HANWHA SNB-6004F CCTV攝影機安裝・保養

Name: HANWHA SNB-6004F 2Megapixel Full HD Fiber Optic Network Camera
Brand: hanwha
SKU: SNB-6004F

產品簡介

hanwha SNB-6004F 為2Megapixel Full HD Fiber Optic Network Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SNB-6004F 香港價格連安裝報價。

Imaging Device：1/2.8" 2.38M CMOS
Total Pixels：1,952(H) x 1,116(V)
Effective Pixels：1,944(H) x 1,104(V)
Scanning System：Progressive
最低照度：Color : 0.1Lux (F1.2, 50IRE), 0.03Lux (F1.2, 30IRE) B/W : 0.

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

SNB-6004F hanwha 2Megapixel Full HD Fiber Optic Network Camera 產品圖片

詳細規格

Imaging Device	1/2.8" 2.38M CMOS
Total Pixels	1,952(H) x 1,116(V)
Effective Pixels	1,944(H) x 1,104(V)
Scanning System	Progressive
最低照度	Color : 0.1Lux (F1.2, 50IRE), 0.03Lux (F1.2, 30IRE) B/W : 0.01Lux (F1.2, 50IRE), 0.002Lux (F1.2, 30IRE)
S / N Ratio	50dB
Video Output	CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type
Focus Control	Simple focus / Manual, Remote control via network (Manual, Simple focus, Day & Night)
鏡頭類型	Manual / DC auto iris, P-Iris
Mount Type	C / CS Operational
Camera Title	Off / On (Displayed up to 45 characters)
日夜切換	Auto (ICR) / Color / B/W / External / Schedule
Backlight Compensation	Off / BLC / WDR
寬動態 WDR	120dB
Contrast Enhancement	SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization	Off / On
* Lens not included	Defog Off / Auto / Manual
Motion Detection	Off / On (4 zones with 4-sided polygon)
Privacy Masking	Off / On (32 zones with 4-sided polygon)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed	Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Flip / Mirror	Off / On
Intelligent Video Analytics	Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection with Metadata
Key Features	Alarm I/O Input 1ea / Output 1ea
Remote Control Interface	RS-485
RS-485 Protocol	Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch
• Max. 2M (1920 x 1080) resolution	Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm Triggers
Alarm Events	File upload via FTP and E-mail, Notification via E-mail,
Fiber : Ethernet Physical Layer	100 Base-FX, 1000 Base-X
• Audio / Face / Motion detection	Fiber : Default Speed 1000Mbps
Fiber : Ethernet Standard	IEEE 802.3u, IEEE 802.3z support
解像度	1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
• SFP LC type, 1000Mbps default speed	800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 H.264 : Max. 60fps at all resolutions
Max. Framerate	MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
尺寸	Unit : mm (inch) 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps
Smart Codec	Manual mode (Area-based : 5ea), Face detection mode
Video Quality Adjustment	H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method	H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 10 profiles)
音訊輸入	Selectable (Mic in / Line in), Built-in mic. Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Out	Line out (3.5mm stereo mini jack), Max output level : 1 Vrms
Audio Compression Format	G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication	Bi-directional audio
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
安全	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication 66.6 (2.62") (2.62")
Streaming Method	Unicast / Multicast
Max. User Access	15 users at unicast mode 66.6
Edge Storage	micro SD/SDHC/SDXC - motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage) Application Programming Interface ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, 73.1 (2.88") 73.1 (2.88") 147.8(5.82") 147.8 (5.82") Webpage Language Swedish, Danish, Portuguese, Turkish, Poli
Web Viewer	Mozilla Firefox (Ver. 9 ~ 35), Google Chrome (Ver. 15 ~ 40) Apple Safari (Ver. 8.0.2 (Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only Central Management Software SmartViewer, SSM Environmental
Available Lenses / Accessories (Optional)	Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH Electrical
Input Voltage / Current	24V AC ±10%, 12V DC ±10%
功耗	Max. 12.5W (24V AC, 50 ~ 60Hz), Max. 10.5W (12V DC)
SLA-M2890DN/	SLA-M3180DN/ SHB-4300H/4300H1/4300H2 SHB-4200/4200H Color / Material Black, Ivory / Aluminium, Plastic
M2890PN	M3180PN Dimensions (WxHxD) 73.1 x 66.6 x 147.8mm (2.88" x 2.62" x 5.82")
重量	385g (0.85 lb)
use with	or * Data recorded on an SD memory card may be lost or damaged by data access during power-off, mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur when a memory card reaches end of life, which varies according to operational conditions. No guarantee is given against damage (including passive damage).
STB-400	STH-500 STH-200 STB-4150V * The latest product information / specification can be found at www.samsungsecurity.com 02-11-2015 ⓒ 2015 Hanwha TECHWIN CO., LTD. ALL RIGHTS RESERVED.
