| System | Holiday Period 128 |
|---|
| Main Processor | Embedded Processor First-card Unlock Support |
|---|
| 網絡協議 | IPv4, RTSP, RTP, TCP, UDP, P2P Remote Verification Support |
|---|
| OSDP Protocol | Support Peripheral Card Reader 1 RS-485 and 1 Wiegand |
|---|
| Interoperability | CGI Multi-card Unlock Support |
|---|
| SDK | Support Real-time Surveillance Support |
|---|
| Basic | Web Configuration Support |
|---|
| Display | 10.1 inch TFT screen Card Reading Distance 1 cm–4 cm |
|---|
| Screen Type | Capacitive touch screen Face-camera distance: 0.3 m–2.0 m Human Face Recognition Range height:0.9 m–2.4 m |
|---|
| Screen Resolution | 1280x800 |
|---|
| Face Verification Accuracy | ≥99.5% |
|---|
| Camera | 2MP CMOS |
|---|
| Face Recognition Speed | 0.2s |
|---|
| WDR | 120dB |
|---|
| Fingerprint Sensor Type | Capacitance Auto whitelight fill light |
|---|
| Light Compensation | Fingerprint Verification Mode 1:N Auto IR fill light 1 indicator lights. Red: Recognition failed; Green: Fingerprint Comparison Time ≤1.5S Status Indicator Light Recognition succeeded; Blue: Standby mode |
|---|
| Voice Prompt | Support |
|---|
| User Amount | 100, 000 |
|---|
| Housing Material | PC+ABS; Aluminum alloy frame |
|---|
| Face Amount | 100, 000 |
|---|
| Fingerprint Amount | 10, 000 Card/Password/Fingerprint/Face unlock |
|---|
| Unlock Mode | Card, password, fingerprint, and face combination Card Amount 100, 000 unlock |
|---|
| Password Amount | 100, 000 |
|---|
| Card Reader Type | IC card www.dahuasecurity.com |
|---|
| Storage Record Amount | 100, 000 Dimensions (mm[inch]) Port |
|---|
| RS-485 | 1 |
|---|
| RS-232 | 1 |
|---|
| Wiegand | 1 (26, 34, 66) |
|---|
| USB | 1 USB2.0 port |
|---|
| Network | 1 100M Ethernet port |
|---|
| 警報輸入 | 2 |
|---|
| 警報輸出 | 2 |
|---|
| Alarm Linkage | Support |
|---|
| Unlock Button | 1 |
|---|
| Door Status Detection | 1 Application |
|---|
| Door Lock Control | 1 Alarm |
|---|
| Anti-passback | Support Switch |
|---|
| 防拆 | Support Management Client Platform |
|---|
| Duress | Support |
|---|
| Door Sensor Timeout | Support |
|---|
| Illegal Intrusion | Support Illegal Card Exceeding Support Threshold Alarm |
|---|
| Duress Fingerprint | Support |
|---|
| 供電 | DC 12V 2A IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is Ingress Protection recommended. For details, see the quick start guide.) |
|---|
| 功耗 | ≤24W |
|---|
| 尺寸 | 396.9mm×185.6mm×77.2mm |
|---|
| 工作溫度 | -30°C to +50°C |
|---|
| 工作濕度 | 5%RH–95%RH |
|---|
| Working Environment | Indoor and outdoor |
|---|
| 毛重 | 4.32 kg |
|---|
| 安裝 | Wall mount |
|---|
| Certifications | CE/FCC |
|---|
| Rev 001.001 | © 2019 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
|---|
