| System | HDCVI Camera Input 4/8/16 Channel |
|---|
| Main Processor | Embedded Processor IP Camera Input 4+2/8+4/16+8 Channel, each channel up to 5MP |
|---|
| 操作系統 | Embedded LINUX Audio In/Out 4/8/16 Channel input,1 Channel output, RCA |
|---|
| Display | Two-way Talk Reuse audio in(channel 1)/out, RCA Recording |
|---|
| 接口 | 1 HDMI ,1 VGA |
|---|
| Compression | H.264+/H.264 |
|---|
| 解像度 | 1920×1080, 1280×1024, 1280×720, 1024×768 |
|---|
| Multi-screen Display | 8CH: 1/4/8/9/16 Main stream: 1080P(1~15fps) 16CH: 1/4/8/9/16/25 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF Record Rate (1~25/30fps) Camera title, Time, Video loss, Camera lock, Motion Sub steram:D1/CIF/QCIF(1~15fps) OSD detection, Recording |
|---|
| Bit Rate | 1Kbps ~ 6144Kbps Per Channel Video Detection and Alarm Recording, PTZ, Tour, Alarm Out, Video Push, Email, Manual, Schedule (Regular, Continuous), MD |
|---|
| Trigger Events | Record Mode (Video detection: Motion Detection, Video Loss, FTP, Snapshot, Buzzer and Screen Tips Tampering), Alarm, Stop Motion Detection, MD Zones: 396 (22 × 18), Video |
|---|
| Video Detection | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Loss, Tampering and Diagnosis Record Interval Post-record: 10 ~ 300 sec |
|---|
| 警報輸入 | 4/8/16 |
|---|
| Relay Output | 3 4/8CH: 1 RJ-45 Port (100M) |
|---|
| Playback and Backup | 16CH: 1 RJ-45 Port (1000M) 4CH: 1/4 HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, |
|---|
| Playback | 8CH: 1/4/9 NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Network Function 16CH: 1/4/9/16 Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) Time /Date, Alarm, MD and Exact Search (accurate |
|---|
| Search Mode | Max. User Access 128 users to second) |
|---|
| Smart Phone | iPhone, iPad, Android Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Interoperability ONVIF 2.42, CGI Conformant Playback Function Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom Electrical |
|---|
| Backup Mode | USB Device/Network Power Supply DC12V/2A |
|---|
| 功耗 | <15W (Without HDD) Storage Environmental |
|---|
| Internal HDD | 1 SATA Port, up to 8TB capacity |
|---|
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
|---|
| eSATA | N/A |
|---|
| 儲存環境 | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH Construction 4/8CH:2 USB Ports (2 USB 2.0) USB 16CH:2 USB Ports (1 USB 2.0 , 1 USB 3.0) |
|---|
| 尺寸 | Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") |
|---|
| RS232 | N/A |
|---|
| 淨重 | 1.5kg (3.3 lb) (without HDD) |
|---|
| RS485 | 1 Port, for PTZ Control |
|---|
| 毛重 | 2kg (4.4lb) |
|---|
| Third-party Support | Installation Desktop installation Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Certifications Third-party Support Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, |
|---|
| and more | FCC: Part 15 Subpart B ICES 003 Issue 6 CE: EN 55032: 2012+AC:2013 (Class B) |
|---|
| Certifications | EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 www.dahuasecurity.com |
|---|
| Ordering Information | Rear Panel |
|---|
| 類型 | Part Number Description DHI-HCVR5104HE-S3 |
|---|
| DHI- | 4 Channel Tribrid 1080P-Lite |
|---|
| HCVR5104HE-S3 | Mini 1U Digital Video Recorder 4/8/16 |
|---|
| HCVR5108HE-S3 | Mini 1U Digital Video Recorder HCVR |
|---|
| HCVR5116HE-S3 | Digital Video Recorder DHI-HCVR5116HE-S3 Dimensions (mm) |
|---|
| Rev 001.001 | © 2016 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
