| System | - Memory: 8GB |
|---|
| Overview | - Flash: 64GB • CPU: 4 cores at 2.2GHz + 4 cores at 2.0GHz • AI Computing Power: 13.2T FLOPS • Size: - MeetingBoard 65 Pro: 65 inch - MeetingBoard 75 Pro: 75 inch - MeetingBoard 86 Pro: 86 inch • Anti-glare panel • Resolution: 3840 x 2160 |
|---|
| Display | • Color Gamut: 72% NTSC/99% sRGB • Color Depth: 1.07G (10bit) • Contrast Ratio: 1200:1 • Brightness: 400 cd/㎡ • Refresh Rate: 60 Hz • Viewing Angle: 178°(H)/178°(V) • System wake-up: Motion sensor • Touch Technology: Infrared • Touch Height: 1.5 mm • Touch Accuracy: ±1 mm Touch • Touch Points: 20 points • Touch latency: 21 ms（Measured under yealink whiteboard） • Four-level stylus • Max Resolution: |
|---|
| Speakers | • Expansion output: Supports RCA output • THD (Total Harmonic Distortion): at 20W, 1KHz, <5% • Rated impedance: tweeter-4ohm，full-range speaker-8ohm • Rated power: 30W • Max power: 36W • Built-in 16 MEMS microphone array • Pickup distance: 12 meters full-duplex • Signal-to-noise ratio: 70dB@1KHz • Max sound pressure level: 130dB SPL • Equivalent noise level: 24dB SPL |
|---|
| Microphones | • Dynamic range: 24-130dB SPL • Sensitivity: -38±1dBV/Pa • Frequency response: 20Hz~20KHz • Sampling rate: 48KHz • Bit depth: 24-bit • Expansion input: supports RCA input |
|---|
| Video | • Lens resolution: supports up to 4K30fps |
|---|
| 解像度 | • Content sharing: supports up to 4K60fps (HDMI In) locally, and up to 4K15fps in meetings • Wired screen sharing: - HDMI In - VCH51 • Wireless screen sharing - AirPlay - Miracast - Wireless Presentation Pod (unavailable in the United States) • Yealink AI Audio 2.1 • Multi-channel echo cancellation processing • Noise suppression technology • Multi-channel reverberation cancellation technology • Mu |
|---|
| and | Video codecs: H.264 SVC, H.264 High Profile, H.264, • Wi-Fi 6 - 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax |
|---|
| Network | - 2x2 MIMO |
|---|
| 網絡協議 | • Bluetooth 5.1 • TCP/IP (IPv4/IPv6), DHCP/Static IP • HTTPS secure web access • Encryption protocols: supports H.235/TLS/signaling encryption • Encryption algorithms: supports SRTP media stream encryption and AES-256 encryption • Security mechanisms: supports VLAN, 802.1P/Q, Diffserv, and other QoS services • Security protocols: supports 802.1X, LLDP-MED, and other network security protocols • We |
|---|
| 安全 | • Secure connection: supports OpenVPN • Other security mechanisms: - Built-in security encryption certificate - Supports protection against network and protocol attacks - Supports meeting password to ensure meeting security - Supports meeting whitelist and blacklist • Configuration methods: Web/Device/Touch screen • Debugging interface: RJ45/USB 2.0 • Upgrade methods: Web/TAC/ZDM/USB • Device mana |
|---|
| Hardware | • Reset button |
|---|
| Description | • 1 LED MUTE light • Human motion sensor (for automatic device wake-up) • Wall-mounted installation • Wall-stand installation • Floor-stand installation • Display output interface: 1 x HDMI output interface (supports CEC) • Content input interface: 1 x HDMI input interface • Line input interface: 1 pair of RCA line inputs • Line output interface: 1 pair of RCA line outputs • 3 x USB-A 2.0 interfac |
|---|
| MeetingBoard 65 Pro | MeetingBoard 75 Pro MeetingBoard 86 Pro |
|---|
| Packaging Dimensions (W × D × H) | 1660 x 220 x 1045 mm 1900 x 225 x 1160 mm 2095 x 225 x 1310 mm |
|---|
| Bare device dimensions(W × D × H) | 1484 x 105 x 955 mm 1705 x 105 x 1081 mm 1951 x 105 x 1218 mm |
|---|
| With stand dimensions(W × D × H) | 1484 x 778 x 1887 mm 1705 x 858 x 1960 mm 1950 x 858 x 2058 mm |
|---|
| VESA hole specs | 600 x 400 mm 800 x 600 mm 800 x 600 mm |
|---|
| 毛重 | 50 kg (110.2 lbs) 65 kg (143.3 lbs) 83.2 kg (183.02 lbs) |
|---|
| 淨重 | 40 kg (88.2 lbs) 52.2 kg (115.74lbs) 65.6 kg (144.7 lbs) |
|---|
| Quantity | 1 unit/box 1 unit/box 1 unit/box 65-inch mobile stand 75-inch mobile stand 86-inch mobile stand (with tray): MB-FS-P650T (with tray): MB-FS-P750T (with tray): MB-FS-P860T Stand |
|---|
| dimensions(W × D | 1168 x 778 x 1034 mm 1362 × 850 × 994 mm 1432 x 858 x 954 mm × H) Outer box |
|---|
