Dahua DH-IPC-HDW1230S-S5 為DH-IPC-HDW1230S-S5，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DH-IPC-HDW1230S-S5 香港價格連安裝報價。
| Camera | Day/Night Auto (ICR)/Color/B/W |
|---|---|
| 影像感測器 | 1/2.8" CMOS |
| BLC | Yes |
| 最大解像度 | 1920 (H) × 1080 (V) |
| HLC | Yes |
| ROM | 16 MB |
| WDR | DWDR |
| RAM | 64 MB Auto; natural; street lamp; outdoor; manual; regional White Balance custom |
| Scanning System | Progressive |
| Gain Control | Manual; auto |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Noise Reduction | 3D NR 0.01 lux@F2.0 (Color,30 IRE) |
| 最低照度 | 0.001 lux@F2.0 (B/W,30 IRE) 0 lux (Illuminator on) Motion Detection OFF/ON (4 areas, rectangular) |
| S/N Ratio | > 56 dB Region of Interest (RoI) Yes (4 areas) |
| Illumination Distance | 30 m (98.4 ft) (IR) Smart Illumination Yes |
| Illuminator On/Off Control | Auto; manual 0°/90°/180°/270° (Support 90°/270° with 1080p Image Rotation resolution and lower) |
| Illuminator Number | 12 (IR LED) |
| Mirror | Yes Pan: 0°–355° |
| Pan/Tilt/Rotation Range | Tilt: 0°–78° Privacy Masking 4 areas Rotation: 0°–360° Alarm Network disconnection; IP conflict; illegal access; motion |
| 鏡頭類型 | Fixed-focal Alarm Event detection; video tampering; security exception |
| 鏡頭接口 | M12 Network |
| 焦距 | 2.8 mm; 3.6 mm Network Port RJ-45 (10/100 Base-T) 2.8 mm: F2.0 SDK and API Yes Max. Aperture 3.6 mm: F2.0 Video encryption; Configuration encryption; Digest; 2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120° |
| Field of View | WSSE; Account lockout; Security logs; Generation and 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100° Cyber Security importing of X.509 certification; Trusted boot; Trusted |
| Iris Control | Fixed upgrade IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; 2.8 mm: 0.5 m (1.6 ft) Network Protocol |
| Close Focus Distance | FTP; DHCP; DNS; DDNS; NTP; Multicast 3.6 mm: 0.8 m (2.6 ft) |
| Interoperability | ONVIF(Profile S); CGI; P2P |
| 鏡頭 | Detect Observe Recognize Identify |
| 用戶管理 | 6 (Total bandwidth: 36 M) |
| DORI 偵測距離 | 38.6 m 15.4 m 7.7 m 3.9 m 2.8 mm |
| Distance | (126.6 ft) (50.5 ft) (25.3 ft) (12.8 ft) |
| Storage | FTP 49.7 m 19.9 m 9.9 m 5.0 m 3.6 mm Browser IE; Chrome; Firefox (163.1 ft) (65.3 ft) (32.5 ft) (16.4 ft) |
| Video | Management Software Smart PSS; DSS; DMSS H.265; H.264; H.264B; MJPEG (Only supported by the Mobile Client iOS; Android Video Compression sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ Certification |
| 主碼流 | CE-LVD: EN 62368-1 1920 × 1080@1–25/30 fps CE-EMC: Electromagnetic Compatibility Directive Certifications |
| 子碼流 | 2014/30/EU 704 × 576@1–25 fps FCC: 47 CFR FCC Part 15, Subpart B Video Frame Rate 704 × 480@1–30 fps *The values above are the max. frame rates of each Power stream; for multiple streams, the values will be subjected |
| to the total encoding capacity. | Power Supply 12 VDC/PoE (802.3af) |
| Stream Capability | 2 streams Basic: 1.4 W (12 VDC); 2.2 W (PoE) |
| 功耗 | Max. (ICR + H.265+IR intensity): 3.3 W (12 VDC); 4.3 W 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 (PoE) |
| 解像度 | × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Environment |
| 碼率控制 | CBR/VBR Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F) www.dahuasecurity.com |
| 工作濕度 | ≤ 95% |
| 儲存溫度 | –40 °C to +60 °C (–40 °F to +140 °F) |
| 防護等級 | IP67 Structure Inner core: Metal Cover: Plastic Casing Decoration ring: Plastic Pedestal: plastic |
| Product Dimensions | 84.9 mm × Φ108 mm (3.3" × Φ4.3") |
| 淨重 | 0.22 kg (0.5 lb) |
| 毛重 | 0.34 kg (0.7 lb) |
| Ordering Information | Dimensions (mm[inch]) |
| 類型 | Model Description |
| DH-IPC- | 2 MP Entry IR Fixed-Focal Eyeball Netwok 2 MP Camera |
| HFW1230S1-S5 | Camera |
| PFA136 | Junction Box |
| PFB203W | Pole Mount Bracket |
| PFA152-E | Pole Mount Bracket Accessories |
| PFA106 | Mount Adapter (optional) |
| PFB220C | Ceiling Mount Bracket |
| PFM321D | 12 VDC 1A Power Adapter |
| PFM900-E | Integrated Mount Tester Accessories Optional: |
| Junction Box | Pole Mount Bracket Pole Mount Bracket |
| Mount Adapter | Ceiling Mount Bracket 12 VDC 1A Power Adapter PFM900-E Integrated Mount Tester |
| Rev 001.001 | © 2021 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →DH-IPC-HDW1230S-S5 Dahua DH-IPC-HDW1230S-S5亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，DH-IPC-HDW1230S-S5 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：DORI 偵測距離方面，DH-IPC-HDW1230S-S5 係 38.6 m 15.4 m 7.7 m 3.9 m 2.8 mm，IPC-HFW1230S1-S5 係 2.8 mm。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HFW1230S1-S5 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 DH-IPC-HDW1230S-S5 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
