| Camera | Main stream: 1920 × 1080@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 |
|---|
| 影像感測器 | 1/2.8" CMOS fps) Video Frame Rate *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected |
|---|
| 最大解像度 | 1920 (H) × 1080 (V) to the total encoding capacity. |
|---|
| ROM | 128 MB Stream Capability 2 streams |
|---|
| RAM | 128 MB 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 |
|---|
| 解像度 | × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF |
|---|
| Scanning System | Progressive (352 × 288/352 × 240) |
|---|
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s Bit Rate Control CBR/VBR 0.002 Lux@F1.6 (Color, 30IRE) H.264: 32 kbps–6144 kbps; Video Bit Rate |
|---|
| 最低照度 | 0.0002Lux@F1.6 (B/W, 30IRE) H.265: 12 kbps–6144 kbps 0 lux (Illuminator on) |
|---|
| Day/Night | Auto(ICR)/Color/B/W |
|---|
| S/N Ratio | >56 dB |
|---|
| BLC | Yes up to 30 m (98.43 ft) (IR); up to 30 m (98.43 ft) (Warm |
|---|
| light) | HLC Yes |
|---|
| Illuminator On/Off Control | Auto; Manual WDR 120 dB |
|---|
| Illuminator Number | 1 (IR LED); 1 (Warm light) Auto; natural; street lamp; outdoor; manual; regional White Balance custom Pan: 0°–360° |
|---|
| Pan/Tilt/Rotation Range | Tilt: 0°–78° Gain Control Auto;Manual Rotation: 0°–360° |
|---|
| 鏡頭 | Noise Reduction 3D NR |
|---|
| 鏡頭類型 | Fixed-focal Motion Detection OFF/ON (4 areas, rectangular) |
|---|
| 鏡頭接口 | M12 Region of Interest (RoI) Yes (4 areas) 0°/90°/180°/270° (Support 90°/270° with 1080p |
|---|
| 焦距 | 2.8 mm; 3.6 mm Image Rotation resolution and lower) |
|---|
| Max. Aperture | F1.6 Mirror Yes 2.8 mm: H: 107°; V: 56°; D: 127° |
|---|
| Field of View | Privacy Masking 4 areas 3.6 mm: H: 88°; V: 44°; D: 105° |
|---|
| Iris Control | Fixed 2.8 mm: 0.7 m (2.30 ft) |
|---|
| Close Focus Distance | Built-in MIC Yes 3.6 mm: 1.3 m (4.27 ft) |
|---|
| DORI 偵測距離 | (193.24 ft) (77.43 ft) (38.71 ft) (19.36 ft) detection; video tampering; tripwire; intrusion; voltage |
|---|
| Distance | detection; security exception; SMD *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in Network this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/ Network P |
|---|
| SDK and API | Yes |
|---|
| Intelligence | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; Intrusion, tripwire (the two functions support the Network Protocol SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; |
|---|
| IVS (Perimeter Protection) | classification and accurate detection of vehicle and ICMP; IGMP; P2P human) |
|---|
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI Work together with Smart NVR to perform refine |
|---|
| Smart Search | intelligent search, event extraction and merging to event User/Host 6 (Total bandwidth: 36 M) videos |
|---|
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB) H.264H; H.265; H.264; H.264B; MJPEG (Only supported Browser Chrome |
|---|
| by the sub stream) | Firefox |
|---|
| Management Software | DSS;DMSS www.dahuasecurity.com |
|---|
| Mobile Client | iOS;Android Accessories Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout; syslog; Video Optional: |
|---|
| Cyber Security | encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive PFA130-E PFB205W-E PFA152-E |
|---|
| Certifications | 2014/30/EU; Junction Wall Mount Pole Mount |
|---|
| FCC: 47 CFR FCC Part 15, Subpart B; | Box Bracket Bracket UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
|---|
| 供電 | 12 VDC/PoE (802.3af) Basic: 1.6 W (12 VDC); 1.9 W (PoE) |
|---|
| 功耗 | Max. (H.265 + intelligence on + WDR + warm light): 3.8 W (12 VDC); 4.4 W (PoE) |
|---|
| PFA109 | PFB220C PFM321D |
|---|
| Mount | Ceiling Mount 12V DC 1A |
|---|
| Environment | Adapter Bracket Power Adapter |
|---|
| 工作溫度 | –40 °C to +60 °C (–40 °F to +140 °F) |
|---|
| 工作濕度 | ≤95% |
|---|
| 儲存溫度 | –40 °C to +60 °C (–40 °F to +140 °F) |
|---|
| 防護等級 | IP67 |
|---|
| PFM900-E | TF-P100 |
|---|
| Structure | Integrated MicroSD |
|---|
| Mount Tester | Memory Card Inner core: Metal; |
|---|
| Casing Material | Cover: Metal; Decoration ring: Plastic |
|---|
| Product Dimensions | 99.1 mm × Φ121.9 mm (3.90" × Φ4.80") |
|---|
| 淨重 | 0.46 kg (1.01 lb) |
|---|
| 毛重 | 0.65 kg (1.43 lb) |
|---|
| 類型 | Model Description 2MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera |
|---|
| PFA130-E | Junction Box |
|---|
| PFB205W-E | Wall Mount Bracket |
|---|
| PFA152-E | Pole Mount Bracket |
|---|
| PFM321D | 12 VDC 1A Power Adapter |
|---|
| TF-P100 | MicroSD Memory Card www.dahuasecurity.com Dimensions (mm[inch]) |
|---|
| Rev 002.000 | © 2024 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com |
|---|
