| Camera | Smart IR Yes |
|---|
| 影像感測器 | 1/2.7 inch CMOS Mirror Off/On |
|---|
| Effective Pixels | 3840 (H)× 2160 (V), 4K Privacy Masking Off/On (8 area, rectangle) |
|---|
| Scanning System | Progressive Certifications |
|---|
| PAL: 1/25s–1/100000s | CE (EN55032, EN55024, EN50130-4,EN60950-1) Electronic Shutter Speed |
|---|
| NTSC: 1/30s–1/100000s | Certifications FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|---|
| S/N Ratio | >65dB Port |
|---|
| Minimum Illumination | 0.03Lux/F2.0, 30IRE, 0Lux IR on Video output choices of CVI/TVI/AHD/CVBS by one Video Output |
|---|
| Fill Light Working Distance | 30 m (98.4 ft) BNC port |
|---|
| IR On/Off Control | Auto; manual Audio Input None |
|---|
| IR LED Number | 1 Power |
|---|
| Pan: 0°–360° | Power Supply 12V ±30% DC |
|---|
| Pan/Tilt/Rotation Range | Tilt: 0°–90° |
|---|
| Rotation: 0°–360° | Power Consumption Max 4.3W (12V DC, IR on) |
|---|
| 鏡頭 | Environment |
|---|
| 鏡頭類型 | Fixed-focal -40°C to +60°C (-40°F to 140°F);<95% (non- Operating Temperature condensation) |
|---|
| Mount Type | M12 -40°C to +60°C (-40°F to 140°F);<95% (non- Storage Temperature condensation) |
|---|
| 焦距 | 2.8mm; 3.6mm;6mm |
|---|
| Protection Grade | IP67 |
|---|
| Max. Aperture | F2.0 2.8mm: 125° x 105° x 56° (diagonal x horizontal x Structure vertical) 3.6mm: 104° x 87° x 47° (diagonal x horizontal x Casing Metal throughout the whole casing Angle of View vertical) 6mm:62.4° x54.7° x31.3°(diagonal x horizontal x Camera Dimensions 174.5mm×70.6mm×72.3mm (6.87”×2.78”×2.85”) vertical) |
|---|
| 淨重 | 0.35Kg (0.77lb) |
|---|
| 光圈類型 | Fixed iris |
|---|
| 毛重 | 0.45Kg (0.99lb) 2.8mm: 1.0 m (3.3 ft) |
|---|
| Close Focus Distance | 3.6mm: 1.9 m (6.2 ft) 6mm:3.6m(11.8ft) |
|---|
| DORI 偵測距離 | (245.1 ft) (98.1 ft) (48.9ft) (24.6 ft) |
|---|
| Distance | 106.7 m 42.7 m 21.3 m 10.7 m 3.6mm (350.1 ft) (140.1 ft) (69.9 ft) (35.1 ft) 160m 64 m 32 m 16 m 6mm (524.9 ft) (210.0ft) (105.0ft) (52.5ft) CVI: 4K@25/30fps; 4K@15fps; 5M@20fps; 4M@25fps/30fps; |
|---|
| Frame Rate | AHD: 4K@15fps; TVI: 4K@15fps; CVBS: 960H 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); Resolution 960H (960 × 576/960 × 480) |
|---|
| Day/Night | Auto switch by ICR |
|---|
| BLC | BLC/HLC/WDR |
|---|
| WDR | DWDR |
|---|
| White Balance | Auto; manual |
|---|
| Gain Control | Auto; manual www.dahuasecurity.com Ordering Information |
|---|
| 類型 | Part Number Description |
|---|
| DH-HAC-HFW1800TP | PFM320D-015 2.8mm DC12V1.5A Power Adapter DH-HAC-HFW1800TP 3.6mm |
|---|
| Junction Mount | Junction Mount Pole Mount |
|---|
| PFA134 | Water-proof Junction Box Water-proof Junction Box+Pole Mount |
|---|
| PFB134+PFA152-E | Bracket |
|---|
| PFM800-4K | Passive Video Balun |
|---|
| Accessories | PFM800B-4K Passive Video Balun |
|---|
| PFM320D Series | 12V 2A Power Adapter |
|---|
| PFM321D Series | 12V 1A Power Adapter |
|---|
| PFM320D-015 | DC12V1.5A Power Adapter Accessories Optional: |
|---|
| Water-proof Junction Box | Water-proof Junction Passive Video Balun Box+Pole Mount Bracket |
|---|
| PFM800B-4K | 12V 2A Power Adapter 12V 1A Power Adapter Passive Video Balun |
|---|
| Rev 001.001 | © 2019 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
|---|
