dahua PNB-A9001LP 為PNB-A9001LP，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 PNB-A9001LP 香港價格連安裝報價。
| Imaging Device | Size 1/1.8" |
|---|---|
| 類型 | CMOS |
| 解像度 | 3840x2160, 3072x1728, 2688x1520, 2592x1944, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
| Max. Framerate | H.265/H.264 30fps/25fps(60Hz/50Hz) |
| MJPEG | 30fps |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) 0.03 |
| BW(1/30sec, 30IRE) | 0.003 |
| Video Out | CVBS: 1.0 Vp-p / 75 composite for installation, USB: Micro USB Type B |
| Focus Control | Simple focus |
| 鏡頭類型 | DC auto iris, P iris(IR corrected), Manual, I-CS |
| Mount Type | C mount, CS mount Operational |
| 日夜切換 | Auto(ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Digital Noise Reduction | SSNRⅤ |
| Digital Image Stabilization | Support(built-in gyro sensor) |
| Motion Detection | Quantity 8ea |
| Privacy Masking | Quantity 6ea |
| Shape | Rectangular zones |
| Color / Option | Gray, Black, White |
| Gain Control | Low, Middle, High |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor |
| LDC | Support |
| Electronic Shutter | Mode Minimum, Maximum, Anti flicker |
| Speed Range | 1/5~1/12,000sec |
| PNB-A9001LP | ' Operational |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm Interface | In/Out Input 1ea, Output 1ea |
| Others | 12VDC output |
| Alarm Triggers | Analytics, Network disconnect, Alarm input |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers,Alarm output, Handover: PTZ preset,send message by HTTP/HTTPS/TCP,Audio clip playback |
| 音訊輸入 | Selectable(mic in/line in), Built-in mic |
| Audio Out | Line out Analytics |
| Analytics Events | Normal Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection |
| Ethernet | Metal shielded RJ-45(10/100/1000BASE-T) |
| 視頻壓縮 | H.265/H.264: Main/High, MJPEG |
| 音訊壓縮 | G.711 u-law /G.726 selectable,G.726(ADPCM) 8kHz,G.711 8kHz, G.726: 16kbps,24kbps,32kbps,40kbps, AAC-LC: 48kbps at 16kHz |
| Smart Codec | Manual, WiseStreamⅡ |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR |
| Streaming | Unicast Up to 6 users |
| Multicast | Support |
| Multiple Streaming | Up to 3 profiles |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast) |
| Application | ONVIF S, G, T Programming Interface |
| OS / Firmware Protect | Secure boot |
| User authentication | Digest authentication |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP) |
| Secure Communication | HTTPS |
| Access Control | IP-based access control |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate(Hanwha Vision Root CA) |
| Secure Storage | SDcard partition encrypt(AES-256) |
| Memory | RAM 4GB |
| Flash | 512MB |
| Edge Storage | Micro SD/SDHC/SDXC 1slot (32GB card preinstalled) Environmental & Electrical |
| 工作環境 | Temperature -10°C~+55°C(+14°F~+131°F) |
| Humidity | 0~90% RH(non-condensing) |
| Storage Condition | Temperature -50°C~+60°C(-58°F~+140°F) |
| Input Voltage | PoE+(IEEE802.3at, Class4), 12VDC |
| 功耗 | PoE PoE+: Max 16.50W, typical 12.50W 12VDC 12VDC: Max 13.50W, typical 10.80W |
| 顏色 | Black |
| 材質 | Aluminum |
| Product Dimensions | 81x67x165mm(3.19x2.64x6.48") |
| Product Weight | 0.88kg(1.94lb) Wisenet Road AI LPR/ANPR/MMCR |
| App Type | CNN (Convolutional Neural Network) AI |
| LPR Usage Condition | NA City Traffic |
| EU | City Traffic |
| Speed Description by | NA Regular Speed Region |
| Lane Coverage_NA | 1 Lane 3.6m/12ft wide (with built in IR) 2 Lanes 8.1m/26ft wide (with built in IR) |
| Lane Coverage_EU | 1 Lane 3.6m/12ft wide (with built in IR) 2 Lanes 8.1m/26ft wide (with built in IR) 3 Lanes 16.2m/53ft wide (with built in IR) |
| Plate Capture | 1 Lane 4K Resolution_NA 2 Lanes 4K |
| Speed Limit_NA | 1 Lane Up to 140km/h (87mph) 2 Lanes Up to 120km/h (74mph) |
| Speed Limit_EU | 1 Lane Up to 140km/h (87mph) 2 Lanes Up to 140km/h (87mph) 3 Lanes Up to 70km/h (43mph) |
| Min. Forward | 1 Lane 6m (19.7ft) Distance_NA 2 Lanes 15m (49.2ft) |
| Max. Forward | 1 Lane 30m (98.4ft) Distance_NA 2 Lanes 30m (98.4ft) |
| Max. Horizontal Angle by NA | 30° for highway, 45° for traffic observation Region |
| Max. Vertical Angle by | NA 30° Region |
| Vehicle Recognition | Make: 100+ makes Model: 4700+ models Color: 11 colors |
| Available Countries | Albania, Armenia, Austria, Belarus, Belgium, Bosnia and Herzegovina, Bulgaria, Cyprus, Czechia, Denmark, Estonia, Finland, France, Greece, Germany, Hungary, Ireland, Iceland, Italy, Lithuania, Luxembourg, Latvia, Montenegro, North Macedonia, Malta, Netherlands, Norway, Poland, Portugal, Romania, Serbia, Slovenia, Slovakia, Spain, Switzerland, Turkey, United Kingdom, United States of America, Canad |
| Integration Options | JSON over HTTP, UTMC 1, UTMC 2, NVR, Wisenet WAVE |
| VMS Support | Wisenet WAVE, Wisenet SSM, Genetec Security Center, Milestone Xprotect, Genetec AutoVu |
| CAD | Unit: mm [inch] |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →PNB-A9001LP dahua PNB-A9001LP亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，PNB-A9001LP 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：Mount Type方面，PNB-A9001LP 係 C mount, CS mount Operational，IPC-HDBW3541R-ZAS 係 φ14；音訊輸入方面，PNB-A9001LP 係 Selectable(mic in/line in), Built-in mic，IPC-HDBW3541R-ZAS 係 1-channel (RCA port)；Smart Codec方面，PNB-A9001LP 係 Manual, WiseStreamⅡ，IPC-HDBW3541R-ZAS 係 Smart H.265+/ Smart H.264+。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HDBW3541R-ZAS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
