tp-link T2600G-28MPS(UN)1.0 為T2600G-28MPS Datasheet，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 T2600G-28MPS(UN)1.0 香港價格連安裝報價。
| 交換容量 | 56Gbps |
|---|---|
| Forwarding Rate | 41.7Mpps |
| MAC 位址表 | 16K |
| Packet Buffer Memory | 1.5Mb |
| Jumbo Frame | 9216Bytes |
| Power Budget | 384W |
| 供電 | 100-240V, 50/60Hz |
| Maximum Power Consumption | Maximum (PoE on): 468.7W (110V/50Hz) |
| Dimension (W * D * H) | 17.3*13*1.7 in.(440*330*44 mm) |
| 重量 | 6.0kg |
| FAN Quantity | 2 |
| Operation Temperature | 0℃~40℃ (32 ℉ ~104 ℉ ) |
| 儲存溫度 | -40℃ ~70℃ (-40 ℉ ~158 ℉ ) |
| Operation Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing CE, FCC |
| Link Aggregation | Loopback Detection |
| - Static Link Aggregation | Flow Control |
| - 802.3ad LACP | - 802.3x Flow Control - Up to 8 aggregation groups, containing 8 ports - HOL Blocking Prevention |
| per group | Port Mirroring |
| L2 Features | Spanning Tree Protocol - One-to-One |
| - 802.1D STP | - Many-to-One |
| - 802.1w RSTP | - Flow-Based |
| - 802.1s MSTP | - Tx/Rx/Both - STP Security: Loop back detection, TC Protect, L2PT BPDU Filter/Protect, Root Protect |
| Support 1000(IPv4/IPv6)IGMP groups | MLD Snooping |
| IGMP Snooping | - MLD v1/v2 Snooping |
| - IGMP v1/v2/v3 Snooping | - MLD Snooping Querier |
| - IGMP Fast Leave | - Fast Leave |
| - Multicast VLAN | - - IGMP Authentication |
| - IGMP Snooping Querier | - Static Multicast - Static Multicast |
| 16 IP Interfaces | Proxy ARP |
| L3 Features | - supports IPv4 interface Static Routing |
| - supports IPv6 interface | 48 static routes |
| 802.3af/at | PoE Schedule(Time-based Settings) |
| PoE | Up to 30W per port 384W Power Budget 24 PoE+ Ports |
| VLAN Group | Private VLAN |
| - 4K VLAN Groups | GVRP |
| 802.1Q Tagged VLAN | VLAN VPN (QinQ) |
| MAC VLAN | - Port-Based QinQ |
| - 256 Groups | - Selective QinQ |
| Protocol VLAN | VLAN VPN (QinQ) - 16 Groups - 16 Protocols |
| 802.1p/DSCP priority | |
| 8 Priority Queues | - Mirror(to supported interface) |
| Queue Scheduling | - Redirect(to supported interface) |
| - SP(Strict Priority) | - Rate Limit |
| - WRR(Weighted Round Robin) | - QoS Remark - SP+WRR Bandwidth Control - Port/Flow based Rating Limiting Supports up to 300 entries(up to 600 by Access Standard IP ACL |
| Template) | - Source IP |
| Time-Based ACL | - Destination IP |
| MAC ACL | Extended IP ACL |
| - Source MAC | - Source IP |
| - Destination MAC | - Destination IP |
| - VLAN ID | - Fragment |
| - User Priority | - IP Protocol |
| ACL | - EtherType - TCP Flag |
| Combined ACL | - TCP/UDP Port |
| IP-MAC-Port Binding | AAA (including TACACS+) |
| DoS Defend | Port Isolation |
| Dynamic ARP Inspection | Secure web management through HTTPS with |
| IP Source Guard | SSLv3/TLS1.0 |
| Static/Dynamic Port Security | Secure Command Line Interface(CLI) |
| - Up to 64 MAC addresses per port | management with SSHv1/SSHv2 |
| 安全 | Broadcast/Multicast/Unicast Storm Control IP/Port/MAC based access control - kbps/ratio/pps control mode 802.1X - Port based authentication - MAC(Host) based authentication - Guest VLAN - Support Radius authentication and accountability |
| OAM | 802.3ah Ethernet Link OAM Device Link Detect Protocol(DLDP) |
| Web-based GUI | DHCP Option82 Command Line Interface(CLI) through console port, DHCP Relay |
| telnet | 802.1ab LLDP/LLDP-MED |
| sFlow | CPU Monitoring |
| SNMPv1/v2c/v3 | Cable Diagnostics |
| Management | SNMP Trap/Inform Access Control |
| RMON (1,2,3,9 groups) | Password Recovery |
| SDM Template | SNTP |
| PPPoE Circuit ID | System Log DHCP/BOOTP Client DHCP Snooping |
| IPv6 Dual IPv4/IPv6 | TCPv6/UDPv6 Multicast Listener Discovery(MLD) Snooping IPv6 applications |
| IPv6 ACL | - DHCPv6 Client |
| IPv6 Interface | - Ping6 |
| Static IPv6 Routing | - Tracert6 |
| IPv6 Support | DHCPv6 Relay - Telnet(v6) |
| DHCPv6 Snooping | - IPv6 SNMP |
| IPv6 neighbor discovery (ND) | - IPv6 SSH Path maximum transmission unit (MTU) discovery - IPv6 SSL Internet Control Message Protocol (ICMP)version 6 - Http/Https - IPv6 TFTP |
| MIB II (RFC1213) | RMON2 MIB (RFC2021) |
| Interface MIB (RFC2233) | Radius Accounting Client MIB (RFC2620) |
| Ethernet Interface MIB (RFC1643) | Radius Authentication Client MIB (RFC2618) |
| Bridge MIB (RFC1493) | Remote Ping, Traceroute MIB (RFC2925) |
| P/Q-Bridge MIB (RFC2674) | Support TP-LINK private MIBs RMON MIB (RFC2819) |
| Product Model | Description |
| T2600G-28MPS | JetStream 24-Port Gigabit L2 managed POE+ Switch with 4 SFP Slots |
| TL-SM311LS | Gigabit SFP module, Single-mode, LC interface, Up to 10km distance |
| TL-SM311LM | Gigabit SFP module, Multi-mode, LC interface, Up to 550m distance |
| TL-SM321A | Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1550nm/RX:1310nm, 10km |
| TL-SM321B | Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1310nm/RX:1550nm, 10km |
| MC210CS | Gigabit single-mode SC SFP Transceiver, up to 15Km, chassis mountable |
| MC200CM | Gigabit multi-mode SC SFP Transceiver, up to 550m, chassis mountable |
| MC220L | Gigabit SFP slot supporting mini-GBIC modules, chassis mountable |
| MC1400 | 14-slot power supply chassis for TP-LINK Media Converter, 19-inch rack-mountable www.tp-link.com Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright @ 2016 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →
詳見圖示｜Unit: mm
T2600G-28MPS(UN)1.0 tp-link T2600G-28MPS Datasheet亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，T2600G-28MPS(UN)1.0 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 官方 App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：Maximum Power Consumption方面，T2600G-28MPS(UN)1.0 係 Maximum (PoE on): 468.7W (110V/50Hz)，TAPO-D230S1 係 Doorbell Max Power Consumption: 2.39 W；儲存溫度方面，T2600G-28MPS(UN)1.0 係 -40℃ ~70℃ (-40 ℉ ~158 ℉ )，TAPO-D230S1 係 -40℃ ~60℃。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 TAPO-D230S1 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
