| Loop Out | People Counting |
|---|
| HDCVI/TVI/AHD/CVBS Full Compatibility | Smart Search time through drawing a region when playback. It is very useful when an |
|---|
| Smart tracking | emergency occurs. |
|---|
| between Bullet and PTZ Camera. | Fisheye Dewarp The function of fisheye dewarping can be realized including HDCVI & IP fisheye camera. This series supports 4MP HDCVI fisheye camera access, including preview, recording and dewarping. www.dahuasecurity.com |
|---|
| Technical Specification | Audio and Video |
|---|
| HDCVI Camera Input | 8/16 Channel |
|---|
| Main Processor | Embedded Processor IP Camera Input up to 64 Channel, each channel up to 12MP |
|---|
| 操作系統 | Embedded LINUX Audio In/Out 8/16 Channel input, 1 Channel output, BNC |
|---|
| Two-way Talk | 1 MIC IN, 1 MIC OUT, BNC(independent) Recording |
|---|
| 接口 | 2 HDMI(HDMI1 up to 4K), 1 VGA, 1 TV |
|---|
| Compression | H.264+/H.264 3840×2160, 2560×1440, 1920×1080, 1280×1024, 4K, 4MP, 1080P, 720P, 960H, D1, HD1, BCIF, CIF, |
|---|
| 解像度 | Resolution 1280×720, 1024×768 QCIF Main stream: 1st and 9th channel |
|---|
| Multi-screen Display | 1/4/8/9/16/25/36 4K(1~12/15fps)/4MP (1~25/30fps), others 4MP(1~15fps); Record Rate |
|---|
| Privacy Masking | 4 rectangular zones (each camera) 1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) Sub steram:960H/D1/CIF/QCIF(1~25/30fps) Camera title, Time, Video loss, Camera lock, Motion OSD detection, Recording |
|---|
| Bit Rate | 1Kbps ~ 12288Kbps Per Channel Video Detection and Alarm Manual, Schedule (Regular, Continuous), MD Recording, PTZ, Tour, Alarm Out, Video Push, Email, |
|---|
| Trigger Events | Record Mode (Video detection: Motion Detection, Video Loss, FTP, Snapshot, Buzzer and Screen Tips Tampering), Alarm, Stop Motion Detection, MD Zones: 396 (22 × 18), Video Video Detection |
|---|
| Loss, Tampering and Diagnosis | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 Record Interval sec, Post-record: 10 ~ 300 sec |
|---|
| 警報輸入 | 8/16 |
|---|
| Relay Output | 6 channel |
|---|
| Playback and Backup | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Network Function Server, P2P, IP Search (Support Dahua IP camera, |
|---|
| Playback | 1/4/9/16 DVR, NVS, etc.) |
|---|
| Max. User Access | 128 users Time /Date, Alarm, MD and Exact Search (accurate Search Mode to second) |
|---|
| Smart Phone | iPhone, iPad, Android Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Interoperability ONVIF 2.42, CGI Conformant Playback Function Full Screen, Repeat, Shuffle, Backup Selection, |
|---|
| Digital Zoom | Electrical |
|---|
| Backup Mode | USB Device/Network Power Supply AC 100~240V, 50/60HZ |
|---|
| Storage | Power Consumption <40W (Without HDD) |
|---|
| Internal HDD | 8 SATA Ports, up to 8 TB capacity for each disk Environmental |
|---|
| eSATA | 1 Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
|---|
| Auxiliary Interface | Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
|---|
| USB | 4 USB Ports (2USB 2.0 , 2 USB 3.0) Construction |
|---|
| RS232 | 1 Port，for PC communication & Keyboard Dimensions 2U, 440mm×455mm×95mm (17.3"×17.9"×3.7") |
|---|
| RS422 | 1 Port，for PTZ Control Net Weight 8.24 kg (without HDD) |
|---|
| RS485 | 1 Port, for PTZ Control Gross Weight 9.48 kg (without HDD) |
|---|
| 安裝 | Desktop installation/Rack installation |
|---|
| LOOP | HDCVI/CVBS 8/16 BNC Certifications FCC: 47 CFR PART 15 SUBPART B, 2015 Certifications CE: EN 60950-1:2006+A11:2009+A1:2010+A12: 2011+A2:2013 UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 www.dahuasecurity.com |
|---|
| Ordering Information | Rear Panel |
|---|
| 類型 | Part Number Description DHI-XVR8808S 8 Channel Penta-brid 4MP 2U Digital Video DHI-XVR8808S Recorder 8/16 Channel XVR 16 Channel Penta-brid 4MP 2U Digital Video DHI-XVR8816S Recorder DHI-XVR8816S Dimensions (mm) |
|---|
| Rev 001.001 | © 2016 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
