TP-LINK TX-W6961N CCTV攝影機安裝・保養

Name: TP-LINK TX-W6961N GPON Router
Brand: tp-link
SKU: TX-W6961N

產品簡介

tp-link TX-W6961N 為GPON Router，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 TX-W6961N 香港價格連安裝報價。

接口：4 10/100Mbps RJ45 LAN Ports 1 Power On/Off Button
按鈕：1 WPS Button 1 Wi-Fi On/Off Button 1 RESET Button
External Power Supply：9VDC/0.85A
IEEE Standards：IEEE 802.3, 802.3u ITU G.984.1
GPON Standards：ITU G.984.2 ITU G.984.3 ITU G.984.4

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

接口	4 10/100Mbps RJ45 LAN Ports 1 Power On/Off Button
按鈕	1 WPS Button 1 Wi-Fi On/Off Button 1 RESET Button
External Power Supply	9VDC/0.85A
IEEE Standards	IEEE 802.3, 802.3u ITU G.984.1
GPON Standards	ITU G.984.2 ITU G.984.3 ITU G.984.4
Optical Module	Class C+ Transmit at 1310nm Optical Wavelength Receive at 1490nm
Transmission Distance	0 ~ 20Km Max Downstream 2.488Gbps Max Bandwidth Upstream 1.244Gbps Max
Dimensions (Wx Dx H)	10.1× 7.0× 2.0 in. (256× 177× 51 mm)
Antenna Type	Omni directional
天線增益	2×5dBi
TX Powe	0.5~5dbm
RX Power	-8~-30dBm WIRELESS FEATURES
Wireless Standards	IEEE 802.11n, 802.11g, 802.11b
Wireless Speeds	Up to 300Mbps (dynamic)
Frequency	2.400-2.4835GHz
Transmit Power	<20dBm(EIRP)
Wireless Functions	Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption, Wireless Wireless Security MAC Filtering SOFTWARE FEATURES PPPoE, Dynamic IP, Static IP, Bridge WAN Connection Type Support Multiple WAN connection Server, Client, DHCP Client List, DHCP Address Reservation, DHCP relay
Quality of Service	Bandwidth Control
Port Forwarding	Virtual server, Port Triggering, DMZ, ALG, UPnP
VPN Pass-Through	PPTP, L2TP, IPSec Pass-through
Dynamic DNS	DynDns, NO-IP Copyright © 2011 TP-LINK Technologies Co., Ltd. All rights reserved. www.tp-link.com
N300 Wireless GPON Router	TX-W6961N Specifications： NAT Firewall, SPI Firewall MAC / URL Filtering Security Firewall for Denial of Service(DoS), SYN Flooding, Ping of Death IP and MAC Address Binding OMCI Web Based Configuration
Management	Command Line Interface, SSL for TR-069 SNMP v1/2c OMCI Based Firmware Upgrade Web Based Firmware Upgrade
IPv6	IPv6 and IPv4 dual stack SN, Password, SN + Password Authentication Mode Upstream and Downstream FEC, AES encryption Advanced Features Dynamic Bandwidth Allocation(DBA) support NSR/SR 802.1Q VLAN, Static Routing; IGMP v1/v2 /v3 16 T-CONTs, 256 GEM Ports OTHERS
Certification	CE, FCC, RoHS TX-W6961N RJ-45 Ethernet Cable
Package Contents	Quick Installation Guide Power Adapter Microsoft® Windows® 98SE, NT, 2000, XP, Vista™, Windows 7, Windows 8, System Requirements Windows10,MAC® OS, NetWare®, UNIX® or Linux. Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Copyright © 2011 TP-LINK Technologies Co., Ltd. All rights r
