| System | HDCVI Camera Input 4/8 Channel 4+1 Channel: each channel up to 2MP |
|---|
| Main Processor | Embedded Processor IP Camera Input 8+2 Channel:each channel up to 5MP |
|---|
| 操作系統 | Embedded LINUX Audio In/Out 1/1, RCA |
|---|
| Display | Two-way Talk Reuse audio in/out, RCA |
|---|
| 接口 | 1 HDMI ,1 VGA Recording |
|---|
| 解像度 | 1920×1080, 1280×1024, 1280×720, 1024×768 Compression H.264 4CH: 1/4/6 Resolution 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF Multi-screen Display 8CH: 1/4/8/9/16 Main stream: 4CH:1080N/720P/960H/D1/HD1/ BCIF/CIF/QCIF (1~25/30fps) Camera title, Time, Video loss, Camera lock, Motion |
|---|
| OSD | 8CH:1080N(12fps)/720P(15fps)/960H/D1/HD1/ |
|---|
| detection, Recording | Record Rate BCIF/CIF/QCIF (1~25/30fps) Sub steram:4CH:CIF/QCIF(1~15fps) |
|---|
| Video Detection and Alarm | 8CH:CIF/QCIF(1~7fps) Recording, PTZ, Tour, Video Push, Email, FTP, |
|---|
| Trigger Events | Bit Rate 1Kbps ~ 6144Kbps Per Channel Snapshot, Buzzer and Screen Tips Motion Detection, MD Zones: 396 (22 × 18), Video Manual, Schedule (Regular, Continuous), MD |
|---|
| Video Detection | Record Mode (Video detection: Motion Detection, Video Loss, Loss and Ta Tampering), Alarm, Stop |
|---|
| 警報輸入 | N/A 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Record Interval Post-record: 10 ~ 300 sec |
|---|
| Relay Output | N/A Playback and Backup |
|---|
| Playback | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, 8CH:1/4/9 NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Network Function Server, P2P, IP Search (Support Dahua IP camera, Time /Date, Alarm, MD and Exact Search (accurate DVR, NVS, etc.) Search Mode to second) |
|---|
| Max. User Access | 128 users Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, |
|---|
| Playback Function | Smart Phone iPhone, iPad, Android Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|---|
| Interoperability | ONVIF 2.42, CGI Conformant |
|---|
| Backup Mode | USB Device/Network Electrical |
|---|
| Storage | Power Supply DC12V/2A |
|---|
| Internal HDD | 1 SATA Port, up to 8TB capacity Power Consumption <10W (Without HDD) |
|---|
| eSATA | N/A Environmental |
|---|
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
|---|
| 儲存環境 | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
|---|
| USB | 2 USB Ports (2 USB 2.0) Construction |
|---|
| RS232 | N/A |
|---|
| 尺寸 | Smart 1U, 205mm×211mm×45mm (8.1“×8.3”×1.8“) |
|---|
| RS485 | N/A |
|---|
| 淨重 | 0.55kg (1.2lb) (without HDD) Third-party Support |
|---|
| 毛重 | 1kg (2.2lb) Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, |
|---|
| Third-party Support | Installation Desktop installation Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more Certifications FCC: Part 15 Subpart B ICES 003 Issue 6 CE: EN 55032: 2012+AC:2013 (Class B) |
|---|
| Certifications | EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 UL:IEC 61000-4-3：2006+A1：2007+A2：2010 www.dahuasecurity.com |
|---|
| Ordering Information | Rear Panel |
|---|
| 類型 | Part Number Description DHI-XVR4104C 4 Channel Penta-brid 720P Smart 1U DHI-XVR4104C 4/8 Channel Digital Video Recorder XVR 8 Channel Penta-brid 720P Smart 1U DHI-XVR4108C Digital Video Recorder DHI-XVR4108C Dimensions (mm) |
|---|
| Rev 001.001 | © 2016 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
