DAHUA XVR5104H-X CCTV攝影機安裝・保養

Name: DAHUA XVR5104H-X DH-XVR5104H-X
Brand: dahua
SKU: XVR5104H-X

產品簡介

dahua XVR5104H-X 為DH-XVR5104H-X，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 XVR5104H-X 香港價格連安裝報價。

System：Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP,
Main Processor：Embedded Processor Motion Detection, MD Zones: 396 (22 × 18)
操作系統：Embedded LINUX
警報輸入：N/A
Relay Output：N/A

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

System	Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Main Processor	Embedded Processor Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Video Detection Tampering and Diagnosis
操作系統	Embedded LINUX
警報輸入	N/A
Relay Output	N/A
Analog Camera Input	4 Channel, BNC Playback and Backup
HDCVI Camera	5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
Playback	1/4
AHD Camera	5MP, 4MP, 1080P@25/30, 720P@25/30fps Time /Date, Alarm, MD and Exact Search (accurate to Search Mode
TVI Camera	5MP, 4MP, 1080P@25/30, 720P@25/30fps second)
CVBS Camera	PAL/NTSC Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File,
Playback Function	Previous File, Next Camera, Previous Camera, Full Screen,
IP Camera Input	4+2 Channel, each channel up to 6MP Repeat, Shuffle, Backup Selection, Digital Zoom
Audio In/Out	1/1, RCA Backup Mode USB Device/Network
Two-way Talk	Reuse audio in/out, RCA Storage
Recording	Internal HDD 1 SATA Port, up to 10TB capacity
Compression	H.265+/H.265/H.264+/H.264 eSATA N/A
解像度	5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF Main stream:the 1st channel 5M-N(1~10fps), other channels 4M-N/1080P(1~15fps); 1080N/720P/960H/
USB	2 USB 2.0 Record Rate
D1/CIF (1~25/30fps)	RS232 N/A Sub stream: D1/CIF(1~15fps)
RS485	1 Port, for PTZ Control
Bit Rate	32Kbps ~ 6144Kbps Per Channel Electrical Manual, Schedule (General, Continuous), MD (Video detection:
Record Mode	Power Supply DC12V/2A Motion Detection, Video Loss, Tampering), Alarm, Stop 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post- Power Consumption
Record Interval	<10W
record: 10 ~ 300 sec	(Without HDD)
音訊壓縮	AAC(only for the 1st channel), G.711A, G.711U, PCM Construction
Audio Sample Rate	8KHz, 16 bit Per Channel Dimensions Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2")
音訊碼率	64Kbps Per Channel Device with PFH101 483mmx281mmx56mm (19.0"x11.1"x2.2") Rack Mount Tray Net Weight 1.0kg (2.2lb)
接口	1 HDMI ,1 VGA (without HDD)
安裝	Desktop installation When IP extension mode not enabled: 1/4 Multi-screen Display When IP extension mode enabled: 1/4/6 Environmental Camera title, Time, Video loss, Camera lock, Motion detection,
OSD	Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 10%~ 90% RH Recording
儲存環境	-20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH Third-party Support
Third-party Support	Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP,
Network Function	Sanyo, Sony, Videotec, Vivotek, and more Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.) Certifications
Max. User Access	128 users FCC: Part 15 Subpart B
Smart Phone	iPhone, iPad, Android CE: CE-LVD: EN 60950-1/IEC 60950-1
Interoperability	ONVIF 16.12, CGI Conformant Certifications CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1 www.dahuasecurity.com
Ordering Information	Rear Panel
類型	Part Number Description 4 Channel Penta-brid 1080P Mini 1U DH-XVR5104H-X 4 Channel XVR DH-XVR5104H-X Digital Video Recorder 1 2 9 10
Accessory, optional	DH-PFH101 Rack Mount Tray 3 4 5 6 7 8 Dimensions (mm) 1 VIDEO IN 6 RS485 Interface 255.1mm 2 AUDIO IN, RCA Connector 7 USB Interface 325mm 243mm 3 AUDIO OUT, RCA Connector 8 DC 12V Power Input 55mm 4 HDMI Interface 9 VGA Interface 5 Network Interface 10 Power Switch Installation on Rack Mount Tray Standard Cabinet 1U Device Rack Mount Tray
Rev 001.001	© 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com
