| 操作系統 | Linux CPU: Quad Core with max. clock rate 1.5GHz RAM: 2GB eMMC: 16GB Compute Power: 4 Tops |
|---|
| Authentication method | Fingerprint / RFID / QR code (static) / Password Onboard Access Point: 1 Scalabe Door Control Points: up to 16 Access Point Capacity via ZKTeco's DE10 door unit OR via Primary-Secondary mode RS-485: ZKTeco RS-485 Protocol / OSDP (Version 2.1.7) Type of Reader Supported Wiegand: 26 / 34 / 66-bit (via WR485) (Coming Soon) |
|---|
| IO Expansion Board Capacity | 8pcs EX0808 (RS-485 connection) |
|---|
| 用戶容量 | 5,000(Optional: 100,000) |
|---|
| 卡容量 | 5,000 (1: N) (Standard) Optional: 100,000 (1:N) |
|---|
| Fingerprint Template Capacity | 10,000 (1: N) (Standard) Optional: 20,000 (1:N) |
|---|
| Facial Template Capacity | N/A |
|---|
| QR Code Capacity | 5,000 (Static QR Code) ; Optional: 100,000 |
|---|
| Transaction Capacity | 300,000 |
|---|
| Fingerprint Authentication Speed | less than 0.5sec (Fingerprint) |
|---|
| Fingerprint Authentication Algorithms | ZKFingerprint Algorithm V13.0 (Default) / V10.0 |
|---|
| False Acceptance Rate (FAR) % | FAR 0.0001% (Fingerprint) |
|---|
| False Rejection Rate (FRR) % | FRR 0.01% (Fingerprint) 1* Exit Button, 1* Door Status, 1 * AUX Inputs,1* Tamper,1* Fire Alarm; Number of Inputs or 64 (with 8pcs of EX0808 IO expansion board) 1* Form C Relay for Lock, 1* Form C Relay for Aux Output,1* Audio output; Number of Outputs or 64 (with 8pcs of EX0808 IO expansion board) |
|---|
| Max. Card Number Length | 16 digits |
|---|
| QR Code | Standard QR code (Static) TCP/IP * 1 RS-485: ZKTeco RS-485 / OSDP (Optional) * 2 USB 3.0: Type A (USB Drive Only) * 1 |
|---|
| Communication | SATA: (3.5" SATA HDD, up to 20TB) * 1 Wi-Fi: IEEE 802.11 b/n/g @ 2.4 GHz ; AP mode Aux Inputs * 1, Aux Outputs * 1, Electric Lock * 1, Door Sensor * 1, Exit Button * 1, Alarm * 1, Tamper * 1, Audio out * 1; Webserver, Up to 14-digit User ID, Access Levels, Access Groups, Holidays,Anti-passback, Anti- |
|---|
| Standard Functions | tailgating, Linkage, Global Linkage, Multiple Authentication Methods,Power Detection, LED Status Output, Primary-Secondary Mode. RS-485 (RS-485 Card Reader / Fingerprint Reader / QR code Reader); Access Control Interface Wiegand (Card Reader) (Coming soon) Intelligent Video Analytics (IVA) Video Channel: 4 Decoding Format: H.264/H.265; Split Screen: 4; |
|---|
| Audio and video | Decoding Capacity: 4; Synchronized Playback Channels: 4; Maximum video resolution: 8MP/5MP/3MP/1080P/960P/720P/D1VGAV4CIF/DCIF/2CIF/ CIF/OCIF Absent detection, Detects employee absence from designated stations. Absent Detection Configurable: zone occupancy count, motion sensing, time threshold. Alarm triggered (Standard) when absence duration exceeded. Cross line statistics(target counting). Confi |
|---|
| Object Detection | Supports missing object detection, abandoned object detection, and object removal / (Standard) abandonment detection. Area Detection Monitors zone entry, exit, entry/exit, loitering, and intrusion (persistent alarm on zone breach). (Standard) Tripwire Detection Triggers when persons, motor vehicles, or non-motor vehicles cross designated lines. (Standard) Validates single-person entry during acces |
|---|
| 供電 | DC 12V 5A -10℃ to 55℃ (Without Hard Disk) Operating Temperature 0℃ to 45℃ (With Hard Disk) |
|---|
| 工作濕度 | 10% to 90% RH (Non-condensing) |
|---|
| 尺寸 | 200mm*111mm* 32mm (L*W*H) |
|---|
| 毛重 | 0.55 Kg |
|---|
| 淨重 | 0.35 Kg |
|---|
| 防護等級 | N/A |
|---|
| Supported Software | On-board web console |
|---|
| 安裝 | Supported DIN35 Rail / Wall mount /Metal Enclosure (Optional) Size: 242mm*197mm*72mm (L*W*H) |
|---|
| Enclosure (Optional) | Material: SPCC steel Net Weight: 2.12 kg (without hard disk) |
|---|
| Certifications | ISO14001, ISO9001, CE, FCC, Equivalent to RoHS |
|---|
| Factory ID | AC02-CB41H-42 |
|---|
| I/O Expansion Board | I/O Expansion Board |
|---|
| GND | GND 485- 485- 485+ 485+ Web Client |
|---|
| DC 12V | DC 12V DC 12V PC (Browser) DC 12V DC 12V DC 12V |
|---|
| #1 EX0808 | #2 EX0808 #8 EX0808 #1 EX0808 #2 EX0808 #8 EX0808 Tablet |
|---|
| Mobile Device | (Browser) (Browser) |
|---|
| KR902 | OSDP |
|---|
| Mobile Client | FR1500S Mobile Client FR1500S |
|---|
| 警報 | Alarm 1# in #2 out 1# in #2 out |
|---|
| WiFi | RS485 Wi-Fi Wi-Fi Wi-Fi RS485 TCP/IP |
|---|
| Primary Controller | Secondary Controller PoE Switch TCP/IP |
|---|
| Door Sensor | Door Sensor |
|---|
| Hard Disk | Hard Disk Electric Lock Electric Lock |
|---|
| No Touch | No Touch |
|---|
| EXIT | EXIT |
|---|
| Exit Button Door 1 | Exit Button Door 2 TCP/IP |
|---|
| POE | PoE |
|---|
| CAM 1 | CAM 2 CAM 3 CAM 4 CAM 1 CAM 2 CAM 3 CAM 4 |
|---|
| FR1500S | KR904 FR1500S KR904 |
|---|
| Door 3 | Door 4 111 32 200 197 242 72 |
|---|
| CVEdge 160 Enclosure | CVEdge 160 Hard Disk(Optional) V1.0 03/19/2026 |
|---|
