| Hardware | Gross Weight 0.63 kg (1.39 lb) |
|---|
| Included Power Adapter | Yes Product Dimensions 190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18") |
|---|
| PoE | Yes Packaging Dimensions 265 mm × 238 mm × 76 mm (10.43" × 9.37" × 2.99") |
|---|
| Ethernet Port | 8 |
|---|
| Certifications | CE; FCC |
|---|
| Ethernet Port Speed | 10/100 Mbps |
|---|
| Ethernet Port Uplink Speed | 10/100/1000 Mbps Description of Function Slots |
|---|
| Port 1–8: 8 × RJ–45 10/100 Mbps | Transmission Performance: Uplink1–2: 2 × RJ–45 10/100/1000 Mbps Switch power supply voltage 53V. |
|---|
| 供電 | 53 VDC, 1.81 A CAT5E/CAT6. Max. DC resistance < 10Ω/100m |
|---|
| Cable(m) | Load Capacity(W) Bandwidth(Mbps) |
|---|
| 工作溫度 | –10 °C to +55 °C (+14 °F to +131 °F) |
|---|
| 工作濕度 | 5%–95% (RH), non-condensing IEEE802.3bt 90W 100 71.3 100 |
|---|
| 儲存溫度 | –40 °C to +70 °C (–40 °F to +158 °F) 150 62 10 |
|---|
| Storage Humidity | 5%–95% (RH), non-condensing |
|---|
| Idling: 5 W | 200 51 10 |
|---|
| 功耗 | Full load: 96 W 250 40 10 Performance Hi-PoE 60W |
|---|
| Smart Managed Switch | Yes 100 53 100 |
|---|
| MTBF | 864,663 h 150 50 10 |
|---|
| 交換容量 | 7.2Gbps 200 47 10 |
|---|
| 包轉發率 | 4.17 Mpps 250 37 10 |
|---|
| Packet Buffer Size | 4 Mbit |
|---|
| Jumbo Frame | 1,664 Bytes IEEE802.3at 30W 100 25.5 100 |
|---|
| MAC Table Size | 16K 150 25.5 10 |
|---|
| Communication Standard | IEEE 802.3; IEEE 802.3u; IEEE 802.3X; IEEE 802.3ab 200 25.5 10 Feature 250 25.5 10 |
|---|
| PoE Protocol | IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt |
|---|
| Port 1 ≤90 W; | Note: Data from this table was collected by Dahua test lab and is for reference only. |
|---|
| PoE Power | Port2–8 ≤30 W; The actual transmission distance may vary due to power consumption of connected |
|---|
| Total ≤96 W | devices or the cable type and status. PoE Power Consumption Yes Management |
|---|
| PoE Pin Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V–) Long Distance PoE Yes Transmission |
|---|
| DHCP Function | DHCP Client Operation and maintenance management on mobile |
|---|
| Equipment Management | app; ConfigTool configuration and management Air discharge: 8 kV Statics Protection Contact discharge: 6 kV Common mode: 4 kV Lighting Protection Differential mode: 2 kV www.dahuasecurity.com Cloud Managed Switch | DH-S4100-8ET2GT-96-C REVISIONS |
|---|
| REV | ZONE MARK DESCRIPTION DATE CHANGED Dimensions (mm[inch]) 30.0 [1.18] mm[inch] 190.0 [7.48] 105.7 [4.16] 100.3 [3.95] Panels |
|---|
| .X | 0.2 TITLE: PFS3010-12-桌面式百兆8口轻网管交换机 |
|---|
| .XX | 0.15 F |
|---|
| .XXX | 0.05 ANG 0.5 DRAW: DATE: UNIT'S:mm DWG NO.: |
|---|
| THESE DRAWINGS AND SPECIFICATION ARE THE | CHKD: DATE: SCALE:1:2 PROPERTY OF ZHEJIANG DAHUA TECHNOLOGY Co., LTD. AND SHALL NOT BE REPRODUCED COPYIED OR PART NO.: |
|---|
| USED IN ANY MANNER WITHOUT THE PRIOR | STAD: DATE: WRITTEN CONSENT OF ZHEJIANG DAHUA |
|---|
| TECHNOLOGY Co. LTD | APPD: DATE: SHEET:1 OF 1 |
|---|
| Rev 002.000 | © 2023 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com |
|---|
