| 影像感測器 | 1/3” Progressive Scan CMOS Color: 0.012 Lux @ (F2.0, AGC ON) |
|---|
| 最低照度 | B/W: 0.00062 Lux @ (F2.0, AGC ON) |
|---|
| 快門速度 | 1 to 1/100,000 second |
|---|
| 鏡頭 | 2.8 mm/4 mm (optional) In integrated mode, red, green, yellow, blue, cyan, and magenta colors can be indicated. |
|---|
| LED 指示燈 | In separation mode, up to 3 external indicators which can indicate red, green, yellow, blue, cyan, and magenta colors can be connected. Supports indicator flashing. |
|---|
| 角度調節 | Pan: -30° to 30° Tilt: 0° to 30° For 2.8 mm lens: horizontal: 98°, vertical: 53.1°, diagonal: 114.7° For 4 mm lens: horizontal: 75.3°, vertical: 41.4°, diagonal: 88.2° |
|---|
| 視頻壓縮 | H.265/H.264/MJPEG |
|---|
| Output Bit Rate | 32 Kbps to 16 Mbps |
|---|
| Image Format | JPEG |
|---|
| 最大解像度 | 2560 × 1440 |
|---|
| DS-TCP440-B: | DS-TCP440-DB: 30 fps (N)/25 fps (P) 15 fps (N)/15 fps (P) |
|---|
| 主碼流 | 2560 x 1440 (default), 1920 x 1080, 1600 x 1200, 2560 x 1440 (default), 1920 x 1080, 1600 x 1200, 1280 x 720, 720 x 576 1280 x 720, 720 x 576 DS-TCP440-B: DS-TCP440-DB: |
|---|
| 子碼流 | 2560 x 1440, 1920 x 1080, 1280 x 720, 720 x 576 720 x 576, 352 x 288 (default) (default), 352 x 288 |
|---|
| 圖像設定 | Brightness, contrast, saturation, white balance, and gain can be adjusted via client or IE browser. |
|---|
| Backlight | Supported. Areas can be selected. NAS (iSCSI optional) |
|---|
| Storage | Local storage: guidance terminal HDD |
|---|
| Protocol | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS (SIP, SRTP, and IPv6 optional) |
|---|
| 一般功能 | Flashing filter, dual-stream, heartbeat, mirror, password protection, privacy mask, watermark, NTP time synchronization |
|---|
| Smart Function | Built-in AI deep-learning algorithm, supporting ANPR and parking space detection. 2 × RJ45 10 M/100 M self-adaptive Ethernet interface |
|---|
| Communication | 1 × power interface |
|---|
| 接口 | 3 × external indicator interface |
|---|
| iBeacon | Standard iBeacon protocol (for -B model) |
|---|
| 工作溫度 | -20 °C to 50 °C (-4 °F to 122 °F) |
|---|
| 工作濕度 | < 95% (no condensation) |
|---|
| Protection Level | IP54 |
|---|
| 供電 | Hikvision PoE, or 12 to 24 VDC wide-range voltage |
|---|
| 功耗 | Single lens: max. 6.5 W Dual lens: max. 10 W |
|---|
| 重量 | 500 g (1.1 lb) |
|---|
