dahua DH-PFM900-E 為DH-PFM900-E，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DH-PFM900-E 香港價格連安裝報價。
| 操作系統 | Linux Multi-language interface: English, Chinese, Spanish, French, German, Turkish, Russian, Czech, Serbian, Portuguese, |
|---|---|
| 語言 | Polish, Romanian, Hebrew, Japanese, and Persian |
| Operation Mode | Button and keyboard |
| Auto Standby/Shutdown | Yes |
| Keyboard Sound | Enable/Disable |
| Screen | 4.0" TFT screen, 800 × 480 resolution Controlling keyboard: 13 keys of the main keyboard, and 45 keys of the flip keyboard |
| Keyboard | Others: Power button, reset button |
| LED Indicator Light | 2 * 35lm lights |
| Update | Online and local update IPC Test |
| Camera Access | ONVIF |
| 解像度 | 1MP, 1.3MP, 2MP, 3MP, 4MP, 5MP, 6MP, 8MP, and 12MP |
| Camera Initialization | Yes |
| Video Display | Live view, snapshots, records, digital zoom, and H.264/H.265 decoding |
| Function Control | Support IPC modifications such as resolution, IP, and account password, and restoring IPC to factory settings Analog Video Test |
| Format | HDCVI, HDTVI, AHD, and CVBS (NTSC, PAL) HDCVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps, 6MP@20 fps, 4K@12.5 fps/15 fps HDTVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps |
| Video Signal Generator | Generate HDCVI, HDTVI, and AHD video test signals with 720/1080P RS–485 Control |
| Communication Protocol | More than 30 protocols such as Pelco-D/P, Samsung, Panasonic, Lilin, and Yaan |
| Baud Rate | 150 bps, 300 bps, 600 bps, 1200 bps, 2400 bps, 4800 bps, 9600 bps, and 19200 bps Protection Air discharge: ±8KV ESD Contact discharge: ±6KV Others |
| Audio Test | 1 channel audio input test and 1 channel audio output test |
| Camera Power Supply | 12V/2A DC power output to the camera |
| Network Test | IP address scanning, and Ping test |
| Voltage Test | Display voltage, data transmission, and signal strength of PoE/PSE device |
| Data Monitor | Receive and display protocol data with a RS–485 cable Test the length and attenuation of a network cable Network Cable Test Test range: 1–130 m (3.28–426.51 ft) (The maximum length varies depending on the material of the cable) |
| Digital Multimeter | Tests of AC/DC voltage, AC/DC current, resistance, capacitance, diode, and circuit conductivity Certifications CE: EN 55032 Certifications FCC: FCC Part 15 Subpart B www.dahuasecurity.com Port 1 standard PoE charging, IEEE802.3af Power 1 power output , 12V/2A DC 1 audio input 1 audio output |
| USB | 1 USB Mini-B |
| Ethernet | 2 RJ45 10M/100M/1G |
| RS–485 | 1 |
| Digital Multimeter Port | 3 Power |
| Charging | PoE 48V-0.32A |
| 電池 | Dedicate battery, replaceable, 7.4V polymer lithium ion batteries, up to 22.2Wh, working for about 8 hours |
| 工作溫度 | –10°C to +55°C (+14°F to +131°F) |
| 工作濕度 | 30%–95% (RH) Structure |
| Appearance Color | Yellow |
| 尺寸 | 193.0 × 115.0 × 37.1 mm (7.8" × 4.53"× 1.48") |
| 淨重 | 0.54 kg (1.19 lb) |
| 毛重 | 1.40 kg (3.09 lb) Ordering Information |
| 類型 | Part Number Description |
| DH-PFM900-E | Dahua integrated mount tester Tool Series |
| PFM900-E | General integrated mount tester Package Information |
| Integrated Mount Tester | 1 |
| Lanyard of the Tester | 1 |
| Tool Bag | 1 |
| Lanyard of the Tool Bag | 1 |
| User Manual | 1 |
| Network Cable | 1 |
| Coaxial Cable | 1 |
| USB Cable | 1 |
| RS–485 Cable | 1 |
| RS–485 Terminal | 1 |
| Power Output Cord | 1 |
| Audio Cable | 1 |
| Multimeter Probes | 1 |
| PoE Power Injector | 1 |
| Charging Cord | 1 www.dahuasecurity.com Dimensions (mm/inch) Application |
| Rev 001.001 | © 2019 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →
193.0 × 115.0 × 37.1 mm (7.8" × 4.53"× 1.48")｜Unit: mm
