| Camera | BLC Mode BLC / HLC / DWDR |
|---|
| 影像感測器 | 1/2.8" CMOS WDR DWDR |
|---|
| Effective Pixels | 1920(H)×1080(V), 2MP Gain Control AGC |
|---|
| Scanning System | Progressive Noise Reduction 2D |
|---|
| PAL: 1/25~1/100000s | White Balance Auto / Manual Electronic Shutter Speed NTSC: 1/30~1/100000s |
|---|
| Smart IR | Auto / Manual |
|---|
| Minimum Illumination | 0.005Lux/F1.8, 30IRE, 0Lux IR on |
|---|
| S/N Ratio | More than 65dB Certifications |
|---|
| IR Distance | Up to 60m (197feet) CE (EN55032, EN55024, EN50130-4) |
|---|
| Certifications | FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
|---|
| IR On/Off Control | Auto / Manual UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|---|
| IR LEDs | 4 |
|---|
| 鏡頭 | Audio Interface N/A |
|---|
| 鏡頭類型 | Motorized lens / Fixed iris Eelectrical |
|---|
| Mount Type | Board-in |
|---|
| 供電 | POC/12V DC ±30% |
|---|
| 焦距 | 2.7-12mm |
|---|
| 功耗 | Max 12.1W (12V DC, IR on) |
|---|
| Max Aperture | F1.8 Environmental |
|---|
| Angle of View | H: 101.7°~32.3° -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH Operating Conditions * Start up should be done at above -30°C (-22°F) |
|---|
| Focus Control | Motorized |
|---|
| 儲存環境 | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH 200mm Close Focus Distance 7.87'' Ingress Protection & Vandal IP67 Resistance DORI Distance Construction Note: The DORI distance is a “general proximity” of distance which makes it easy to |
|---|
| Casing | Aluminium pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. |
|---|
| 尺寸 | 209.9mm×90.4mm×90.4mm (8.26"×3.56"×3.56") |
|---|
| Distance | Net Weight 0.55kg (1.21lb) |
|---|
| Definition | Wide Tele Gross Weight 0.70kg (1.54lb) 25px/m |
|---|
| Detect | 47m(153ft) 137m(448ft) (8px/ft) 63px/m |
|---|
| Observe | 19m(61ft) 55m(179ft) (19px/ft) 125px/m |
|---|
| Recognize | 9m(31ft) 27m(90ft) (38px/ft) 250px/m |
|---|
| Identify | 5m(15ft) 14m(45ft) (76px/ft) Pan / Tilt / Rotation Pan: 0° ~ 360° |
|---|
| Pan/Tilt/Rotation | Tilt: 0° ~ 87° Rotation: 0° ~ 360° |
|---|
| 解像度 | 1080P (1920×1080) |
|---|
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P 1-channel BNC high definition video output / CVBS Video Output video output (Can switch) |
|---|
| Day/Night | Auto (ICR) / Manual www.dahuasecurity.com |
|---|
| Ordering Information | Juncon Mount Pole Mount |
|---|
| PFA130-E | PFA130-E + PFA152-E |
|---|
| 類型 | Part Number Description |
|---|
| DH-HAC-HFW1230RP-Z-IRE6- | 2MP Starlight HDCVI POC IR Bullet |
|---|
| POC | Camera, PAL 2MP Camera |
|---|
| DH-HAC-HFW1230RN-Z-IRE6- | 2MP Starlight HDCVI POC IR Bullet |
|---|
| PFM320 | 12V 2A Power Adapter |
|---|
| PFM320D-015 | 12V 1.5A Power Adapter |
|---|
| PFM300 | 12V 2A Power Adapter Accessories Optional: Dimensions (mm/inch) |
|---|
| PFA152-E | PFM300 PFA130-E |
|---|
| Pole mount | 12V 2A Power Adapter Junction box |
|---|
| Rev 001.001 | © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
