BELDEN 10GX52F 安裝、保養、維修
10GX52F
拉網線 | 拉光纖 | FLUKE認證 — 硬件連工程一站式
詳細規格
| Environmental Space: | Riser Premise Horizontal Cable, 10 Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video, AES/EBU Digital Audio, AES51, RS-422, Noisy Environments, PoE, PoE+ |
|---|
| AWG Stranding | Material No. of Pairs |
|---|
| Conductor Count: | 8 |
|---|
| Total Number of Pairs: | 4 Material |
|---|
| Number | Color |
|---|
| 類型 | Material Material Trade Name Coverage [%] Drainwire Material Drainwire AWG |
|---|
| Tape | Aluminum Foil-Polyester Beldfoil® 100 % TC - Tinned Copper 26 |
|---|
| 材質 | Nominal Diameter Ripcord |
|---|
| PVC - Polyvinyl Chloride 0.275 in | Yes |
|---|
| Max. Delay | Max. Delay Skew Nominal Velocity of Propagation (VP) [%] |
|---|
| @ 100 MHz 537.6 ns/100m 45 ns/100m | 64 % |
|---|
| Min. RL | Max./Min. |
|---|
| Max. Insertion | Min. Min. Min. PSACRF Max./Min. Min. Min. |
|---|
| Frequency | (Return Input Min. Min. |
|---|
| Loss | PSNEXT PSACR (PSELFEXT) Fitted TCL ELTCTL |
|---|
| [MHz] | Loss) Impedance PSANEXT PSAACRF (Attenuation) [dB] [dB] [dB] Impedance [dB] [dB] |
|---|
| [dB] | (unFitted) |
|---|
| Installation Temp Range: | +5°C To +50°C |
|---|
| UL Temp Rating: | 90°C |
|---|
| Storage Temp Range: | -20°C To +75°C |
|---|
| Operating Temp Range: | -20°C To +75°C |
|---|
| Bulk Cable Weight: | 41 lbs/1000ft |
|---|
| Max Recommended Pulling | 25 lbs |
|---|
| Min Bend Radius/Minor Axis: | 2.25 in |
|---|
| Min Bend Radius/Installation: | 2.75 in |
|---|
| NEC/(UL) Specification: | CMR |
|---|
| CEC/C(UL) Specification: | CMR |
|---|
| ISO/IEC Compliance: | 11801 ed 2.2 (2011) Class EA |
|---|
| CPR Euroclass: | Eca |
|---|
| Data Category: | Category 6A |
|---|
| ANSI Compliance: | S-116-732-2013 Category 6A, ANSI/NEMA WC-66 Category 6A |
|---|
| Telecommunications Standards: | ANSI/TIA-568-C.2 Category 6A |
|---|
| IEEE Specification: | POE per 802.3af & POE+ per 802.3at-2009 |
|---|
| Other Specification: | Verified Channel/Category 6A |
|---|
| Other Standards: | C(UL)US CMR 90C OR (UL) CMR-LP (0.6A) OR CL3R-LP (0.6A) |
|---|
| EU Directive 2000/53/EC (ELV): | Yes |
|---|
| EU Directive 2002/96/EC | Yes |
|---|
| EU Directive 2003/11/EC (BFR): | Yes |
|---|
| EU Directive 2003/96/EC (BFR): | Yes |
|---|
| EU Directive 2012/19/EU | Yes |
|---|
| EU Directive 2015/863/EU: | Yes |
|---|
| EU Directive Compliance: | Yes |
|---|
| EU CE Mark: | Yes |
|---|
| EU REACH SVHC Compliance | 2017-07-10 |
|---|
| EU RoHS Compliance Date | 2011-03-07 |
|---|
| CA Prop 65 (CJ for Wire & | Yes |
|---|
| MII Order #39 (China RoHS): | Yes |
|---|
| Suitability - Aerial: | No |
|---|
| Suitability - Burial: | No |
|---|
| Suitability - Indoor: | Yes |
|---|
| Suitability - Non-Halogenated: | No |
|---|
| Suitability - Oil Resistance: | No |
|---|
| Suitability - Outdoor: | No |
|---|
| Suitability - Sunlight Resistance: | No |
|---|
| UL Flammability: | UL 1666 Riser |
|---|
| Plenum (Y/N): | No |
|---|
| Plenum Number: | 10GX53F |
|---|
| Item # | Color |
|---|
| Patent: | http://www.belden.com/p |
|---|
* 規格以原廠最新 Datasheet 為準。
規格書連結更新中，如需完整PDF請WhatsApp查詢
綜合佈線安裝工程服務
HKEZIT 專營拉網線、拉光纖、FLUKE認證工程，10GX52F 由我們供貨、安裝、調試到使用教學一站式完成。無論拉網線、拉光纖或FLUKE認證，均由自家工程團隊上門施工，品質有保證。
綜合佈線適合邊類專業客戶
10GX52F Belden 10GX52F CAT6A屏蔽網線亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
常見問題
10GX52F 定 AX102282 邊個好？
兩者屬同系列產品，實際應該邊個型號更適合，需視乎現場環境同需求而定。歡迎直接聯絡我們免費現場評估，由工程師建議最合適方案。
10GX52F 保養、維修邊度做？
HKEZIT 提供 10GX52F 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱綜合佈線安裝工程頁面或聯絡我們查詢保養範圍。
