| Hardware | Net Weight 0.5 kg (1.10 lb) |
|---|
| Included Power Adapter | Yes Gross Weight 1.25 kg (2.76 lb) |
|---|
| PoE | Yes 190 mm × 106 mm × 30 mm (7.48" × 4.17" × 1.18") (L × Product Dimensions W × H) |
|---|
| Ethernet Port | 8 256 mm × 244 mm × 87 mm (10.07" × 9.61" × 3.43") (L Packaging Dimensions |
|---|
| Ethernet Port Speed | 10/100 Mbps × W × H) |
|---|
| Ethernet Port Uplink Speed | 10/100/1000 Mbps Casing Material Sheet metal |
|---|
| Description of Function | Port 1-8: 8 × RJ-45 10/100 Mbps (PoE); Port 9-10: 2 × Installation Desktop mount; wall mount |
|---|
| Slots | RJ-45 10/100/1000 Mbps（uplink） |
|---|
| Certifications | CE |
|---|
| Reset Button | 1 |
|---|
| 供電 | External power supply: 54 VDC, 2.22 A |
|---|
| 工作溫度 | –10 °C to +55 °C (+14 °F to +131 °F) Ordering Information |
|---|
| 類型 | Part Number Description |
|---|
| 工作濕度 | 5%–95% (RH), non-condensing 10-Port Cloud Managed |
|---|
| 儲存溫度 | –40 °C to +70 °C (–40 °F to +158 °F) |
|---|
| PoE Switch | DH-CS4010-8ET-110 Desktop Switch with 8-Port |
|---|
| Storage Humidity | 5%–95% (RH), non-condensing PoE |
|---|
| 功耗 | Idling: ≤3 W; Full load: 110 W |
|---|
| Performance | Installation |
|---|
| Layer | Layer 2 |
|---|
| Management Type | Yes |
|---|
| Smart Managed Switch | Yes |
|---|
| MTBF | 150 years |
|---|
| 交換容量 | 5.6 Gbps |
|---|
| 包轉發率 | 4.17 Mpps |
|---|
| Packet Buffer Size | 4 Mbit |
|---|
| Jumbo Frame | 9216 Byte |
|---|
| MAC Table Size | 8K |
|---|
| VLAN Number | 32 |
|---|
| Communication Standard | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab |
|---|
| PoE Protocol | IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt |
|---|
| PoE Power | Port 1 ≤ 90 W, Port 2-8 ≤ 30 W, total ≤ 110 W Yes |
|---|
| PoE Pin Assignment | 1,2,4,5（V+）,3,6,7,8（V-） Yes |
|---|
| VLAN Function | Port-based VLAN |
|---|
| IEEE 802.3x Flow Control | Yes |
|---|
| DHCP Function | DHCP Client |
|---|
| Equipment Management | Web management; App management |
|---|
| Statics Protection | Air discharge: 8 kV; Contact discharge: 6 kV www.dahuasecurity.com |
|---|
