| HA | 1 3 5 7 9 11 13 15 17 19 21 23 X1 X3 X5 — ULL — X7 Interfaces FortiGate 600F 1. 2 x USB Ports |
|---|
| USB | USB CONSOLE 2. 1 x Console Port |
|---|
| MGMT | 2 4 6 8 10 12 14 16 18 20 22 24 X2 X4 X6 — ULL — X8 3. 2 x GE RJ45 MGMT/HA Ports 1 2 3 4 5 6 7 4. 16 x GE RJ45 Slots 5. 8 x GE SFP Slots SSD2 |
|---|
| SSD1 | PWR2 PWR1 6. 4 x 10GE/GE SFP+/SFP |
|---|
| FAN1 | FAN2 FAN3 FAN4 FAN5 Slots 7. 4x 25GE/10GE SFP28/ SFP+ Ultra Low Latency Slots |
|---|
| NP7 | CP9 TPM 1RU 25GE DUAL AC 480GB Trusted Platform Module (TPM) The FortiGate 600F series features a dedicated module that hardens physical networking appliances by generating, storing, and authenticating cryptographic keys. Hardware-based security mechanisms protect against malicious software and phishing attacks. Dual power supply Power supply redundancy is essential in the operation of mission-cri |
|---|
| FortiGate 600F Series | Data Sheet |
|---|
| FG-600F | FG-601F FG-600F FG-601F |
|---|
| Interfaces and Modules | Dimensions and Power |
|---|
| Hardware Accelerated GE RJ45 | 16 Height x Width x Length (inches) 1.75 x 17.0 x 15.0 Interfaces |
|---|
| Height x Width x Length (mm) | 44.45 x 432 x 380 |
|---|
| Hardware Accelerated GE SFP Slots | 8 |
|---|
| 重量 | 15.6 lbs (7.1 kg) 16.2 lbs (7.35 kg) |
|---|
| Hardware Accelerated 10GE SFP+ / | 4 |
|---|
| GE SFP Slots | Form Factor Rack Mount, 1 RU (supports EIA/non-EIA standards) |
|---|
| Hardware Accelerated 25GE SFP28/ | 4 10GE SFP+ Ultra Low Latency Slots AC Power Consumption 169 W / 255 W 174 W / 260 W (Average / Maximum) |
|---|
| GE RJ45 MGMT/HA Ports | 2 |
|---|
| AC Power Input | 100–240V AC, 50/60Hz |
|---|
| USB Ports | 2 |
|---|
| AC Current (Maximum) | 6A@100V |
|---|
| RJ45 Console Port | 1 |
|---|
| Heat Dissipation | 871 BTU/h 888 BTU/h |
|---|
| Onboard Storage | 0 2x 240 GB SSD |
|---|
| Redundant Power Supplies | Yes |
|---|
| Trusted Platform Module (TPM) | (Hot Swappable) (comes with 2PSU default) |
|---|
| Bluetooth Low Energy (BLE) | Power Supply Efficiency Rating 80Plus Compliant |
|---|
| Signed Firmware Hardware Switch | — Operating Environment and Certifications |
|---|
| Included Transceivers | 2x SFP (SX 1 GE) Operating Temperature 32°F to 104°F (0°C to 40°C) System Performance — Enterprise Traffic Mix Storage Temperature -31°F to 158°F (-35°C to 70°C) |
|---|
| IPS Throughput 2 | 14 Gbps Humidity 5% to 90% non-condensing |
|---|
| NGFW Throughput 2, 4 | 11.5 Gbps Noise Level 55 dBA |
|---|
| Threat Protection Throughput 2, 5 | 10.5 Gbps Airflow Side and Front to Back |
|---|
| System Performance and Capacity | Operating Altitude Up to 10 000 ft (3048 m) |
|---|
| IPv4 Firewall Throughput | 139 / 137.5 / 70 Gbps Compliance FCC Part 15 Class A, RCM, VCCI, CE, (1518 / 512 / 64 byte, UDP) UL/cUL, CB |
|---|
| IPv6 Firewall Throughput | 139 / 137.5 / 70 Gbps Certifications USGv6/IPv6 (1518 / 512 / 64 byte, UDP) |
|---|
| Firewall Latency (64 byte, UDP) | 4.12 μs / 2.5 μs* * Latency based on Ultra Low Latency (ULL ports) |
|---|
| Firewall Throughput (Packet per Second) | 105 Mpps ** FortiOS 7.6.1+ is required for supporting up to 128 FSW. |
|---|
| Concurrent Sessions (TCP) | 8 Million All prior releases support up to 96. |
|---|
| New Sessions/Second (TCP) | 550 000 |
|---|
| Firewall Policies | 30 000 |
|---|
| IPsec VPN Throughput (512 byte) 1 | 55 Gbps |
|---|
| Gateway-to-Gateway IPsec VPN Tunnels | 2000 |
|---|
| Client-to-Gateway IPsec VPN Tunnels | 50 000 |
|---|
| SSL-VPN Throughput | 4.3 Gbps |
|---|
| Concurrent SSL-VPN Users | 10 000 (Recommended Maximum, Tunnel Mode) |
|---|
| SSL Inspection Throughput | 9 Gbps (IPS, avg. HTTPS) 3 |
|---|
| SSL Inspection CPS (IPS, avg. HTTPS) 3 | 7500 |
|---|
| SSL Inspection Concurrent Session | 840 000 (IPS, avg. HTTPS) 3 |
|---|
| Application Control Throughput | 32 Gbps (HTTP 64K) 2 |
|---|
| CAPWAP Throughput (HTTP 64K) | 64.5 Gbps |
|---|
| Virtual Domains (Default / Maximum) | 10 / 50 |
|---|
| Maximum Number of FortiSwitches | 128** Supported |
|---|
| Maximum Number of FortiAPs | 1024 / 512 (Total / Tunnel) |
|---|
| Maximum Number of FortiTokens | 5000 |
|---|
| High Availability Configurations | Active-Active, Active-Passive, Clustering IPsec VPN performance test uses AES256-SHA256. 4 NGFW performance is measured with Firewall, IPS and Application Control enabled. IPS (Enterprise Mix), Application Control, NGFW and Threat Protection are measured 5 Threat Protection performance is measured with Firewall, IPS, Application Control and |
|---|
| with Logging enabled. | Malware Protection enabled. SSL Inspection performance values use an average of HTTPS sessions of different cipher suites. |
|---|
| Service | Enterprise Unified Threat Advanced Threat |
|---|
| Category | Service Offering A-la-carte Protection Protection Protection SD-WAN |
|---|
| FortiGuard | IPS — IPS, Malicious/Botnet URLs • • • • |
|---|
| Services | Anti-Malware Protection (AMP)—AV, Botnet Domains, Mobile • • • • Malware, Virus Outbreak Protection, Content Disarm and Reconstruct1, AI‑based Heurestic AV, FortiGate Cloud Sandbox URL, DNS and Video Filtering — URL, DNS and Video1 Filtering, • • • Malicious Certificate |
|---|
| Anti-Spam | • • |
|---|
| AI-based Inline Malware Prevention | • • |
|---|
| Data Loss Prevention (DLP) 2 | • • Attack Surface Security — IoT Device Detection, IoT • • Vulnerability Correlation and Virtual Patching, Security Rating, Outbreak Check OT Security—OT Device Detection, OT Vulnerability Correlation • and Virtual Patching, OT Application Control and IPS 2 |
|---|
| Application Control | --------------included with FortiCare Subscription-------------- Inline CASB 1 --------------included with FortiCare Subscription-------------- |
|---|
| SD-WAN | SD-WAN SLA Database • |
|---|
| SD-WAN Overlay Orchestration Service | • SD-WAN Connector for FortiSASE Secure Private Access • |
|---|
| FortiSASE Starter Kit for n* Users | 3 FortiGate Cloud One Year Cloud-based Log Retention • |
|---|
| FortiTelemetry Cloud | • |
|---|
| NOC and | FortiConverter Service for One Time Configuration Conversion • • Managed FortiGate Service—Available 24x7, with Fortinet NOC • Experts Performing Device Setup, Network, And Policy Change Management FortiGate Cloud—Management, Analysis, and One Year Log • Retention |
|---|
| FortiManager Cloud | • |
|---|
| FortiAnalyzer Cloud | • FortiGuard SOCaaS—24x7 Cloud-Based Managed Log • Monitoring, Incident Triage, and SOC Escalation Service |
|---|
| Hardware | FortiCare Essentials Desktop |
|---|
| and Software | models only |
|---|
| FortiCare Premium | • • • • • |
|---|
| FortiCare Elite | • |
|---|
| Base | Device/OS Detection, GeoIPs, Trusted CA Certificates, Internet |
|---|
| Product | SKU Description 4x 25G SFP28 slots, 4x 10GE SFP+ slots, 18x GE RJ45 ports (including 1x MGMT port, 1x HA port, |
|---|
| FortiGate 600F | FG-600F 16x switch ports), 8x GE SFP slots, SPU NP7 and CP9 hardware accelerated, dual AC power supplies. 4x 25G SFP28 slots, 4x 10GE SFP+ slots, 18x GE RJ45 ports (including 1x MGMT port, 1x HA port, |
|---|
| FortiGate 601F | FG-601F 16x switch ports), 8x GE SFP slots, SPU NP7 and CP9 hardware accelerated, 480GB onboard SSD storage, dual AC power supplies. |
|---|
| AC Power Supply | SP-FG400F-PS AC power supply for FG-400/401F, FG-600/601F, power cable SP-FGPCOR-XX sold separately. (connects to FN-TRAN-SFP+BD33, ordered separately). (connects to FN-TRAN-SFP+BD27, ordered separately). www.fortinet.com |
|---|
