TP-LINK ER605(UN)1.0 網絡設備安裝・保養

Name: TP-LINK ER605(UN)1.0 MODEL: ER605 (TL-R605)
Brand: tp-link
SKU: ER605(UN)1.0

產品簡介

tp-link ER605(UN)1.0 為MODEL: ER605 (TL-R605)，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 ER605(UN)1.0 香港價格連安裝報價。

Product Description：Omada Gigabit VPN Router IEEE 802.3, IEEE802.3u, IEEE802.3ab
Standards and Protocols：TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec
接口：3 Gigabit LAN/WAN ports 1 Gigabit LAN port 10BASE-T: UTP cat
Network Media：100BASE-TX: UTP cat egory 5, 5e cable (Max 100 m) EIA/TIA-56
按鈕：Reset Button

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝WIFI、裝ROUTER、裝FIREWALL工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

ER605(UN)1.0 tp-link MODEL: ER605 (TL-R605) 產品圖片

詳細規格

Product Description	Omada Gigabit VPN Router IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3x, IEEE 802.1q
Standards and Protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP 1 Gigabit WAN port
接口	3 Gigabit LAN/WAN ports 1 Gigabit LAN port 10BASE-T: UTP cat egory 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
Network Media	100BASE-TX: UTP cat egory 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 1000BASE-T: UTP cat egory 5, 5e, 6 cable (Max 100 m)
按鈕	Reset Button
供電	External 9 V/0.85 A DC Adapter
Flash	16 MB SPI
DRAM	128 MB
LED	PWR, SYS, WAN (Link/Act), LAN (Link/Act)
Dimensions ( W x D x H )	6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) Automatic Device Discovery
Hardware Controller (OC200/OC300)	Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration
Software Controller	Reboot Schedule Captive Portal Configuration
Concurrent Session	25,000
New Sessions /Second	2,400 Upload: 936.7 Mbps Static IP NAT Throughput Download: 940.1 Mbps Upload: 941.1 Mbps DHCP NAT Throughput Download: 940.5 Mbps Upload: 940.1Mbps PPPoE NAT Throughput Download: 939.6 Mbps
Performance	Upload: 781.2 Mbps L2TP NAT Throughput Download: 708.4 Mbps Upload: 826.4 Mbps PPTP NAT Throughput Download: 607.1 Mbps Upload: 1,308,139 pps 66 Byte Packet forwarding rate Download: 1,308,140 pps Upload: 81,067 pps 1,518 Byte Packet forwarding rate Download: 81,063 pps
IPSec VPN Throughput (AES256)	41.5 Mbps Unencrypted: 748.7 Mbps L2TP VPN Throughput Encrypted: 15.0 Mbps Performance Unencrypted: 719.0 Mbps PPTP VPN Throughput Encrypted: 72.0 Mbps Static IP Dynamic IP
WAN Connection Type	PPPoE PPTP L2TP DHCP Server DHCP Address Reservation DHCP
Basic Functions	Multi-IP Interfaces1 Multi-Net DHCP1
MAC Clone	Modify WAN/LAN MAC Address2
IPTV	IGMP v2/v3 Proxy
IPv6	Developing3
VLAN	802.1Q VLAN Intelligent Load Balance Application Optimized Routing Load Balance Link Backup (Timing4, Failover) Online Detection One-to-One NAT5 Multi-Net NAT Virtual Server
NAT	Port Triggering5 Transmission NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG, UPnP Static Routing Routing Policy Routing
Session Limit	IP-based Session Limit
Bandwidth Control	IP-based Bandwidth Control 20 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IPSec VPN	IKE v1/v26 MD5, SHA1 Authentication Algorithm
VPN	NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) PPTP VPN Server PPTP VPN Client (10)7 PPTP VPN 16 Tunnels PPTP with MPPE Encryption L2TP VPN Server L2TP VPN Client (10)1 L2TP VPN 16 Tunnels
OpenVPN2	OpenVPN Client (10)1 16 OpenVPN Tunnels TCP/UDP/ICMP Flood Defense
Attack Defense	Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN Web Group Filtering3
Filtering	URL Filtering
安全	Web Security3 Sending GARP Packets
ARP Inspection4	ARP Scanning IP-MAC Binding
Access Control	Source/Destination IP Based Access Control No Authentication Simple Password5 Hotspot (Local User / Voucher5 / SMS5 / Radius5)
Authentication	Web Authentication External Radius Sever External Portal Sever5 Facebook5
Service	Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) Web Management Interface Remote Management
Management	Export & Import Configuration
Maintenance	SNMP v1/v2c/v36 Diagnostics (Ping & Traceroute)7 NTP Synchronize7 Syslog Support
Certification	CE, FCC, RoHS ER605 (TL-R605), Power Adapter, RJ-45 Ethernet Cable, Quick Package Contents Installation Guide Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10
Others	System Requirements MAC OS, NetWare, UNIX or Linux Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing Portal Sever, and Facebook.
