DAHUA DH-XVR7108HE-4K-X CCTV攝影機安裝・保養

Name: DAHUA DH-XVR7108HE-4K-X DH-XVR7108HE-4K-X
Brand: dahua
SKU: DH-XVR7108HE-4K-X

產品簡介

dahua DH-XVR7108HE-4K-X 為DH-XVR7108HE-4K-X，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DH-XVR7108HE-4K-X 香港價格連安裝報價。

System：Trigger Events Buzzer and Screen Tips
Main Processor：Embedded Processor Motion Detection, MD Zones: 396 (22 × 18)
操作系統：Embedded LINUX
警報輸入：8
Relay Output：3

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

System	Trigger Events Buzzer and Screen Tips
Main Processor	Embedded Processor Motion Detection, MD Zones: 396 (22 × 18), Video Video Detection Loss,Tampering and Diagnosis
操作系統	Embedded LINUX
警報輸入	8
Relay Output	3
Analog Camera Input	8 Channel, BNC Playback and Backup 4K, 6MP, 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, HDCVI Camera 720P@25/30fps Playback 1/4/9
AHD Camera	5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps Time /Date, Alarm, MD and Exact Search (accurate to Search Mode second)
TVI Camera	5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File,
CVBS Camera	PAL/NTSC Playback Function Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
IP Camera Input	8+8 Channel, each channel up to 8MP
Backup Mode	USB Device/Network
Audio In/Out	8 Channel Input, 1 Channel Output, RCA
Two-way Talk	Reuse audio in/out, RCA Storage
Recording	Internal HDD 1 SATA Port, up to 10TB capacity for each disk
Compression	H.265+/H.265/H.264+/H.264 eSATA N/A
解像度	4K, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF, QCIF
USB	2 USB Ports (1 USB 2.0 , 1 USB 3.0) Main stream: 4K(1~15fps); 6MP(1~20fps); 5MP(1~25fps); 4MP/3MP/1080P/720P/960H/D1/CIF/QCIF (1~25/30fps) RS232 N/A Record Rate Sub steram:960H(1~15fps);
D1/CIF/QCIF(1~25/30fps)	RS485 1 Port, for PTZ Control
Bit Rate	1Kbps ~ 8192Kbps Per Channel Electrical
供電	DC12V/2A Manual, Schedule (General, Continuous), MD (Video detection: Record Mode Motion Detection, Video Loss, Tampering), Alarm, Stop
功耗	<15W (Without HDD) 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post- Record Interval record: 10 ~ 300 sec Construction
尺寸	Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2")
接口	1 HDMI, 1 VGA Net Weight 1.45kg (3.2lb) (without HDD) HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024, Gross Weight 2kg (4.4lb)
VGA: 1920×1080, 1280×1024, 1280×720	Installation Desktop installation When IP extension mode not enabled: 1/4/8/9 Multi-screen Display When IP extension mode enabled: 1/4/8/9/16 Environmental Camera title, Time, Video loss, Camera lock, Motion detection, Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH OSD Recording
儲存環境	-20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH Third-party Support
Network Function	DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Sanyo, Sony, Videotec, Vivotek, and more Search (Support Dahua IP camera, DVR, NVS, etc.) Certifications
Max. User Access	128 users FCC: Part 15 Subpart B
Smart Phone	iPhone, iPad, Android CE: CE-LVD: EN 60950-1/IEC 60950-1
Interoperability	ONVIF 16.12, CGI Conformant Certifications CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1 www.dahuasecurity.com
Ordering Information	Rear Panel
類型	Part Number Description DH-XVR7108HE-4K-X 8 Channel XVR 8 Channel Penta-brid 4K Mini 1U DH-XVR7108HE-4K-X Digital Video Recorder 1 10 11
Dimensions (mm)	3 4 5 6 7 8 9 1 VIDEO IN 7 USB port 2 AUDIO IN, RCA Connector 8 DC12V Power Input 3 AUDIO OUT, RCA Connector 9 ALARM IN / OUT 4 HDMI port 10 VGA port 5 Network port 11 Power Switch 6 RS485 port
Rev 001.001	© 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com
