Hanwha PRO-212 為Enterprise Class 2U 12 Bay Rackmount，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 PRO-212 香港價格連安裝報價。
| 操作系統 | Windows Server 2022 IoT |
|---|---|
| Memory | 32GB (2x16GB) DDR5, RDIMM 4800 MT/s |
| Storage | M.2 SSD 2x480GB On RAID 1 (1) Intel Xeon Silver 4410Y Scalable Processors (12Core, 24 Threads, Base Frequency 2.00GHz, Processor Turbo Frequency 3.90Ghz) |
| Networking | (2) 1GbE RJ45 Ports, (2)10/25Gb SFP28 OCP NIC 3.0 |
| PCIe | 1 PCIe slots (1 x16 Gen4) |
| Ports | 1 x USB 2.0, 1 x USB 3.0, 1 x VGA |
| Video Outputs | 1xVGA |
| Remote Management | iDRAC9 Storage |
| Hard Drive Bays | (12) 3.5" Hot Swappable Bays, (2) M.2 SSD Slots |
| Maximum Storage | up to 240TB of RAW Storage (20TB) |
| Hard Drive Supported | PCIe NVMe, SAS & SATA |
| RAID | RAID 0, 1, 5, 6, 10 |
| RAID Controller | PERC H755 Controller with 8Gb NVME Cache Recording Rate Throughput 128Channel - Up to 700Mbps, 256Channel – Up to 1.5Gbps |
| Recording Rate | * The calculation is based upon these parameters: 1080p @ 30fps, 5Mbps/Channel H.264 * Compatible with other Third-party VMS (for more details please contact our sales team) |
| Form Factor | 2U |
| 供電 | 2x800W (100-240VAC) Platinum |
| 工作溫度 | (Min) 50°F - (Max) 95° F, (Min) 10°C - (Max) 35° C |
| 工作濕度 | 10 ~ 80% (non-condensing) |
| Heat Dissipation | 3000 Max BTU/hr |
| Dimensions (WxDxH) | 18.97” (482mm) x 30.44” (772.13mm) x 3.39” (86.8mm) |
| Max. Weight | 65.36 lbs. (29.64Kg) |
| Warranty | 5 Years On-Site, Next Business Day, Keep your Hard Drive Warranty Models |
| PRO-212-108-12 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-108-12 | 32GB RAM, (9)x12TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-108-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-120-12 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-120-12 | 32GB RAM, (10)x12TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-120-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-132-12 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-132-12 | 32GB RAM, (11)x12TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-132-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-144-12 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-144-12 | 32GB RAM, (12)x12TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-144-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-144-16 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-144-16 | 32GB RAM, (9)x16TB SATA HDD (2)1GbE, (2) 10/25Gb SFP PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-212-160-16 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-160-16 | 32GB RAM, (10)x16TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-160-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-176-16 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-176-16 | 32GB RAM, (11)x16TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-176-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-192-16 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-192-16 | 32GB RAM, (12)x16TB SATA HDD (2)1GbE, (2) 10/25Gb SFP PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-192-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-180-20 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-180-20 | 32GB RAM, (9)x20TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-180-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-200-20 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-200-20 | 32GB RAM, (10)x20TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-200-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-220-20 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-220-20 | 32GB RAM, (11)x20TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-220-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| PRO-212-240-20 | 2U 12 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
| PRO-1-212-240-20 | 32GB RAM, (12)x20TB SATA HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
| PRO-2-212-240-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. |
| P | R O - 1 - 2 1 2 - 2 4 0 - 2 0 |
* 規格以原廠最新 Datasheet 為準。
規格書連結更新中，如需完整PDF請WhatsApp查詢
詳見圖示｜Unit: mm
PRO-212 PRO-212-SERIES亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，PRO-212 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 官方 App 可隨時遠程實時監看及回放，無需固定 IP。
兩者屬同系列產品，實際應該邊個型號更適合，需視乎現場環境同需求而定。歡迎直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 PRO-212 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
HKEZIT 於全港各區提供 PRO-212 PRO-212-SERIES供貨連專業安裝服務（裝CAM、裝CCTV、裝監控），熱門地區包括：旺角CCTV 閉路電視安裝、柴灣CCTV 閉路電視安裝、沙田CCTV 閉路電視安裝、油麻地CCTV 閉路電視安裝、深水埗CCTV 閉路電視安裝、灣仔CCTV 閉路電視安裝、筲箕灣CCTV 閉路電視安裝、紅磡CCTV 閉路電視安裝。港島、九龍、新界全港 32 區均有上門安裝，歡迎聯絡我們查詢 PRO-212 香港價格連安裝報價。
PRO-212 PRO-212-SERIES適合多種場景使用，以下為部分常見安裝場景，歡迎查詢是否適合您的現場環境。
骨科診所裝 CCTV 監控候診區同復康治療區同X光儀器，診症室私隱合規佈點不入鏡治療過程，復康儀器房防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →耳鼻喉科診所裝 CCTV 監控候診區同內窺鏡同精密診斷儀器，診症室私隱合規佈點不入鏡治療過程，內窺鏡儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →皮膚科診所裝 CCTV 監控候診區同激光同皮秒儀器，診症室私隱合規佈點不入鏡治療過程，療程儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →眼科診所裝 CCTV 監控候診區同OCT同驗光儀器，診症室私隱合規佈點不入鏡治療過程，眼科儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →婦產科診所裝 CCTV 監控候診區同超聲波檢查儀器，診症室私隱合規佈點不入鏡治療過程，超聲波檢查室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →心臟科診所裝 CCTV 監控候診區同心電圖同心臟監測儀器，診症室私隱合規佈點不入鏡治療過程，心臟儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →查看更多CCTV 監控適用場景，請參閱 CCTV 監控安裝工程。
如需整套CCTV 監控方案，請參閱 CCTV 監控安裝工程。
