| Basic | Long Distance PoE Yes Transmission |
|---|
| 交換容量 | 16 Gbps STP/RSTP Spanning Tree Protocol |
|---|
| 包轉發率 | 11.90 Mpps VLAN Function Port-based VLAN Port 1-4: 4 × RJ-45 10/100/1000 Mbps (PoE) IEEE 802.3x Flow Control Yes |
|---|
| Description of Function Slots | Port 5-6: 2 × RJ-45 10/100/1000 Mbps (uplink) |
|---|
| Port 7-8: 2 × SFP 1000 Mbps (uplink) | DHCP Client DHCP Function |
|---|
| PoE Power | Port 1 ≤ 60 W, Port 2-4 ≤ 30 W, total ≤ 60 W |
|---|
| Equipment Management | Web management |
|---|
| Layer | Layer 2 |
|---|
| QoS/ACL | Qos |
|---|
| Management Type | Yes Web (http and https) Equipment Management SNMP V1/V2C/V3 |
|---|
| 工作溫度 | –30 °C to +65 °C (-22 °F to +149 °F) |
|---|
| 工作濕度 | 5%–95% (RH), non-condensing |
|---|
| 功耗 | Idling: ≤4 W ; Full load: 65 W Gross Weight 1.37 kg (3.02 lb) 311.5 mm × 251.5 mm × 128.5 mm (12.26" × 9.90" × |
|---|
| 供電 | External power supply: 53 VDC, 1.22 A Packaging Dimensions 5.06") (L × W × H) |
|---|
| Statics Protection | Air discharge: 8 kV; Contact discharge: 6 kV Casing Material Sheet metal |
|---|
| Lighting Protection | Common mode: 4 kV; Differential mode: 2 kV Installation Desktop mount; DIN-Rail mount |
|---|
| 淨重 | 0.66 kg (1.45 lb) Transmission Performance: 162 mm × 123.6 mm × 42 mm (6.38" × 4.87" × 1.65") Switch power supply voltage 53V. |
|---|
| Product Dimensions | (L × W × H) CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m |
|---|
| Hardware | Cable(m) Load Capacity(W) Bandwidth(Mbps) |
|---|
| Included Power Adapter | Yes Hi-PoE 60 W |
|---|
| PoE | Yes 100 53 1000 |
|---|
| Ethernet Port | 4 150 50 10 |
|---|
| Ethernet Port Speed | 10/100/1000 Mbps 200 47 10 |
|---|
| Ethernet Port Uplink Speed | 10/100/1000 Mbps 250 37 10 |
|---|
| Optical Port Uplink Speed | 1 Gbps IEEE802.3at 30 W |
|---|
| Debugging | 1 × Console port 100 25.5 1000 |
|---|
| Reset Button | 1 150 25.5 10 |
|---|
| 儲存溫度 | –40 °C to +70 °C (–40 °F to +158 °F) 200 25.5 10 |
|---|
| Storage Humidity | 5%–95% (RH), non-condensing 250 25.5 10 |
|---|
| Performance | Note: Data from this table was collected by Dahua test lab and is for reference only . The actual transmission distance may vary due to power consumption of connected |
|---|
| Packet Buffer Size | 4 Mbit devices or the cable type and status. |
|---|
| Jumbo Frame | 15K Byte Ordering Information |
|---|
| MAC Table Size | 8K |
|---|
| GSFP-1310T-20-SMF | 1.25G 1310/1550nm, 20km, LC, Single-mode |
|---|
| VLAN Number | 32 |
|---|
| GSFP-1310R-20-SMF | 1.25G 1550/1310nm, 20km, LC, Single-mode |
|---|
| Communication Standard | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab SFP module |
|---|
| GSFP-1310-20-SMF | 1.25G 1310nm,20km,LC, Single-mode Feature |
|---|
| GSFP-850-MMF | 1.25G 850nm,550m,LC, Multi-mode |
|---|
| PoE Protocol | IEEE802.3af; IEEE802.3at; Hi-PoE PoE Power Consumption Yes Management www.dahuasecurity.com |
|---|
| 安裝 | Panels Dimensions (mm[inch]) mm [inch] 42.0 [1.65] 162.0 [6.38] 132.4 [5.21] 122.0 [4.80] |
|---|
| Rev 002.000 | © 2023 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com |
|---|
