dahua TNP-A9430RWB 為TNP-A9430RWB，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 TNP-A9430RWB 香港價格連安裝報價。
| Imaging Device | Size 1/1.8" |
|---|---|
| 類型 | CMOS |
| 解像度 | 3840x2160, 3328x1872, 2592x1944, 2592x1464, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate | H.265/H.264 30fps/25fps(60Hz/50Hz) |
| MJPEG | 30fps(@8MP Max. 5fps) |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) 0.06 Lux(F1.69, 1/30sec, 30 IRE) |
| BW(1/30sec, 30IRE) | 0.006 Lux(F1.69, IR LED Off), 0Lux (IR LED On) |
| Focal Length (mm) | 6.1~262.4 |
| Zoom Ratio | Optical 43 |
| Digital | 1367 |
| Max Aperture Ratio (F | Wide F1.69 number) |
| Tele | F4.92 |
| Angular Field of View | Horizontal 63.62 (Wide)~1.77 (Tele) |
| ˚ | ˚ |
| Vertical | 37.69 (Wide)~0.99 (Tele) |
| Diagonal | 70.9 (Wide)~2.05 (Tele) |
| Min. Object Distance | 5m(16.4ft) |
| Focus Control | Auto, Manual, Oneshot AF, Focus save |
| 鏡頭類型 | P iris(IR corrected) Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range Pan | 360° Endless |
| Tilt | Upright: 140°(50°~-90°), Canted: 165°(75°~-90°), Inverted: 140°(90°~-50°) |
| 水平速度 | Preset Max. 160°/sec |
| Manual | 0.024°/sec~160°/sec |
| TNP-A9430RWB | ' Pan / Tilt / Rotate |
| 垂直速度 | Preset Max. 160°/sec |
| Sequence | Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule |
| Preset Accuracy | ±0.07° Operational |
| Direction Indicator | Support |
| 日夜切換 | Auto(ICR) |
| Backlight Compensation | BLC, HLC, WDR, SSDR |
| Wide Dynamic Range (dB) | 120 |
| Digital Noise Reduction | WiseNRⅡ(Based on AI engine), SSNRⅤ |
| Digital Image Stabilization | Support(built-in gyro sensor) |
| Optical Image Stabilization | Support |
| 除霧 | Support |
| Motion Detection | Quantity 8ea |
| Shape | 8point Polygonal zones |
| Privacy Masking | Quantity 32ea |
| Color / Option | Gray, Green, Red, Blue, Black, White, Mosaic |
| Dynamic Privacy Masking: | Gray, Green, Red, Blue, Black, White, Mosaic, Purple, Yellow Color / Option |
| Gain Control | Off, Max gain, Manual |
| White Balance | ATW, NarrowATW, AWC, Manual, Indoor, Outdoor, Mercury, Sodium |
| Electronic Shutter | Mode Minimum, Maximum, Anti flicker, Prefer shutter control(Based on AI engine) |
| Speed Range | 2~1/30,000sec |
| Video Rotation | Flip&Mirror |
| Installation Direction | Upright, Inverted, Canted |
| Alarm Interface | Others Support alarm I/O via optional I/O box |
| Alarm Triggers | Analytics, Network disconnect, Alarm input, Time schedule, MQTT subscription |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP, File upload(video clip): FTP/SFTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers,Alarm output, Handover: PTZ preset,send message by HTTP/HTTPS/TCP,Audio clip playback, MQTT: publication |
| 音訊輸入 | Support via optional I/O box |
| Audio Out | Support via optional I/O box |
| Light Type | IR LED |
| Light Viewable Length | IR 500m(1,640.42ft) |
| 紅外波長 | 850nm |
| Water Removal | Support(with Wiper) |
| Ice Removal | Window, Pan |
| Auto Tracking | Support, Object auto tracking(Person/Vehicle), Target lock tracking Analytics |
| Classified Object Type | Person, Face, Vehicle, License plate |
| Attributes | Person Upper/Lower clothes color, Gender, Bag |
| Vehicle | Type(car, bus, truck, motorcycle, bicycle), Color |
| Face | Age, Gender, Face mask, Glasses |
| Thumbnail | BestShot |
| Analytics Events | Based on AI Engine Object detection, Virtual line(Crossing/Direction), Motion detection, Slip & fall detection, Virtual area(Loitering/Intrusion/Enter/Exit/Appear/Disappear), Auto tracking |
| Normal | Tampering, Audio detection, Shock detection |
| Ethernet | RJ-45 Push-pull Connector(10/100BASE-T) |
| 視頻壓縮 | H.265/H.264: Main/Baseline/High, MJPEG |
| Smart Codec | WiseStream(Based on AI engine) |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR |
| Streaming | Unicast Up to 20 users |
| Multicast | Support |
| Multiple Streaming | Up to 10 profiles |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SFTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT, NTCIP 1205, Syslog |
| Application | ONVIF S, G, T, M Programming Interface |
| Others | SUNAPI(HTTP API), Hanwha Vision Open Platform |
| Direct Cloud Connection | Support Security |
| OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
| User authentication | Digest authentication, Prevent brute-force attack |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP |
| Access Control | IP-based access control, MAC-based access control, Auto logout |
| Data Protect | Encryption credentials, Encrypt compress for live recording file export |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate(Hanwha Vision Root CA) |
| Secure Storage | SDcard partition encrypt(AES-256), Secure element |
| Supply Chain Security | SBOM |
| Security Certificate | Secure element(FIPS 140-3 level3, CC EAL6+), Consumer IoT Security Standard (ETSI EN 303 645) |
| SoC | Type Wisenet 9 |
| Dual NPU | Support |
| Memory | RAM 4GB |
| Flash | 8GB eMMC |
| Edge Storage | Micro SD/SDHC/SDXC Max. 1TB x 1slot |
| Edge Storage(OnCloud) | Micro SD/SDHC/SDXC Max. 1TB x 1slot *Hanwha Vision branded microSD cards have been certified and recommended for OnCloud edge recording. Environmental & Electrical |
| 工作環境 | Temperature -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~100% RH(condensing) |
| Storage Condition | Temperature -50°C~+60°C(-58°F~+140°F) |
| Wind Load | Sustained 257km/h (160mph) |
| EPA(Effective Projected Area) | 0.095㎡ |
| Input Voltage | PoE++(IEEE802.3bt type4, Class8) |
| 功耗 | PoE Max 71W, Typical 33.2W |
| WisePower | Power mode, Power monitoring, Eco mode |
| 顏色 | Black |
| 材質 | Aluminum, PC(Polycarbonate), ITO Glass |
| Material Management | Declaration RoHS(EU RoHS directive 2011/65/EU and IEC/EN 63000:2018), REACH(Regulation (EC) No. 1907/2006), Conflict mineral policy(Section 1502 of US Dodd Frank Act) |
| RAL Code | RAL9005 |
| Product Dimensions | Upright Normal/Inverted : 293.4(W)x205.6(D)x399.9(H)mm (11.55x8.09x15.74") Upright Canted : 293.4(W)x301.9(D)x363.6.9(H)mm (11.55x11.89x14.31") |
| Product Weight | 10.5kg(9.5kg: Excluding installation part) Certifications & Standards |
| EMC | EN 50121-4, FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA - EN55032 Class A, EN 50130-4, VCCI CISPR 32 Class A, RCM AS-NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835, EN 55035 |
| Safety | UL 62368-1, CAN/CSA C22.2 NO. 62368-1, IEC 62471, IEC/EN/UL 62368-1 GS UL cUL CE FCC VCCI CB |
| Environment | IEC 60529 IP66, IEC 60529 IP68, IEC 62262 IK10, NEMA TS 2-2013 (2.2.7, 2.2.8, 2.2.9), NEMA 250 type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, MIL-STD-810H 501.7, MIL-STD-810H 502.7, MIL-STD- 810H 503.7, MIL-STD-810H 505.7, MIL-STD-810H 506.6, MIL-STD-810H 507.6, MIL- STD-810H 509.7, MIL-STD-810H 510.7, MIL-STD-810H 521.4, IEC 60068-2-52:2017, |
| Detect (25PPM/ 8PPF) | Wide 123.8m(406.23ft) |
| Observe (63PPM/ 19PPF) Wide | 49.5m(162.49ft) |
| Recognize (125PPM/ | Wide 24.8m(81.25ft) 38PPF) |
| Identify (250PPM/ | Wide 12.4m(40.62ft) 76PPF) |
| CAD | Unit: mm [inch] |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →TNP-A9430RWB dahua TNP-A9430RWB亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，TNP-A9430RWB 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：鏡頭類型方面，TNP-A9430RWB 係 P iris(IR corrected) Pan / Tilt / Rotate，IPC-HDBW3541R-ZAS 係 Motorized vari-focal；音訊輸入方面，TNP-A9430RWB 係 Support via optional I/O box，IPC-HDBW3541R-ZAS 係 1-channel (RCA port)；Smart Codec方面，TNP-A9430RWB 係 WiseStream(Based on AI engine)，IPC-HDBW3541R-ZAS 係 Smart H.265+/ Smart H.264+。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HDBW3541R-ZAS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 TNP-A9430RWB 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
