dahua QNV-C8012 為QNV-C8012，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 QNV-C8012 香港價格連安裝報價。
| Imaging Device | Size 1/2.8" |
|---|---|
| 類型 | CMOS |
| 解像度 | 2592x1944, 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate | H.265/H.264 30fps/25fps(60Hz/50Hz) |
| MJPEG | 30fps(@5MP Max. 5fps) |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) 0.05 |
| BW(1/30sec, 30IRE) | 0.005 |
| Video Out | USB: Micro USB Type B. Preview and installation ONLY. Requires WiFi dongle. |
| Focal Length (mm) | 2.4 |
| Max Aperture Ratio (F | Wide 2.0 number) |
| Angular Field of View | Horizontal 123° |
| Vertical | 91° |
| Diagonal | 159° |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Fixed |
| 鏡頭類型 | Fixed iris |
| Mount Type | M12 Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range Pan | 0°~350° |
| Tilt | -35°~70° |
| Rotate | 0°~355° Operational |
| 日夜切換 | Auto(ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range (dB) | 120 |
| QNV-C8012 | ' Operational |
| Digital Noise Reduction | WiseNRⅡ(Based on AI engine), SSNRⅤ |
| Motion Detection | Quantity 8ea |
| Shape | 8point Polygonal zones |
| Privacy Masking | Quantity 32ea |
| Color / Option | Gray, Green, Red, Blue, Black, White |
| Gain Control | Low, Middle, High |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor |
| LDC | Support |
| Electronic Shutter | Mode Minimum, Maximum, Anti flicker |
| Speed Range | 1/5~1/12,000sec |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) |
| Alarm Triggers | Analytics, Network disconnect, MQTT subscription |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Handover: PTZ preset,send message by HTTP/HTTPS/TCP, MQTT: publication Analytics |
| Classified Object Type | Person, Vehicle |
| Attributes | Vehicle Type(car, bus, truck, motorcycle, bicycle) |
| Thumbnail | DetectionShot |
| Analytics Events | Based on AI Engine Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit), Motion detection |
| Normal | Defocus detection, Tampering, Virtual area(Appear/Disappear) |
| Business Intelligence | Based on AI Engine People counting, Queue management, Heatmap, Vehicle counting |
| Ethernet | RJ-45(10/100BASE-T) |
| 視頻壓縮 | H.265/H.264: Main/High, MJPEG |
| Smart Codec | Manual, WiseStreamⅢ |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR |
| Streaming | Unicast Up to 20 users |
| Multicast | Support |
| Multiple Streaming | Up to 5 profiles |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT |
| Application | ONVIF S, G, T, M Programming Interface |
| Others | SUNAPI(HTTP API), Hanwha Vision Open Platform |
| Direct Cloud Connection | Support Security |
| OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
| User authentication | Digest authentication, Prevent brute-force attack |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication | HTTPS, WSS(WebSocket Secure) |
| Access Control | IP-based access control |
| Data Protect | Encryption credentials, Encrypt compress for live recording file export |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate(Hanwha Vision Root CA) |
| Secure Storage | SDcard partition encrypt(AES-256) |
| Memory | RAM 2GB |
| Flash | 1GB |
| Edge Storage | Micro SD/SDHC/SDXC Max. 256GB x 1slot |
| Edge Storage(OnCloud) | Micro SD/SDHC/SDXC Max. 1TB x 1slot *Hanwha Vision branded microSD cards have been certified and recommended for OnCloud edge recording. Environmental & Electrical |
| 工作環境 | Temperature -40°C~+55°C(-40°F~+131°F) |
| Humidity | 0~100% RH(condensing) |
| Storage Condition | Temperature -50°C~+60°C(-58°F~+140°F) |
| Input Voltage | PoE(IEEE802.3af, Class3) |
| 功耗 | PoE Max. 7W, typical 4.9W |
| 顏色 | White |
| 材質 | Aluminum |
| RAL Code | RAL9003 |
| Product Dimensions | ø110x77mm( 4.33x3.03") |
| Product Weight | 522g(1.15lb) |
| Compatible Gang Box | Single, Double, 4" Octagon |
| EMC | FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, RCM AS-NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835 |
| Safety | UL 62368-1, CAN/CSA C22.2 NO. 62368-1, IEC 62471 |
| Environment | IEC/EN 63000, IEC 60529 IP66, IEC 62262 IK10 DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) | Wide 28.1m(92.35ft) |
| Observe (63PPM/ 19PPF) | Wide 11.3m(36.94ft) |
| Recognize (125PPM/ | Wide 5.6m(18.47ft) 38PPF) |
| Identify (250PPM/ | Wide 2.8m(9.23ft) 76PPF) |
| CAD | Unit: mm [inch] |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →QNV-C8012 dahua QNV-C8012亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，QNV-C8012 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：鏡頭類型方面，QNV-C8012 係 Fixed iris，IPC-HDBW3541R-ZAS 係 Motorized vari-focal；Mount Type方面，QNV-C8012 係 M12 Pan / Tilt / Rotate，IPC-HDBW3541R-ZAS 係 φ14；Smart Codec方面，QNV-C8012 係 Manual, WiseStreamⅢ，IPC-HDBW3541R-ZAS 係 Smart H.265+/ Smart H.264+。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HDBW3541R-ZAS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
