| PoE Protocol | IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt Port 1-2≤90W; |
|---|
| PoE Power | Port 3-24≤30W; Total ≤360 W www.dahuasecurity.com PoE Power Consumption |
|---|
| Yes | Ordering Information Management |
|---|
| 類型 | Model Description |
|---|
| PoE Pin Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V–) |
|---|
| GSFP-1310T-20-SMF | 1.25G 1310/1550nm,20km,LC, Single-mode Long Distance PoE Yes Transmission |
|---|
| GSFP-1310R-20-SMF | 1.25G 1550/1310nm,20km,LC, Single-mode |
|---|
| General | SFP module |
|---|
| GSFP-1310-20-SMF | 1.25G 1310nm,20km,LC, Single-mode Air discharge: 8 kV |
|---|
| Statics Protection | 1.25G 850nm,550m,LC, Multi-mode |
|---|
| Contact discharge: 6 kV | GSFP-850-MMF Common mode: 4 kV Lighting Protection Differential mode: 2 kV |
|---|
| 淨重 | 3.50 kg (7.72 lb) Installation |
|---|
| 毛重 | 4.60 kg (10.14 lb) 440 mm × 300 mm × 44 mm Product Dimensions (17.32" × 11.81" × 1.73") (L × W × H) 528 mm × 412 mm × 112 mm Packaging Dimensions (20.79" × 16.22" × 4.41") (L × W × H) |
|---|
| Certifications | CE; FCC Transmission Performance: Switch power supply voltage 53V. CAT5E/CAT6. Max. DC resistance < 10Ω/100m |
|---|
| Cable(m) | Load Capacity(W) Bandwidth(Mbps) IEEE802.3bt 90W 100 71.3 100 150 62 10 200 51 10 250 40 10 Dimensions (mm[inch]) Hi-PoE 60W 100 53 100 150 50 10 200 47 10 250 37 10 IEEE802.3at 30W 100 25.5 100 150 25.5 10 200 25.5 10 250 25.5 10 Note: Data from this table was collected by Dahua test lab and is for reference only. The actual transmission distance may vary due to power consumption of connected dev |
|---|
| Rev 002.000 | © 2023 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com |
|---|
