| Main Processor | Quad-core embedded microprocessor |
|---|
| 操作系統 | Embedded LINUX |
|---|
| Bus | PCI-E |
|---|
| Slot | 12(2 Main Control Board Slot, 10 Video and Audio Function Board) |
|---|
| Mainframe | Power module (redundant power optional), main control board, control board, PCI-E bus rear panel, smart temperature controlled fan |
|---|
| Video Input Card | Max. 10 |
|---|
| Video Output Card | Max. 10 |
|---|
| VEC0404HD-M70 (DVI) | Interface 4ch DVI-I (HDMI & VGA with convertor) |
|---|
| Encoding | H.264/MPEG4 Format |
|---|
| Capability | SXGA+/SXGA/XGA/SVGA/VGA |
|---|
| VEC0404HH-M70 (HDMI) | Interface 4ch HDMI |
|---|
| VEC0404HV-M70 (VGA) | Interface 4ch VGA |
|---|
| VEC3204FB-M70 (CVBS) | Interface 32ch BNC (1.0Vp-p, 75Ω) |
|---|
| Signal | NTSC/PAL self-adaption Format |
|---|
| Data Ports | 2 RS485 ports |
|---|
| VEC0804HC-M70 (HDCVI) | Interface 8ch BNC (1.0Vp-p, 75Ω) |
|---|
| VEC0804HS-M70 | Interface 8ch BNC (1.0Vp-p, 75Ω) Format |
|---|
| Network Video | Encoding H.264/MPEG4/ONVIF/PISA Standard |
|---|
| Transfer | TCP/UDP/RTP/RTSP/RTCP/DHCP |
|---|
| Support | IPC, DVR, NVR, NVS, Video Matrix Device |
|---|
| Video | 1200W/800W/500W/300W/1080P/UXGA/720P/D1/HD1/ |
|---|
| Resolutio | 2CIF/CIF/QCIF |
|---|
| VDC0404UD-M70 | Decoding 8CH@12MP(15fps)/8CH@4K/32CH@1080P/72CH@720P |
|---|
| 接口 | 4ch DVI-D |
|---|
| H.265 | 4ch@1080P H.265 decoding |
|---|
| n | 1280*1024@60fps,1280*720@60fps, 1024*768@60fps |
|---|
| Split | 1/4/6/8/9/16/25/36 |
|---|
| VDC0605H-M70(HDMI) | Decoding 8CH@12MP(15fps)/8CH@4K/32CH@1080P/72CH@720P |
|---|
| VS0201R-M70(RAID Card) | Storage 2 pcs SAS storage device, support 48 4T HDDs Capability |
|---|
| RAID | RAID0/ RAID1/ RAID5/ RAID6/ RAID10 |
|---|
| Video Input | Analog Camera, Digital Camera, IPC, DVR, NVS, NVR and etc. |
|---|
| IP HD Matrix Switch | 2048 IP input, 160ch@1080p, 320ch@720p, 640ch@D1 |
|---|
| Decoding | Card Splicing Support video-wall splicing (max 60 LCD display units) |
|---|
| Video-Wall Splicing | Video-Wa Support Splicing Zoom/Merge/Roam/Overlay |
|---|
| Input | HD/SD, Digital/Analog (support mix input) Source |
|---|
| Output | DVI Port |
|---|
| Control | PC client-end/Local Operate Menu/Network |
|---|
| Mode | Keyboard/IPAD |
|---|
| Serial Port | 4 RS232 ports (4 RJ45), for console and control 1 RS485 ports |
|---|
| USB | 3 USB2.0, 1 USB3.0 |
|---|
| 供電 | 100~120V AC，200~240V AC |
|---|
| 功耗 | ≤600W |
|---|
| Working Environment | -10°C ~+50°C / 10~90%RH / 86~106kpa |
|---|
| 尺寸 | 4U, 482.6mm×496mm×177.8mm(W×D×H) |
|---|
| 重量 | ≤25Kg (full configured) Make your life safer ×Design and specifications are subject to change without notice. © 2012 Dahua Technology Co., Ltd. |
|---|
