Dahua ASI6213S 為DHI-ASI6213S，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 ASI6213S 香港價格連安裝報價。
| System | · TCP/IP connection. · IP65 rated. |
|---|---|
| Main Processor | Embedded Processor |
| Button Type | Touch button |
| 網絡協議 | UDP; TCP; IPv4; RTSP; SIP; P2P; RTP Holiday Period 128 periods |
| OSDP Protocol | Yes Network Update Yes |
| Interoperability | CGI; ONVIF First User Unlock Yes |
| SDK and API | Yes Remote Verification Yes |
| Basic | Restricted List/Trusted List Yes |
| Product Type | Standalone 1 × RS-485 card reader |
| Peripheral Card Reader | 1 × Wiegand card reader |
| Display Screen | 4.3" LCD |
| Multi-user Authentication | Yes |
| Screen Type | Capacitive Touchscreen |
| Real-time Monitoring | Yes |
| Screen Resolution | 272 (H) × 480 (V) |
| Multi-factor Authentication | Yes |
| Camera | 2-MP CMOS HD dual-lens camera |
| Capture Function | Yes |
| WDR | DWDR |
| Web Configuration | Yes |
| Light Compensation | Auto IR |
| Auto Registration | Yes |
| Voice Prompt | Yes Yes Performance Buzzer |
| Card Reading Distance | 0 cm–3 cm (0"–1.18") |
| Casing Material | PC+GF |
| Face Recognition Height | 1.1 m–2.0 m (3.61 ft–6.56 ft) |
| Function | Range |
| Card, remote, password, QR code, face and | Face Recognition Distance 0.3 m–1.5 m (0.98 ft–4.92 ft) |
| Unlock Mode | combination unlock |
| Face Recognition Accuracy | 99.9% |
| 卡類型 | IC cards |
| Face Recognition Time | 0.2 s |
| Period List | 128 periods www.dahuasecurity.com |
| User | Operating Altitude 0 m–1,300 m (0 ft–4265.09 ft) Normal user; VIP users; patrol users; guest user; Operating Environment Outdoor; Indoor |
| User (Card) Type | blocklist user; other user; custom user 1; custom user 2 |
| 毛重 | 0.70 kg (1.54 lb) |
| Accessory | Wall mount bracket (included) |
| 用戶容量 | 6,000 Turnstile mount; 86 case mount; wall mount; surface |
| Face Image Capacity | 6,000 Installation mount |
| 卡容量 | 10,000 |
| Password Capacity | 6,000 Installation |
| Record Capacity | 300,000 Port |
| RS-485 | 1 |
| Wiegand | 1 |
| USB | 1 |
| Network Port | 1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| 警報輸入 | 1 |
| 警報輸出 | 1 |
| Alarm Linkage | Yes |
| 出門按鈕 | 1 |
| Door Status Detection | 1 |
| 鎖控 | 1 Alarm Dimensions (mm[inch]) |
| Anti-pass Back | Yes |
| Tamper Alarm | Yes |
| Duress Alarm | Yes |
| Door Sensor Timeout | Yes |
| Intrusion | Yes |
| Illegal Card Exceeding | Yes Threshold |
| Power Adapter | Included |
| 供電 | 12 VDC, 1.5 A |
| 防護等級 | IP65 |
| 功耗 | ≤12 W 180.1 mm × 90.1 mm × 27.0 mm (7.09" × 3.55" × 1.06") |
| Product Dimensions | (L × W × H) 268 mm × 136 mm × 78 mm (10.55" × 5.35" × 3.07") (L × W × H, in an inner carton) |
| Packaging Dimensions | 590 mm × 432 mm × 302 mm (23.23" × 17.01" × 11.89") (L × W × H, protection box) |
| 工作溫度 | –30 °C to +60 °C (–22 °F to +140 °F) |
| 工作濕度 | 0%–90% (RH), non-condensing www.dahuasecurity.com Application |
| Rev 002.000 | © 2023 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com |
* 規格以原廠最新 Datasheet 為準。
詳見圖示｜Unit: mm
ASI6213S Dahua DHI-ASI6213S亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，ASI6213S 原廠行貨連保養，提供上門安裝、系統設定及使用教學，全港 32 區均有服務。
我們會按現場門型（玻璃門、木門、鐵閘）配置電鎖及出門按鈕，並以我們自行研發的考勤軟件設定考勤報表及權限分組，交付即可使用。
於我們自行研發的考勤軟件或網頁後台刪除該員工權限即時生效，無需回收實體鎖匙或更換門鎖。
兩者主要規格分別：Screen Type方面，ASI6213S 係 Capacitive Touchscreen，DHI-VTH5441G 係 Capactive screen Alarm Parameter；供電方面，ASI6213S 係 12 VDC, 1.5 A，DHI-VTH5441G 係 Optional；工作溫度方面，ASI6213S 係 –30 °C to +60 °C (–22 °F to +140 °F)，DHI-VTH5441G 係 -10°C to +55°C (+14°F to +131°F )。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 DHI-VTH5441G 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 ASI6213S 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱門禁系統安裝工程頁面或聯絡我們查詢保養範圍。
ASI6213S Dahua DHI-ASI6213S適合多種場景使用，以下為部分常見安裝場景，歡迎查詢是否適合您的現場環境。
圖書館裝門禁系統，讀者證感應進出、館藏區分級權限、閉館自動鎖定，保障館藏與秩序。全港覆蓋上門安裝，屯門、元朗各區歡迎致電查詢。
WhatsApp 查詢 →貨櫃碼頭閘口裝門禁系統，車牌識別道閘、司機身份核驗、貨運記錄聯動，管控重型車輛進出。免費上門度尺、按規模報價，將軍澳、銅鑼灣項目即約勘察。
WhatsApp 查詢 →豪宅別墅裝門禁系統，可視對講聯動、人臉識別大閘、家庭成員權限管理，高端私隱保安方案。專業團隊上門評估，灣仔、北角場地歡迎洽談報價。
WhatsApp 查詢 →私人會所裝門禁系統，會員資格核驗、分區尊享權限、訪客陪同管控，維持會所私密與尊貴。一站式勘測安裝，深水埗、葵涌各區即日約見報價。
WhatsApp 查詢 →共享辦公室裝門禁系統，手機App開門、按時段租戶授權、會議室預約聯動，靈活管理彈性空間。免費評估方案、即時報價，旺角、觀塘一帶歡迎查詢。
WhatsApp 查詢 →美容院裝門禁系統，預約客戶感應進出、VIP房間權限、員工分區管控，提升服務私密與安全。免費上門勘察、明碼實價報價，中環、尖沙咀一帶即日約期。
WhatsApp 查詢 →查看更多門禁系統適用場景，請參閱 門禁系統安裝工程。
如需整套門禁系統方案，請參閱 門禁系統安裝工程。
