| Illuminator Number | 6 × white light (adjustable brightness) |
|---|
| Image Sensor | 1/1.8'' CMOS |
|---|
| Image Resolution | 2688 (H) × 1520 (V) |
|---|
| Video Resolution | Main stream: 4M (2688 × 1520); UXGA (1600 x 1200); 1080p (1920 × 1080); 720p (1280 × 720); Sub stream: 720p (1280 × 720); D1 (704 × 576, 704 × 480); CIF (352 × 288, 352 × 240) |
|---|
| Bit Rate | H.264M: 32 kbps–32768 kbps; H.264H: 32 kbps–32768 kbps; H.265: 32 kbps–32768 kbps; MJPEG: 512 kbps–65536 kbps |
|---|
| Video Compression | H.264M; H.264H; H.265; MJPEG |
|---|
| Picture Encoding Format | JPEG |
|---|
| Noise Reduction | 3D NR |
|---|
| White Balance | Auto; Natural; Street lamp; Outdoor; Manual; Regional custom |
|---|
| Electronic Shutter Speed | 1/25–1/10000, auto or manual |
|---|
| WDR | 96 db |
|---|
| Iris Control | Auto iris (W: 1.4–T: 2.15) |
|---|
| Shutter | Single shutter |
|---|
| Storage | 1 × built-in TF card slot, supports Kingston/Dahua/SanDisk 16/32/64/128 GB |
|---|
| Field of View | H: 114.6° (W)–48.3° (T); V: 59.0° (W)–27.1° (T); D: 141.6° (W)–55.5° (T) |
|---|
| Illumination Distance | 12 m (39.37 ft) |
|---|
| Min. Illumination | 0.002 lx (built-in illuminator on) |
|---|
| Vehicle Detection | Vehicle capture rate ≥95% |
|---|
| Vehicle Recognition | Supports licensed and unlicensed vehicle recognition |
|---|
| Number of Available Spaces | Max. 50 spaces |
|---|
| Counting Mode | Area monitoring, parking space monitoring, and plate recognition mode |
|---|
| Network | 1 × RJ-45 Ethernet port, 100/1000 M network transmission |
|---|
| RS-485 | 2 |
|---|
| RS-232 | 1 |
|---|
| Alarm Input | 3, optocoupler input (on-off input) |
|---|
| Alarm Output | 3 (1 for relay, and 2 for optocoupler), used to link the barrier |
|---|
| Power Supply | 12 VDC, 24 VAC, POE+ |
|---|
| Power Consumption | <20 W |
|---|
| Operating Temperature | −30 °C to +65 °C (−22 °F to +149 °F) |
|---|
| Operating Humidity | 10% (RH)–90% (RH) (no condensation) |
|---|
| Casing | Metal + plastic |
|---|
| Protection Grade | IP67 |
|---|
| Dimensions | 296.5 mm × 124.3 mm × 107.7 mm (11.67" × 4.89" × 4.24") (L × W × H) |
|---|
| Net Weight | 1.7 kg (3.75 lb) |
|---|
| Installation | Universal mounting bracket |
|---|
| Lens | Included, 4.38 mm–9.33 mm |
|---|
