| Camera | OSD Menu Multi-language |
|---|
| 影像感測器 | 1/2.8" CMOS BLC Mode BLC / HLC / WDR |
|---|
| Effective Pixels | 1937(H)×1097(V), 2.1MP WDR 120dB |
|---|
| Scanning System | Progressive Gain Control AGC |
|---|
| PAL: 1/4s~1/100000s | Noise Reduction 2D / 3D Electronic Shutter Speed NTSC: 1/3s~1/100000s |
|---|
| White Balance | Auto / Manual |
|---|
| Minimum Illumination | 0.005Lux/F1.3, 30IRE, 0Lux IR on |
|---|
| Smart IR | Auto / Manual |
|---|
| S/N Ratio | More than 65dB |
|---|
| IR Distance | Up to 30m (98feet) Certifications |
|---|
| IR On/Off Control | Auto / Manual CE (EN55032, EN55024, EN50130-4) |
|---|
| Certifications | FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
|---|
| IR LEDs | 2 UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|---|
| 鏡頭 | Interface |
|---|
| 鏡頭類型 | Motorized lens / Fixed iris Audio Interface N/A |
|---|
| Mount Type | Board-in Eelectrical |
|---|
| 焦距 | 2.7-13.5mm Power Supply POC/12V DC ±25% |
|---|
| Max Aperture | F1.3 Power Consumption Max 8.8W (12V DC, IR on) |
|---|
| Angle of View | H: 102°~29° Power Output 12V DC, Max.2W |
|---|
| Focus Control | Auto / Manual Environmental 200mm -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH |
|---|
| Close Focus Distance | Operating Conditions 7.87'' * Start up should be done at above -40°C (-40°F) |
|---|
| DORI Distance | Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH Ingress Protection &Vandal *Note: The DORI distance is a “general proximity” of distance which makes it easy to IP67 & IK10 pinpoint the right camera for your needs. The DORI distance is calculated based on Resistance sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, |
|---|
| Casing | Aluminium |
|---|
| DORI 偵測距離 | Distance |
|---|
| Definition | Dimensions Φ122mm×88.9mm (Φ4.8"×3.5") |
|---|
| Wide | Tele 25px/m Net Weight 0.48kg (1.06lb) |
|---|
| Detect | 47m(153ft) 153m(502ft) (8px/ft) |
|---|
| 毛重 | 0.63kg (1.39lb) 63px/m |
|---|
| Observe | 19m(61ft) 61m(201ft) (19px/ft) 125px/m |
|---|
| Recognize | 9m(31ft) 31m(100ft) (38px/ft) 250px/m |
|---|
| Identify | 5m(15ft) 15m(50ft) (76px/ft) Pan / Tilt / Rotation Pan: 0° ~ 355° |
|---|
| Pan/Tilt/Rotation | Tilt: 0° ~ 75° Rotation: 0° ~ 355° |
|---|
| 解像度 | 1080P (1920×1080) |
|---|
| Frame Rate | 25/30fps@1080P, 25/30fps@720P 1-channel BNC high definition video output / CVBS Video Output video output (Can switch) www.dahuasecurity.com |
|---|
| Ordering Information | Juncon Mount In-ceiling Mount |
|---|
| PFA137 | PFB200C |
|---|
| 類型 | Part Number Description |
|---|
| DH-HAC-HDBW2231RP-Z-POC | 2MP Starlight HDCVI PoC IR Dome 2.7~13.5mm Camera, PAL 2MP Camera |
|---|
| DH-HAC-HDBW2231RN-Z-POC | 2MP Starlight HDCVI PoC IR Dome 2.7~13.5mm Camera, NTSC |
|---|
| PFB203W | PFB203W + PFA152-E |
|---|
| PFB200C | In-ceiling mount (For use alone) Wall mount (For use alone or with PFB203W PFA152-E pole mount) Pole mount (For use with PFA152-E PFB203W wall mount) Rain Shade (For use with PFA137 |
|---|
| PFA200W | wall mount or with PFA137 wall mount and PFA152-E pole mount) |
|---|
| Accessories | Wall Mount with Rain Shade Ceiling Mount (Extensible) Adapter Plate of Mini Dome & |
|---|
| PFA106 | PFA137+PFA200W PFA106+PFB220C Eyeball Camera Ceiling Mount Bracket of Mini PFB220C Dome & Eyeball Camera |
|---|
| PFM811-4CH | POC transmitter (PSE end) |
|---|
| PFM321 | 12V 1A power adapter |
|---|
| PFM320 | 12V 2A power adapter |
|---|
| PFM320D-015 | 12V 1.5A Power Adapter Pole Mount with Rain Shade PFA137+PFA200W+PFA152-E Accessories Optional: |
|---|
| Junction box | Inceiling mount Junction box Pole mount Dimensions (mm/inch) |
|---|
| Rain shade | Adapter plate Ceiling mount POC transmitter |
|---|
| bracket | (PSE end) |
|---|
| Adapter | Adapter |
|---|
| Rev 001.001 | © 2017 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
