| Camera | OSD Menu Multi-language |
|---|
| 影像感測器 | 1/2.9" CMOS BLC Mode BLC / HLC / DWDR |
|---|
| Effective Pixels | 1920(H)×1080(V), 2MP WDR DWDR |
|---|
| Scanning System | Progressive Gain Control AGC |
|---|
| PAL: 1/25~1/100000s | Noise Reduction 2D Electronic Shutter Speed NTSC: 1/30~1/100000s |
|---|
| White Balance | Auto / Manual |
|---|
| Minimum Illumination | 0.02Lux/F2.0 (Color), 0.002Lux/F2.0 (B/W) |
|---|
| Smart IR | N/A |
|---|
| S/N Ratio | More than 65dB |
|---|
| IR Distance | N/A Certifications |
|---|
| IR On/Off Control | N/A CE (EN55032, EN55024, EN50130-4) Certifications FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
|---|
| IR LEDs | N/A |
|---|
| Audio Interface | N/A |
|---|
| 鏡頭類型 | Fixed lens / Fixed iris Eelectrical |
|---|
| Mount Type | Board-in |
|---|
| 供電 | 12V DC ±25% |
|---|
| 焦距 | 2.8mm (3.6mm Optional) |
|---|
| 功耗 | Max 0.6W (12V DC, IR on) |
|---|
| Max Aperture | F2.0 Environmental |
|---|
| Angle of View | H: 109.4° (92°) -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH Operating Conditions * Start up should be done at above -40°C (-40°F) |
|---|
| Focus Control | N/A |
|---|
| 儲存環境 | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH 500mm (800mm) Close Focus Distance 19.69'' (31.50'') Ingress Protection &Vandal IP67 Resistance |
|---|
| DORI Distance | Construction |
|---|
| Casing | Aluminium Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the Dimensions Φ30mm×68.2mm (Φ1.18"×2.69") criteria for Detect, Observe, Recognize and Identify respectively. |
|---|
| 淨重 | 0.07kg (0.15lb) |
|---|
| DORI 偵測距離 | Gross Weight 0.11kg (0.24lb) Distance Definition 25px/m 2.8mm: 40m(131ft) Detect (8px/ft) 3.6mm: 51m(169ft) 63px/m 2.8mm: 16m(52ft) Observe (19px/ft) 3.6mm: 21m(68ft) 125px/m 2.8mm: 8m(28ft) Recognize (38px/ft) 3.6mm: 10m(34ft) 250ppm 2.8mm: 4m(13ft) Identify (76px/ft) 3.6mm: 5m(17ft) Pan / Tilt / Rotation |
|---|
| Pan/Tilt/Rotation | N/A |
|---|
| 解像度 | 1080P (1920×1080) |
|---|
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P 1-channel BNC high definition video output / CVBS Video Output video output (Can switch) www.dahuasecurity.com Ordering Information |
|---|
| 類型 | Part Number Description Wall Mount DH-HAC-HUM1220GP 2.8mm 2MP HDCVI Bullet Camera, PAL DH-HAC-HUM1220GP 3.6mm 2MP Camera DH-HAC-HUM1220GN 2.8mm 2MP HDCVI Bullet Camera, NTSC DH-HAC-HUM1220GN 3.6mm |
|---|
| PFM820 | UTC Controller |
|---|
| PFM800-E | Passive HDCVI Balun |
|---|
| PFM800-4K | Passive Video Balun |
|---|
| Accessories | PFM800B-4K Passive Video Balun |
|---|
| PFM321 | 12V 1A Power Adapter |
|---|
| PFM320D-015 | 12V 1.5A Power Adapter |
|---|
| PFM300 | 12V 2A Power Adapter Accessories Optional: Dimensions (mm) |
|---|
| UTC Controller | Passive HDCVI Balun Passive Video Balun 61.5[2.42"] 30.0[1.18"] 30.0[1.18"] 35.7[1.4"] |
|---|
| PFM800B-4K | PFM321 PFM320D-015 |
|---|
| Passive Video Balun | 12V 1A Power Adapter 12V 1.5A Power Adapter PFM300 12V 2A Power Adapter |
|---|
| Rev 001.001 | © 2017 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
