| Varifocal, 5.9–13.8 mm, F1.5–2.9 | Compute capabilities |
|---|
| Horizontal field of view: 114°-46° | Deep learning processing unit (DLPU) Vertical field of view: 62°-26° |
|---|
| Minimum focus distance: 1 m (3.3 ft) | Video 29 mm lens: Varifocal, 10.9–29 mm, F1.7 |
|---|
| Horizontal field of view 29˚–11˚ | Video compression |
|---|
| Vertical field of view 16˚–6˚ | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High |
|---|
| Minimum focus distance: 2.5 m (8.2 ft) | Profiles |
|---|
| Both lenses: | H.265 (MPEG-H Part 2/HEVC) Main Profile IR corrected, remote zoom and focus, P-iris control Motion JPEG |
|---|
| Day and night | Resolution |
|---|
| Automatic IR-cut filter | 5.9 mm lens: 16:9: 3840x2160 to 480x270 16:10: 2560x1600 to 640x400 |
|---|
| Minimum illumination | 4:3: 2592x1944 to 320x240 5.9 mm lens: 29 mm lens: |
|---|
| Color: 0.05 lux at 50 IRE, F1.5 | 16:9: 1920x1080 to 480x270 |
|---|
| B/W: 0.01 lux at 50 IRE, F1.5 | 16:10: 1280x800 to 640x400 0 lux with IR illumination on 4:3: 1280x960 to 320x240 29 mm lens: Color: 0.06 lux, at 50 IRE F1.7 |
|---|
| B/W: 0.01 lux, at 50 IRE F1.7 | Frame rate 0 lux with IR illumination on With Forensic WDR: Up to 25/30 fps (50/60 Hz) in all resolutions No WDR: Up to 50/60 fps (50/60 Hz) in all resolutions |
|---|
| 快門速度 | (for 29 mm lens only) 5.9 mm lens: With Forensic WDR: 1/33,500 s to 2 s |
|---|
| No WDR: 1/66,500 s to 2 s | Video streaming 29 mm lens: Up to 20 unique and configurable video streams1 |
|---|
| With Forensic WDR: 1/37,000 s to 2 s | Axis Zipstream technology in H.264 and H.265 |
|---|
| No WDR: 1/71,500 s to 2 s | Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 Low latency mode |
|---|
| Camera adjustment | Video streaming indicator 29 mm lens: Pan ±15°, tilt ±15° Signal-to-noise ratio >55 dB WDR Forensic WDR: Up to 120 dB depending on scene utilization. A unique video stream can be served to many video clients in the network using multicast or unicast transport method via built-in stream reuse functionality. |
|---|
| Spatial filter (2D noise reduction) | Network Temporal filter (3D noise reduction) Network protocols |
|---|
| 圖像設定 | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS3, HTTP/ Saturation, contrast, brightness, sharpness, white 2, TLS3, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, balance, day/night threshold, local contrast, tone SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB- mapping, exposure mode, exposure zones, defog, barrel II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ distortion correction, compression, |
|---|
| polygon privacy mask | (ZeroConf) Scene profiles: forensic, vivid, traffic overview, license |
|---|
| plate (for 29 mm lens only) | System integration |
|---|
| Image processing | Application Programming Interface Axis Zipstream, Forensic WDR, Lightfinder 2.0, Open API for software integration, including VAPIX®, |
|---|
| OptimizedIR | metadata and AXIS Camera Application Platform (ACAP); specifications at axis.com/developer- |
|---|
| Pan/Tilt/Zoom | community. |
|---|
| Optical zoom, preset positions | One-click cloud connection |
|---|
| Control queue | ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T, specifications at onvif.org Video management systems Compatible with AXIS Camera Station Edge, |
|---|
| Features | AXIS Camera Station Pro, AXIS Camera Station 5, and |
|---|
| Automatic gain control | video management software from Axis’ partners |
|---|
| Speaker pairing | available at axis.com/vms. Microphone pairing Spectrum visualizer2 Onscreen controls IR illumination |
|---|
| Streaming | Privacy masks |
|---|
| Configurable duplex: | Media clip Two-way (half duplex, full duplex) Edge-to-edge |
|---|
| Input | Microphone pairing |
|---|
| Input through microphone pairing | Radar pairing Input for external unbalanced microphone, optional 5 V Speaker pairing microphone power Digital input, optional 12 V ring power Unbalanced line input Output Output through speaker pairing Encoding 24bit LPCM, AAC-LC 8/16/32//44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz Configurable bitrate written by Eric Young (eay@cryptsoft.com). |
|---|
| Event conditions | AXIS Object Analytics |
|---|
| ready | detection, PPE monitoringBETA, motion in area, motion |
|---|
| missing, digital signal okay | Other features: triggered objects visualized with |
|---|
| storage health issues detected | Polygon include/exclude areas |
|---|
| MQTT: client connected, stateless | ONVIF Motion Alarm event |
|---|
| tampering | AXIS Scene Metadata Object classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates |
|---|
| Event actions | Object attributes: vehicle color, upper/lower clothing |
|---|
| Day-night mode: use day-night mode | color, confidence, position Approvals |
|---|
| network share and email | Product markings |
|---|
| MQTT: publish | CSA, UL/cUL, CE, KC, EAC, VCCI, RCM |
|---|
| Overlay text: use overlay text | Supply chain |
|---|
| Recordings: record video | TAA compliant |
|---|
| HTTPS, network share and email | CISPR 35, CISPR 32 Class A, EN 55035, |
|---|
| WDR mode: set WDR mode | EN 55032 Class A, EN 50121-4, EN 50121-3-2, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2 |
|---|
| Built-in installation aids | Australia/New Zealand: RCM AS/NZS CISPR 32 Class A USA: FCC Part 15 Subpart B Class A |
|---|
| Analytics | Railway: IEC 62236-4 |
|---|
| Applications | CAN/CSA C22.2 No. 62368-1 ed. 3, |
|---|
| Included | IEC/EN/UL 62368-1 ed. 3, IEC/EN 62471 risk group |
|---|
| Supported | Environment |
|---|
| acap | NEMA 250 Type 4X NIST SP500-267 Cybersecurity ETSI EN 303 645, BSI IT Security Label, FIPS 140 |
|---|
| Cybersecurity | Network: Shielded RJ45 10BASE-T/100BASE-TX/ 1000BASE-T PoE Audio: 3.5 mm mic/line in Edge security Serial communication: RS485/RS422, 2 pcs, 2 pos, full Software: Signed OS, brute force delay protection, duplex, terminal block digest authentication and OAuth 2.0 RFC6749 OpenID Power: DC input, terminal block Authorization Code Flow for centralized ADFS account I/O: Terminal block for two configura |
|---|
| filesystem (AES-XTS-Plain64 256bit) | OptimizedIR with power-efficient, long-life 850 nm IR Range of reach 50 m (164 ft) or more depending on the Network security scene IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)4, IEEE 802.1AR, HTTPS/HSTS4, TLS v1.2/v1.34, Network Time Security (NTS), X.509 Certificate PKI, host-based Storage |
|---|
| firewall | Support for microSD/microSDHC/microSDXC card Support for SD card encryption (AES-XTS-Plain64 256bit) Documentation Recording to network-attached storage (NAS) AXIS OS Hardening Guide For SD card and NAS recommendations see axis.com Axis Vulnerability Management Policy Axis Security Development Model |
|---|
| AXIS OS Software Bill of Material (SBOM) | Operating conditions To download documents, go to axis.com/support/ Temperature with full power: -40 °C to 60 °C (-40 °F to |
|---|
| cybersecurity/resources | 140 °F) To read more about Axis cybersecurity support, go to Temperature with low power: -5 °C to 60 °C (23 °F to |
|---|
| axis.com/cybersecurity | 140 °F) Start-up temperature: -30 °C |
|---|
| General | Wind speed (sustained): 60 m/s (134 mph) Humidity: 10–100% RH (condensing) Casing |
|---|
| IP66/67-, NEMA 4X- and IK10-rated | Storage conditions |
|---|
| Aluminum and plastic casing | Temperature: -40 °C to 65 °C (-40 °F to 149 °F) |
|---|
| Color: white NCS S 1002-B | Humidity: 5–95% RH (non-condensing) For repainting instructions, go to the product’s support page. For information about the impact on warranty, go Dimensions to axis.com/warranty-implication-when-repainting. For the overall product dimensions, see the dimension drawing in this datasheet. |
|---|
| 供電 | Effective Projected Area (EPA): 0.08193 m2 (0.88 ft2) Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 |
|---|
| Class 4 | Weight |
|---|
| Typical 13.2 W, max 25.5 W | 3,850 g (8.5 lb) 10–28 V DC, typical 13.3 W, max 25.5 W Features: power profiles, power meter Box content Camera, installation guide, AXIS TQ1003-E Wall Mount, terminal block connectors, connector guard, cable gaskets, owner authentication key written by Eric Young (eay@cryptsoft.com). |
|---|
| DORI definition | Distance (wide) Distance (tele) |
|---|
| Detect | 25 px/m (8 px/ft) 80.5 m (264 ft) 193.5 m (634.7 ft) |
|---|
| Observe | 63 px/m (19 px/ft) 31.9 m (105 ft) 76.8 m (252 ft) |
|---|
| Recognize | 125 px/m (38 px/ft) 16.1 m (52.8 ft) 38.7 m (127 ft) |
|---|
| Identify | 250 px/m (76 px/ft) 8.1 m (27 ft) 19.3 m (63.3 ft) |
|---|
| www.axis.com | T10201869/EN/M6.2/202602 |
|---|
| AXIS Object Analytics | in low light better than the human eye. In surveillance, |
|---|
| cryptographic | information used for secure © 2024 – 2026 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ARTPEC and VAPIX are registered trademarks of Axis AB in various jurisdictions. All other trademarks are the property of their respective owners. We reserve the right to introduce modifications without notice. |
|---|
