HANWHA SCB-3003-ENG-2P CCTV攝影機安裝・保養

Name: HANWHA SCB-3003-ENG-2P 960H Analog Box Camera
Brand: hanwha
SKU: SCB-3003-ENG-2P

產品簡介

hanwha SCB-3003-ENG-2P 為960H Analog Box Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SCB-3003-ENG-2P 香港價格連安裝報價。

SCB-3003N：SCB-3003P
Imaging Device：1/3" Super HAD CCD II (Double scan)
Total Pixels：1,028(H) x 508(V) 1,028(H) x 596(V)
Effective Pixels：976(H) x 494(V) 976(H) x 582(V)
Scanning System：2 : 1 Interlace

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

SCB-3003-ENG-2P hanwha 960H Analog Box Camera 產品圖片

詳細規格

SCB-3003N	SCB-3003P
Imaging Device	1/3" Super HAD CCD II (Double scan)
Total Pixels	1,028(H) x 508(V) 1,028(H) x 596(V)
Effective Pixels	976(H) x 494(V) 976(H) x 582(V)
Scanning System	2 : 1 Interlace
Synchronization	Internal / Line lock / Extern
Frequency	H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Horizontal Resolution	Color : 700TV lines (ER mode), B/W : 700TV lines Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x) Min. Illumination B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x)
S / N Ratio	52dB (AGC off, Weight on)
Video Output	CVBS : 1.0 Vp-p / 75Ω composite
尺寸	Unit : mm (inch) Focus Control Simple focus / Manual, Botton control (Manual, Simple focus, Day & Night)
鏡頭類型	Manual / Auto iris (Video / DC)
Mount Type	C / CS Operational English, French, German, Spanish, Italian, Chinese, English, Japanese, Spanish,
On Screen Display	Russian, Polish, Czech, Romanian, Serbian, Swedish, French, Portuguese, Korean Danish, Turkish, Portuguese
Camera Title	Off / On (Displayed 15 characters) 67.2 (2.65") (2.65")
日夜切換	Auto (ICR) / External / Color / B/W
Backlight Compensation	Off / User BLC / HLC / WDR 67.2
寬動態 WDR	128x (52dB) 160x (54dB) 73.1 (2.88") 73.1 (2.88") 123.9 123.9(4.88") (4.88") Contrast Enhancement SSDR (Off / On)
Digital Noise Reduction	SSNRIII (Off / On)
Digital Image Stabilization	Off / On
Accessories (Optional)	Motion Detection Privacy Masking Built-in Off / On (12 programmable zones with polygonal masking)
Sens-up (Frame Integration)	2x ~ 512x
Gain Control	Off / Low / High
White Balance	ATW / Outdoor / Indoor / Manual / AWC (1,700°K ~ 11,000°K)
Electronic Shutter Speed	1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
SLA-3580DN	SLA-2812DN SLA-550DV SLA-612DN Digital Zoom Off / On (1x ~ 16x)
Reverse	Off / H-Rev / V-Rev / HV-Rev
Profile	Basic / Day & Night / Backlight / ITS / Indoor / User
Intelligent Video Analytics	Fixed / Moved, Fence, Tracking, Counting
VPS	Off / On
SLA-12240	SLA-880 STB-4150V
PIP	Off / On
警報	1 Out
Communication	Coaxial control (SPC-300 compatible), RS-485 Coax : Pelco-C (Coaxitron) RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon,GE, AD SHB-4300H1
SHB-4200/4200H	Environmental /4300H2/4300H3
Operating Temperature / Humidity	-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH Electrical
Input Voltage / Current	Dual (24V AC & 12V DC ±10%)
use with	or Power Consumption Max. 4W
STB-400	STH-500 STH-200
Color / Material	Black, Silver / Aluminum, Plastic
Dimensions (WxHxD)	73.1 x 67.2 x 123.9mm (2.88" x 2.65" x 4.88")
重量	285g (0.63 lb) The Eco mark represents Samsung Techwin’s will to create environment-friendly products,and indicates that the product satisfies the EU RoHS Directive. Design and specifications are subject to change without notice. DISTRIBUTED BY SAMSUNG TECHWIN CO., LTD. 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA Tel : +82-70-7147-8741~8749, 8752~876
