| Camera | People Counting displaying and outputting monthly/daily reports. Support 4 tripwire rules configuration, people |
|---|
| 影像感測器 | 1/1.8” 4Megapixel progressive CMOS counting in 4 areas, and 4 queue management functions |
|---|
| 最大解像度 | 2688 (H) × 1520 (V) Work together with Smart NVR to perform refine |
|---|
| ROM | 16 GB Intelligent Search intelligent search, event extraction and merging to event videos. |
|---|
| RAM | 2 GB |
|---|
| Scanning System | Progressive H.265, H.264, H.264H, H.264B, MJPEG(only supported Video Compression by sub stream) |
|---|
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
|---|
| Smart Codec | Smart H.265+/ Smart H.264+ |
|---|
| 最低照度 | 0.001 Lux@F1.2 Main Stream: 2688 × 1520 (1–50/60 fps) Sub stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) |
|---|
| S/N Ratio | > 56 dB Video Frame Rate Third stream: 1920 × 1080 (1–25/30 fps) Fourth stream: 1920 × 1080 (1–25/30 fps) |
|---|
| Illumination Distance | 60m (196.85 ft) Fifth stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) |
|---|
| Auto/Manual | Stream Capability 5 streams 4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 × |
|---|
| Illuminator Number | 4 (IR LED) 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 Resolution × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 |
|---|
| Pan: 0°–360° | × 240) |
|---|
| Pan/Tilt/Rotation Range | Tilt: 0°–90° |
|---|
| Rotation: 0°–360° | Bit Rate Control CBR/VBR |
|---|
| 鏡頭 | Video Bit Rate H.264: 32–10240 kbps H.265: 12–10240 kbps |
|---|
| 鏡頭類型 | Motorized vari-focal |
|---|
| Day/Night | Auto (ICR)/Color/B/W |
|---|
| Mount Type | Module interface |
|---|
| 焦距 | 2.7mm–12 mm BLC Yes |
|---|
| Max. Aperture | F1.2 HLC Yes Horizontal: 114°(W)–47°(T) |
|---|
| Field of View | Vertical: 59°(W)–27°(T) WDR 140 dB Diagonal: 141° (W–55°(T) |
|---|
| 光圈類型 | Auto;Precise iris control Scene Self-adaptation Yes |
|---|
| W: 1 m (3.28ft) | Auto/aatural/street lamp/outdoor/manual/regional |
|---|
| Close Focus Distance | White Balance |
|---|
| T: 2.5 m (8.20ft) | custom |
|---|
| DORI 偵測距離 | 60.1 m 24 m 12 m 6m Noise Reduction 3D NR |
|---|
| Distance | (187.19 ft) (78.74 ft) (39.37 ft) (19.69 ft) |
|---|
| Motion Detection | OFF/ON (4 areas, rectangular) 128.6 m 51.4 m 25.7 m 12.8 m (421.92 ft) (168.64 ft) (84.32 ft) (41.99 ft) |
|---|
| Region of Interest(RoI) | Yes (4 areas) |
|---|
| 智能事件 | Electronic Image Yes Stabilization(EIS) |
|---|
| IVS | Abandoned object, moving object |
|---|
| Smart Illumination | Yes |
|---|
| 除霧 | Yes Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection 0°/90°/180°/270° (Supports 90°/270° with 1080p |
|---|
| IVS (Perimeter Protection) | Image Rotation of vehicle and human); parking detection, loitering resolution or below.) detection, and people gathering. |
|---|
| Mirror | Yes Face recognition, track, priority, snapshot, face |
|---|
| Privacy Masking | 4 areas enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard Audio Compression G.711a; G.711Mu; G726; AAC; G.723 Face matting setting: face, single inch photo |
|---|
| Face Recognition | Two snapshot strategies: priority snapshot, recognition Alarm Face angle filter Priority time setting Management of 5 group face libraries Single person register and person No SD card; SD card full; SD card error; network register in batch Face recognition and similarity setting disconnection; IP conflict; illegal access; motion Max supports face contrast in face library with detection; video tamp |
|---|
| Video Metadata | and non-motor vehicle image capture and attributes alarm; people counting; people counting exception extraction. detection; safety exception, Queue Management www.dahuasecurity.com |
|---|
| Network | Ordering Information |
|---|
| SDK and API | Yes DH-IPC- 4MP IR Bullet WizMind Network Camera,PAL HFW7442HP-ZFR HTTP; Https; 802.1x; TCP; ARP; RTSP; RTP; UDP; RTCP; |
|---|
| Protocol | SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; IPC-HFW7442HP- QoS; UPnP; NTP; SFTP; RTMP; Genetec;Bonjour ; 4MP IR Bullet WizMind Network Camera,PAL ZFR Multicast 4MP Camera ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; DH-IPC- |
|---|
| Interoperability | 4MP IR Bullet WizMind Network Camera,NTSC |
|---|
| Genetec; P2P;RTMP | HFW7442HN-ZFR |
|---|
| 用戶管理 | 20(Total bandwidth: 80M) IPC-HFW7442HN- 4MP IR Bullet WizMind Network Camera,NTSC ZFR |
|---|
| Storage | FTP; Micro SD card (256 G); NAS; SFTP;Dahua Cloud Accessories (optional) PFA154 Pole Mount IE: IE9 and later |
|---|
| Browser | Chrome: Chrome 42 and later Firefox: Firefox 48.0.2 and later Accessories |
|---|
| Management Software | Smart PSS; DSS; DMSS |
|---|
| Mobile Phone | IOS, Android Optional: CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive |
|---|
| Certifications | 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 PFA154 Port |
|---|
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) Pole Mount Wall-Mount Junction Mount DH-PFA154 Audio Input Audio Interface: 1/1 channel In/Out Audio Output |
|---|
| 警報輸入 | 3 channel In: 5mA 5V DC |
|---|
| 警報輸出 | 2 channel Out: 1000mA 30V DC/500mA 50V AC Power |
|---|
| 供電 | 12V DC/24V AC/PoE+ (802.3at) |
|---|
| 功耗 | <17.3W Dimensions (mm/inch) |
|---|
| Operating Conditions | -40°C to +60°C (-40°F to +140°F)/Less than 95% RH |
|---|
| 儲存環境 | -40°C to +60°C (-40°F to +140°F) |
|---|
| Protection Grade | IP67, IK10 Structure |
|---|
| Casing | Metal + Plastic 340.1 mm × 108.5 mm × 92.9 mm (13.39" × 4.27" × Dimensions 3.66") (L × W × H) |
|---|
| 淨重 | 1600g (3.53 lb) |
|---|
| 毛重 | 2400g (5.29 lb) |
|---|
| Rev 001.001 | © 2020 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
|---|
