| Thermal Camera | Ethernet RJ-45 |
|---|
| 影像感測器 | Uncooled VOx Microbolometer IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, 400(H)x300(V) DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, Effective Pixels 802.1x |
|---|
| Pixel Size | 17um Interoperability ONVIF Profile S & G, API |
|---|
| Thermal Sensitivity(NETD) | 40mK Streaming Method Unicast/Multicast |
|---|
| Spectral Range | 8~14um Max. User Access 10 Users/20 Users |
|---|
| Image Setting | Brightness/Sharpness/ROI/AGC/FFC/3D DNR Micro SD (256GB) Memory status display (Normal / Error / Active / 18(Whitehot/Blackhot/Ironrow/Icefire/ Edge Storage Formatting / Lock), |
|---|
| Color Palettes | Fusion/Rainbow/Globow/Iconbow1/ NAS (Network Attached Storage), Local PC for |
|---|
| Iconbow2 .etc) | instant recording |
|---|
| Web Viewer | >IE8, |
|---|
| Management Software | SmartPSS, DSS |
|---|
| 鏡頭類型 | Fixed/F1.0 |
|---|
| Smart Phone | Android, iOS |
|---|
| Focus Control | Athermalized, Focus-free |
|---|
| 焦距 | 7.5mm 13mm 25mm 35mm Certifications |
|---|
| H: 53.7° | H: 30.2° H: 15.5° H: 11.1° |
|---|
| Angle of View | V: 39.7° V: 22.6° V: 11.6° V: 8.3° |
|---|
| Certification | CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB ) |
|---|
| Effective Distance① | D②: 221m D: 382m D: 735m D: 1030m Interface |
|---|
| R③: 57m | R: 98m R: 189m R: 265m |
|---|
| Man(1.8m*0.5m) | I ④: 28m I: 49m I: 95m I: 132m |
|---|
| Video Interface | 1 Port (CVBS/BNC) |
|---|
| D: 490m | D: 850m D: 1634m D: 2288m Audio Interface 1/1 In/Out |
|---|
| Effective Distance | R: 126m R: 219m R: 420m R: 588m |
|---|
| Vehicle(4m*1.4m) | I:63m I: 109m I: 210m I: 294m |
|---|
| RS485 | Support |
|---|
| Video | Alarm 2/2 In/Out |
|---|
| Compression | H.265 / H.264 / MJPEG Electrical |
|---|
| 供電 | DC 12V/PoE/ePoE Main Stream: Thermal: 1280x1024 / 720P / 400x300 @25/30fps Power Consumption Max. 13W Frame Rate |
|---|
| 子碼流 | Environmental Thermal: 640x512 / 400x300 @25/30fps -40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH |
|---|
| 碼率控制 | CBR/VBR Operating Condition * Start up should be done at above -40°C (-40°F) |
|---|
| Bit Rate | H.264: 640 ~ 8192Kbps |
|---|
| 儲存環境 | -40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH |
|---|
| Motion Detection | Off/On (4 zone, Rectangle) |
|---|
| Region of Interest | Off/On (4 zone) Ingress Protection IP67 Electronic Image Stabilization (EIS) Construction |
|---|
| Digital Zoom | 4x(19 levels) |
|---|
| Casing | Metal |
|---|
| Flip | 180° |
|---|
| 尺寸 | 291mm× 103mm× 97mm (11.46" x 4.06" x 3.82") |
|---|
| Mirror | Off/On |
|---|
| 淨重 | 1.5Kg (3.31 lb) |
|---|
| Privacy Masking | Off/On (4 area, Rectangle) |
|---|
| 毛重 | 1.9Kg (4.19 lb) |
|---|
| Audio | Note: ①Effective distance values shown are nominal values and should be used as estimates |
|---|
| Intelligence | ③R: Recognition Distance ④I: Identification Distance |
|---|
| IVS | Tripwire, Intrusion Fire detection & alarm, Cold/Hot spot trace, Advanced Intelligent Functions Human/Vehicle classification www.dahuasecurity.com |
|---|
| Ordering Information | Mounting Type |
|---|
| 類型 | Part Number Description :ƵŶĐƟŽŶDŽƵŶƚ WŽůĞDŽƵŶƚ DH-TPC-BF5401P-B7 PFA121 |
|---|
| PFA121 | PFA121+PFA152-E PFA121 + PFA152 Thermal:400x300 7.5mm lens DH-TPC-BF5401N-B7 DH-TPC-BF5401P-B13 Thermal:400x300 13mm lens DH-TPC-BF5401N-B13 DH-TPC- BF5401 DH-TPC-BF5401P-B25 Thermal:400x300 25mm lens DH-TPC-BF5401N-B25 DH-TPC-BF5401P-B35 Thermal:400x300 35mm lens DH-TPC-BF5401N-B35 Accessories Optional： Dimensions(mm) 291.0[11.46"] 103.8[4.09"] 192.5[7.58"] PFA121 PFA152-E 97.2[3.83"] Junction bo |
|---|
