HANWHA PRN-6400B4 CCTV攝影機安裝・保養

Name: HANWHA PRN-6400B4 PRN-6400B4
Brand: hanwha
SKU: PRN-6400B4

產品簡介

hanwha PRN-6400B4 為PRN-6400B4，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 PRN-6400B4 香港價格連安裝報價。

Inputs：Max. 64CH
Network camera：Resolution 32MP ~ CIF
網絡協議：Wisenet, ONVIF [Dual Display]
Local Display：HDMI 1: 3840 x 2160 (30Hz) HDMI 2: 1920x1080 (60Hz) [Local M
Multi Screen Display：- Clone Mode : Up to 64 Division - Expand Mode : HDMI1 up to

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

Inputs	Max. 64CH
Network camera	Resolution 32MP ~ CIF
網絡協議	Wisenet, ONVIF [Dual Display]
Local Display	HDMI 1: 3840 x 2160 (30Hz) HDMI 2: 1920x1080 (60Hz) [Local Monitor] - Dynamic layout, Virtual channel view
Multi Screen Display	- Clone Mode : Up to 64 Division - Expand Mode : HDMI1 up to 36 Div. HDMI2 up to 16 Div. [Web] 1/ 2H/ 2V/ 3V/ 4/ 6/ 8/ 9 32M(15fps, H.265 Only), 12M(30fps, H.265 Only), Resolution 8.3M(120fps), 1080p(480fps), 720P(960fps), D1(1920fps) Performance
操作系統	Embedded Linux
Compression	H.265, H.264, MJPEG, WiseStream(H.265, H.264) Distributed mode : Up to 400 Mbps Normal mode : Up to 150 Mbps
Recording Bandwidth	{RAID mode} Normal : Up to 400 Mbps Degrade/ Rebuild : Up to 320 Mbps
解像度	32MP ~ CIF Record Normal, Dual Stream, Schedule(Continuous/Event), Event Mode (Pre/Post), Bookmark Alarm Input, Video Loss, Camera Event(Sensor, MD, Video Event Trigger Analytics, Defocus, Audio), Dynamic Event, User Event e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer,
Event Action	Monitor Out, FTP, SUNAPI Command, Shotdown
Playback Bandwidth	Max. 64Mbps(64CH simultaneously)
User	Max. 4 Users (Local 1, Remote 3)
Simultaneous playback	Max. 112CH(Local 64CH, Remote 16CH per user)
Fisheye Dewarping	Support (Local 1CH), CMS Search & Play Date & Time(Calendar), Event list, Text Search, Smart Mode Search
Playback Control	Fast/Slow Forward / Backward, Move one step Up / Down
Supported HDD	Up to 10TB
HDD Slot	SATA 16ea(Max. 160TB, Non-RAID mode), Hot swap Storage
External	iSCSI storage
RAID	RAID-5/6(Array Size : 8 HDD x 2 Array)
File backup	BU/Exe/AVI(GUI), JPG/AVI(Network) Backup
Function	Multi channel(Up to 16CH) Play, Date-Time/Title display IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
DDNS	Hanwha DDNS
Transmission Bandwidth	Max. 400Mbps
Input/Output	64 CH(network)
Audio	Compression G.711, G.726, AAC(16/48KHz)
Audio Communication	2-Way
Max Remote Users	Search(3), Live Unicast(10), Multicast(20) IP address filtering, User access Log, 802.1x, Encryption Security Device certificate(Hanwha Techwin Root CA), Signed firmware
Supported OS	Windows 10, macOS 10.13 Web viewer
Supported browser	Google Chrome, Microsoft Edge, Mac Safari SSM, Webviewer, Smart Viewer, Wisenet mobile Viewer Software Support CGI(SUNAPI) for integration to 3'rd party VMS Functions
Register	Auto, Manual IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup (4, 8 point polygon)
Camera Setup	Camera video setup (Simple focus, Brightness/Contrast, Item Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage
Control	Via GUI, Webviewer, SPC-2000
Preset	300 Presets
Support Model	iOS, Android
Protocol Support	RTP, RTSP, HTTP, CGI(SUNAPI) Smart phone
Max. Remote Users	Search(3), Live Unicast(10)
Failover	N+1 Redundancy
ARB	Support
Easy configuration	P2P(QR code)
Front	Indicator HDD, Alarm, Power, Record, Backup, Network, RAID
Storage	OK
重設	Power button
HDD Key Lock	OK
HDMI	2EA
Ethernet	RJ-45 3EA (LAN/WAN, 1Gbps)
警報	In 8EA, Out 4EA
USB	4EA(Front 2 x USB 2.0, Rear 2 x USB 3.0)
Power inlet	AC 1EA
Log	Log List Max. 100,000 (System Log, Event Log each)
System Control	Mouse, Keyboard, Web, Controller (SPC-2000) English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Czech, Portuguese, Danish,
語言	Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese Environmental
工作溫度	0°C to +40°C(32℉ to 104℉)
工作濕度	20% ~ 85% RH Electrical
Power Input	100 ~ 240 VAC ±10%; 50/60 Hz
功耗	Max. 285W (972.5 BTU with HDD 16ea)
Color / Material	Black / Metal
Dimension (WxHxD)	440.0 x 132.0 x 571.1mm
重量	Approx. 13.6Kg(30 lb, HDD not included) Intelligent Analysis Person, Face(with Wisenet AI camera), Vehicle, Lisence Object Attribute
AI Search	plate
LPR	English, Number (Wisenet AI, P/X Camera)

* 規格以原廠最新 Datasheet 為準。

下載完整PDF規格書 →

外形尺寸

詳見圖示｜Unit: mm

CCTV 監控安裝工程服務

HKEZIT 專營裝CAM、裝CCTV、裝監控工程，PRN-6400B4 由我們供貨、安裝、調試到使用教學一站式完成。無論裝CAM、裝CCTV或裝監控，均由自家工程團隊上門施工，品質有保證。

裝CAM 裝CCTV 裝監控

CCTV 監控適合邊類專業客戶

PRN-6400B4 hanwha PRN-6400B4亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。

保險經紀行

客戶會面室簽單過程存證，減少銷售爭議，配合保監局合規要求。

WhatsApp 查詢 →

兒科診所

候診區同診症室監控兼顧家長安心同私隱，貴重醫療儀器防盜。

WhatsApp 查詢 →

測量師行／則師樓

現場勘察資料同客戶物業圖則屬機密，辦公室網絡同門禁保安係基本要求。

WhatsApp 查詢 →

婦產科診所

診症室及超聲波室私隱要求極高，出入口記錄配合門禁分級管理。

WhatsApp 查詢 →

建築工程顧問公司

圖則模型檔案室保密，配合工地現場監控延伸管理，項目資料防外洩。

WhatsApp 查詢 →

珠寶鑑定／拍賣行

高值品鑑定過程近攝存證，配合保險公司要求，防止調換或盜取。

WhatsApp 查詢 →

常見問題

PRN-6400B4 香港哪裡有代理？

HKEZIT 提供原廠行貨連保養，PRN-6400B4 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。

此型號如何供電及駁線？

支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。

錄影可以儲存多久、如何遠程監看？

儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過官方 App 可隨時遠程實時監看及回放，無需固定 IP。

PRN-6400B4 定 XRP-4310DB4 邊個好？

兩者主要規格分別：Inputs方面，PRN-6400B4 係 Max. 64CH，XRP-4310DB4 係 Max. 128CH ( If clustering, 132CH)；Playback Bandwidth方面，PRN-6400B4 係 Max. 64Mbps(64CH simultaneously)，XRP-4310DB4 係 Max. 150Mbps；RAID方面，PRN-6400B4 係 RAID-5/6(Array Size : 8 HDD x 2 Array)，XRP-4310DB4 係 1/5/6/10/50。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 XRP-4310DB4 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
