| Imaging Device | 1/2.8" 2MP CMOS |
|---|
| 解像度 | 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
|---|
| Max. Framerate | H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
|---|
| 最低照度 | Color: 0.03Lux(F2.0, 1/30sec) BW: 0Lux(IR LED on) |
|---|
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
|---|
| Focal Length (Zoom Ratio) | 2.8mm fixed focal |
|---|
| Max. Aperture Ratio | F2.0 |
|---|
| Angular Field of View | H: 113.7° / V: 61.5° / D: 134.5° |
|---|
| Focus Control | Fixed |
|---|
| Pan / Tilt / Rotate Range | 0°~350° / 0°~67° / 0°~355° |
|---|
| Camera Title | Displayed up to 85 characters |
|---|
| 日夜切換 | Auto(ICR) |
|---|
| Backlight Compensation | BLC, WDR, SSDR |
|---|
| 寬動態 WDR | 120dB |
|---|
| Digital Noise Reduction | SSNR |
|---|
| Motion Detection | 4ea, polygonal zones |
|---|
| Privacy Masking | 6ea, rectangular zones |
|---|
| Gain Control | Low / Middle / High |
|---|
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
|---|
| LDC | Support |
|---|
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
|---|
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) |
|---|
| Analytics | Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
|---|
| Alarm I/O | Input 1ea / Output 1ea |
|---|
| Alarm Triggers | Analytics, Network disconnect, Alarm input |
|---|
| Alarm events | File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output |
|---|
| 音訊輸入 | Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
|---|
| IR Viewable Length | 20m(65.62ft) |
|---|
| Ethernet | RJ-45(10/100BASE-T) |
|---|
| 視頻壓縮 | H.265/H.264: Main/High, MJPEG |
|---|
| 音訊壓縮 | G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps |
|---|
| Smart Codec | WiseStreamⅡ |
|---|
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
|---|
| Streaming | Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
|---|
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
|---|
| 安全 | HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
|---|
| Application Programming Interface | ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
|---|
| Webpage Language | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch |
|---|
| Web Viewer | Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14 Recommended Browser: Google Chrome Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
|---|
| Edge Storage | Micro SD/SDHC/SDXC 1slot 128GB |
|---|
| Memory | 512MB RAM, 256MB Flash |
|---|
| Operating Temperature / Humidity | -30°C ~ +55°C(Normal) / -30°C ~ 60°C(Intermittent) Less than 95% RH(Non-condensing) * Start up should be done at above -20°C |
|---|
| Storage Temperature / Humidity | -30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
|---|
| Certification | IP66, IK10 |
|---|
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC |
|---|
| 功耗 | PoE: Max 7.40W, typical 6.00W 12VDC: Max 6.40W, typical 5.10W |
|---|
| Color / Material | White / Aluminum |
|---|
| RAL Code | RAL9003 |
|---|
| Product Dimensions / Weight | Ø120.3x91.7mm(Ø4.74x3.61"), 510g(1.12 Ib) |
|---|
| Detect (25PPM/ 8PPF) | 25.1m(82.21ft) |
|---|
| Observe (63PPM/ 19PPF) | 10.0m(32.89ft) |
|---|
| Recognize (125PPM/ 38PPF) | 5.0m(16.44ft) |
|---|
| Identify (250PPM/ 76PPF) | 2.5m(8.22ft) QNV-6012R 2M H.265 IR Dome Camera |
|---|
| CAD | Unit: mm [inch] |
|---|
