HANWHA SNO-1080R CCTV攝影機安裝・保養

Name: HANWHA SNO-1080R SNO-1080R-SPA-2P-DATASHEET
Brand: Hanwha
SKU: SNO-1080R

產品簡介

Hanwha SNO-1080R 為VGA Weatherproof Network IR Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SNO-1080R 香港價格連安裝報價。

Imaging Device：1/4" PS CMOS
Total Pixels：680(H) x 512(V)
Effective Pixels：640(H) x 480(V)
Scanning System：Progressive Color : 0.7Lux (F1.2, 50IRE) Min. Illumination B
S / N Ratio：50dB

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

SNO-1080R SNO-1080R-SPA-2P-DATASHEET 產品圖片

詳細規格

Imaging Device	1/4" PS CMOS
Total Pixels	680(H) x 512(V)
Effective Pixels	640(H) x 480(V)
Scanning System	Progressive Color : 0.7Lux (F1.2, 50IRE) Min. Illumination B/W : 0Lux (F1.2, 50IRE, IR LED on)
S / N Ratio	50dB
Video Out	SMD connector type, for installation Focal Length (Zoom Ratio) 2.2 ~ 7.7mm (3.5x) varifocal
Max. Aperture Ratio	F1.2
Angular Field of View	H : 94°(Wide) ~ 26.5°(Tele) / V : 70°(Wide) ~ 20°(Tele)
Min. Object Distance	0.5m (1.64ft)
鏡頭類型	DC auto iris
Mount Type	Board type (Ø14) Operational
IR LED	15ea
Viewable Length	15m (49.21ft)
Camera Title	Off / On (Displayed up to 15 characters)
日夜切換	Auto (ICR) / Color / B/W / External Backlight Compensation Off / BLC Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On) Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Motion Detection	Off / On (4 programmable zones)
VGA	3.5x PoE IR LED Privacy Masking Off / On (32ea 4 points polygonal) Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
V/F Lens	D&N ICR Gain Control Off / Low / Medium / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor Electronic Shutter Speed Auto / A.FLK / Manual (60x ~ 1/12,000sec)
Key Features	Flip / Mirror Off / On Intelligent Video Analytics Face detection
• Max. 30fps at VGA resolution	Alarm I/O Input 1ea
• 2.2 ~ 7.7mm (3.5x) varifocal lens	Ethernet RJ-45 (10/100BASE-T) Video Compression Format H.264, MJPEG
• H.264, MJPEG dual codec	Resolution 640 x 480, 320 x 240, 160 x 120
Max. Framerate	Max. 30fps at all resolutions H.264 : Compression level, Target bitrate level control Video Quality Adjustment
• Face detection	MJPEG : Quality level control Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
• IR LED (15ea), PoE, IP66	Streaming Capability Multiple streaming (Up to 10 profiles)
IP	IPv4, IPv6 TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS HTTPS(SSL) login authentication, Digest login authentication Security IP address filtering, User access log, 802.1x Authentication
Streaming Method	Unicast / Multicast
Max. User Access	10 users at unicast mode
ONVIF Conformance	Yes
尺寸	Unit : mm (inch) English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Webpage Language Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek Supported OS : Windows XP / VISTA / 7, MAC OS Web Viewer Supported Browser : Internet Explorer 7.0/8.0, Firefox, Google Chrome, Apple Safari Central Management Software NET-i viewer
防護等級	IP66 grade Electrical Input Voltage / Current 12V DC / 480mA, PoE (IEEE802.3af)
功耗	Max. 5.6W
Color / Material	Dark gray / Aluminum Dimensions (WxHxD) Ø86.8 x 304.6mm (Ø3.42" x 11.99")
重量	1Kg (2.2 lb) * The latest product information / specification can be found at www.samsungsecurity.com Ø86.8 Ø84.8 (3.42") (3.42") 304.6(11.99") 304.6 (11.99")
