIL-STD-810H 506.6, MIL-STD-810H 507.6, MIL-STD-810H 509.7, MIL-STD-810H 510.7, MIL-STD-810H 514.8, MIL-STD-810H 516.8, MIL-STD-8 |
| Person(1.8m/5.9ft) | Wide 352m(1,154ft) |
| Vehicle(2.4m/7.9ft) | Wide 469m(1,539ft) |
| Vessel(2.4m/7.9ft from | Wide 1,486m(4,874ft) Waterline) DRI (Johnson's Criteria) |
| Detection | Person(1.67PPM) 2,130m(6,989ft) |
| Vehicle(0.65PPM) | 5,444m(17,861ft) |
| Recognition | Person(6.67PPM) 533m(1,747ft) |
| Vehicle(2.61PPM) | 1,361m(4,465ft) |
| Identification | Person(13.33PPM) 266m(874ft) |
| Vehicle(5.22PPM) | 681m(2,233ft) |
| CAD | Unit: mm [inch] |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →TNO-C4080T dahua TNO-C4080T亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，TNO-C4080T 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：鏡頭類型方面，TNO-C4080T 係 Athermalized Pan / Tilt / Rotate，IPC-HDBW3541R-ZAS 係 Motorized vari-focal；音訊輸入方面，TNO-C4080T 係 Selectable(mic in/line in)，IPC-HDBW3541R-ZAS 係 1-channel (RCA port)；Smart Codec方面，TNO-C4080T 係 WiseStream(Based on AI engine)，IPC-HDBW3541R-ZAS 係 Smart H.265+/ Smart H.264+。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HDBW3541R-ZAS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 TNO-C4080T 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
HKEZIT 於全港各區提供 TNO-C4080T dahua TNO-C4080T供貨連專業安裝服務（裝CAM、裝CCTV、裝監控），熱門地區包括：大圍CCTV 閉路電視安裝、大埔CCTV 閉路電視安裝、大角咀CCTV 閉路電視安裝、將軍澳CCTV 閉路電視安裝、尖沙咀CCTV 閉路電視安裝、屯門CCTV 閉路電視安裝、旺角CCTV 閉路電視安裝、柴灣CCTV 閉路電視安裝。港島、九龍、新界全港 32 區均有上門安裝，歡迎聯絡我們查詢 TNO-C4080T 香港價格連安裝報價。
