ZKTeco DS-852E33T-S3-MI-S-HL 為2 MP Smart Hybrid Light Fixed Lens Dome IP Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DS-852E33T-S3-MI-S-HL 香港價格連安裝報價。
| 影像感測器 | 1/2.8” 2 MP CMOS Sensor |
|---|---|
| 最大解像度 | 1920 (H) × 1080 (V) |
| ROM | 128 MB |
| RAM | 256 MB |
| Scanning System | Progressive Scan |
| Electronic Shutter Speed | 1/5 s to 1/100,000 s 0.001 Lux @ F1.3 (AGC on, Color) Min. Illumination 0 lux (IR on, B & W) |
| S/N Ratio | > 52 dB |
| IR Range | 40 m |
| 白光距離 | 30 m |
| Illuminator On / Off Control | Auto / Manual |
| Illuminator Number | 2 × IR / White Light integrated LED |
| Smart IR | Support Pan: 0° to 360° Angle Adjustment for Tilt: 0° to 90° Installation Rotation: 0° to 360° |
| TV System | PAL / NTSC Trigger mode, Brightness, Contrast, Saturation, Hue, Sharpness, AGC, White |
| 圖像設定 | balance, Gamma, Backlight mode, adjustable by platform software or web browser |
| Software Reset Default | Support |
| 一般功能 | Heartbeat, Mirror, Privacy mask, Log, Password reset |
| 鏡頭類型 | Fixed Lens |
| 鏡頭接口 | M22 |
| Mount Type | Board-in |
| 焦距 | 6 mm |
| Max. Aperture | F1.3 |
| Optical Zoom | N/A www.zkteco.com FOV: 60° Horizontal: 54° Field of View Vertical: 29° Diagonal: 63° |
| Iris Control Type | Fixed |
| Close Focus Distance | 1.5 m |
| 鏡頭 | Detect Observe Recognize Identify DORI Distance 6.0 mm 60.0 m 27.0 m 15.0 m 6.7 m |
| 視頻壓縮 | H.265 / H.264 |
| 解像度 | 2 MP (1920 × 1080) / 1.3 MP (1280 × 960) / 720P (1280 × 720) 50 Hz (PAL): 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) Main stream: 60 Hz (NTSC): 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) 50 Hz (PAL): 25 fps (704 × 576, 640 × 480, 640 × 360) |
| Max Video Frame Rate | Sub stream: 60 Hz (NTSC): 30 fps (704 × 576, 640 × 480, 640 × 360) 50 Hz (PAL): 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) Third stream: 60 Hz (NTSC): 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Video Stream Capability | Triple streams |
| 碼率控制 | CBR / VBR H.264: 896 Kbps to 6 Mbps Video Bit Rate H.265: 1024 Kbps to 6 Mbps |
| Day/Night | Auto (ICR) / Color / B&W |
| BLC | Support |
| HLC | Support |
| WDR | 120 dB True WDR |
| Scene Self-adaptation | Support Auto, Custom, Locked, Incandescent lamp, Warm light, Natural light, White Balance Fluorescent lamp |
| Gain Control | Low, Mid low, Mid, Mid high, High |
| Noise Reduction | 2D / 3D NR |
| Motion Detection | Smart / Ordinary (4 areas) |
| 感興趣區域 ROI | Support (4 areas, Level 1 to 6) |
| 除霧 | N/A |
| Mirror | Support |
| Image Rotation | 0° / 90° / 180° / 270° / Horizontal / Vertical |
| Privacy Masking | 4 areas |
| Corridor Mode | Support |
| Digital Zoom | Support |
| Anti-flicker | N/A |
| 內置麥克風 | Support |
| Speaker | N/A |
| 音訊壓縮 | G.711 ulaw |
| 環境噪音過濾 | Support |
| 音訊取樣率 | 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz |
| 音訊碼率 | 64 Kbps (G.711 ulaw) Intelligent Video Analytics Line Crossing, Area Detection, Smart Motion Detection (human and vehicle IVA (Perimeter Protection) targets classification) www.zkteco.com |
| Intelligent Search | Support fast retrieval by human and vehicle targets classification Support fast retrieval by human and vehicle targets classification, playback and Intelligent Video backup Face Detection |
| Face Templates | N/A |
| Face Quality Filtering | N/A |
| Face Detected Per Frame | N/A |
| Detection Area | N/A |
| Detected Face Size | N/A |
| Capture Response | N/A Alarm SD card error, Network disconnection, IP conflict, Illegal access, Motion Basic Alarm Event detection, Video tampering, External alarm Line Crossing, Area Detection, Smart Motion Detection (human and vehicle Smart Alarm Event targets classification) Upload to memory card / FTP, notify surveillance center, trigger recording, Alarm Linkage Actions trigger capture, send email |
| 同時取流 | Up to 15 channels |
| Network | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| SDK and API | Support SDK, API and ONVIF Video encryption; firmware encryption; configuration encryption; account lockout; security logs; IP filtering; trusted boot; trusted execution; trusted Cyber Security upgrade; password protection; complicated password; basic and digest authentication for HTTP/HTTPS; TLS; IP address filter; Security Audit Log TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTSP, NTP, UPnP, SMT |
| Interoperability | ONVIF Profile S / T / G |
| User / Host | Up to 256 users can be added. 3 user levels: admin, operator and guest |
| 網絡儲存 | FTP |
| 瀏覽器 | IE / Edge / Firefox / Chrome / Safari AntarVis 2.0 / ZKBioSecurity IVS / ZKBioAccess IVS / ZKBio CVSecurity / ZKBio Management Software CVAccess |
| Mobile Application | AntarView Pro+ (iOS & Android) |
| 機身儲存 | Micro-SD card slot (support max. 256 GB) |
| 操作系統 | Windows |
| P2P Cloud Service | Support Port |
| 音訊輸入 | N/A |
| 音訊輸出 | N/A |
| 警報輸入 | N/A |
| 警報輸出 | N/A |
| Reset Button | Support |
| ANR | Support |
| USB | N/A |
| RS485 | N/A Power www.zkteco.com |
| 供電 | PoE (IEEE802.3af, Class 3), DC 12 V ± 10% reverse polarity protection |
| 功耗 | Basic ≤3 W (12 VDC); 4.5 W (PoE) |
| 電源接口 | Ø 5.5 mm coaxial power plug Structure |
| Casing Material | Aluminium Alloy |
| 尺寸 | Φ117 * 94.2 (mm) |
| 淨重 | 0.54 KG |
| 毛重 | 0.625 KG |
| Operating Conditions | –30 °C to +60 °C (–22 °F to +140 °F) / Humidity 95% or less (non-condensing) |
| 儲存環境 | –30 °C to +60 °C (–22 °F to +140 °F) / Humidity 95% or less (non-condensing) |
| Ingress Protection Rating | IP67 (water and dust proof ); IK10 (vandal resistance) Certifications |
| Certificate | ISO9001, ISO14001, CE, FCC |
| 類型 | Model Descripton 2 MP Smart Hybrid Light Fixed Lens 2 MP IP Camera DS-852E33T-S3-MI-S-HL Dome IP Camera 94.20 Ø 117.00 |
| Junction Box with Junction Box with | Corner Mount Pole Mount |
| Optional Bracket | Junction Box |
| Straight Bracke | Bent Bracket Bracket Bracket Picture V1.1 01/15/2025 |
| ZKTECO CO.,LTD. www.zkteco.com | E-mail: sales@zkteco.com Copyright © 2025ZKTECO CO., LTD. All rights reserved. |
* 規格以原廠最新 Datasheet 為準。
Φ117 * 94.2 (mm)｜Unit: mm
DS-852E33T-S3-MI-S-HL ZKTeco 2 MP Smart Hybrid Light Fixed Lens Dome IP Camera亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，DS-852E33T-S3-MI-S-HL 原廠行貨連保養，提供上門安裝、系統設定及使用教學，全港 32 區均有服務。
我們會按現場門型（玻璃門、木門、鐵閘）配置電鎖及出門按鈕，並以我們自行研發的考勤軟件設定考勤報表及權限分組，交付即可使用。
於我們自行研發的考勤軟件或網頁後台刪除該員工權限即時生效，無需回收實體鎖匙或更換門鎖。
兩者屬同系列產品，實際應該邊個型號更適合，需視乎現場環境同需求而定。歡迎直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 DS-852E33T-S3-MI-S-HL 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱門禁系統安裝工程頁面或聯絡我們查詢保養範圍。
