| Focal Length (Zoom Ratio) | 10 ~ 23mm (2.3x) motorized varifocal |
|---|
| Max. Aperture Ratio | F1.6 |
|---|
| Angular Field of View | H : 31.3°(Wide) ~ 13.9°(Tele) / V : 17.1°(Wide) ~ 7.8°(Tele) |
|---|
| Min. Object Distance | 0.8m (2.62ft) |
|---|
| Focus Control | Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
|---|
| Lens / Mount Type | P-Iris / Board-in type Pan / Tilt / Rotate |
|---|
| Pan / Tilt / Rotate Range | 0° ~ 354° / 0° ~ 67° / 0° ~ 355° Operational |
|---|
| IR LED | 14ea |
|---|
| Viewable Length | 20m (65.62ft) |
|---|
| Camera Title | Off / On (Displayed up to 45 characters) |
|---|
| 日夜切換 | Auto (ICR) / Color / B/W / External / Schedule |
|---|
| Backlight Compensation | Off / BLC |
|---|
| 寬動態 WDR | 120dB |
|---|
| Contrast Enhancement | SSDR (Samsung Super Dynamic Range) (Off / On) |
|---|
| Digital Noise Reduction | SSNRIII (2D+3D noise filter) (Off / On) |
|---|
| Digital Image Stabilization | Off / On |
|---|
| 除霧 | Off / Auto / Manual |
|---|
| Key Features | Motion Detection Off / On (4ea 4 points polygonal zones) |
|---|
| Privacy Masking | Off / On (32 zones with 4 points of polygonal) |
|---|
| Gain Control | Off / Low / Middle / High |
|---|
| • Max. 2M (1920 x 1080) resolution | White Balance ATW / AWC / Manual / Indoor / Outdoor |
|---|
| Flip / Mirror | Off / On |
|---|
| Alarm I/O | Input 1ea / Output 1ea Video analytics, Network disconnection, Alarm input Local storage (SD/SDHC/SDXC) or NAS recording at Event (Alarm triggers), External output |
|---|
| • Audio / Face / Motion detection | Network |
|---|
| Ethernet | RJ-45 (10/100BASE-T) |
|---|
| • micro SD/SDHC/SDXC memory slot | Video Compression Format H.264 (MPEG-4 part 10/AVC), MJPEG 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, |
|---|
| • Multi-crop streaming, PoE | Resolution 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 H.264 : Max. 60fps at all resolutions 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max.30fps |
|---|
| Smart Codec | Manual mode (Area-based : 5ea), Face detection mode |
|---|
| Video Quality Adjustment | H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
|---|
| Bitrate Control Method | H.264 : CBR or VBR, MJPEG : VBR |
|---|
| 尺寸 | Unit : mm (inch) Streaming Capability Multiple streaming (Up to 10 profiles) |
|---|
| 音訊輸入 | Selectable (Mic in / Line in), Max output level : 1 Vrms Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
|---|
| Audio Out | Line out (3.5mm stereo mini jack) |
|---|
| Audio Compression Format | G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
|---|
| Audio Communication | Bi-directional audio |
|---|
| IP | IPv4, IPv6 118.5 (4.67") (4.67") |
|---|
| Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour 118.5 |
|---|
| 安全 | HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
|---|
| Streaming Method | Unicast / Multicast |
|---|
| Max. User Access | 15 users at unicast mode |
|---|
| Edge Storage | micro SD/SDHC/SDXC Max. 64G, NAS - Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded. Manual recording at local PC |
|---|
| Ø100.0 | (3.94") |
|---|
| Ø100.0 (3.94") | Ø160.0 (6.3") Ø160.0 (6.3") Application Programming Interface ONVIF profile S & G, HTTP API (SUNAPI) English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, |
|---|
| Webpage Language | Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11) |
|---|
| Accessories (Optional) | Web Viewer Mozilla Firefox (Ver. 9 ~ 35), Google Chrome (Ver. 15 ~ 44) Apple Safari (Ver. 8.0.2 (Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only Central Management Software SmartViewer |
|---|
| SBP-300B | SBP-300PM Environmental |
|---|
| Operating Temperature / | -40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH |
|---|
| Humidity | * Start up should be done at above -35°C (-31°F) Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH Ingress Protection / Vandal Resistance IP66 / IK10 Electrical |
|---|
| SHD-3000F1 | SBP-300HM6 SBP-300LM SBP-300CM SBP-300WM1 SBP-300WM SBP-300KM Input Voltage / Current 12V DC ±10%, 24V AC ±10%, PoE (IEEE802.3af) |
|---|
| 功耗 | Max. 11W (Heater off), Max. 12.95W (Heater on) mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur when a memory card reaches end of life, which varies according to operational conditions. |
|---|
| Dimensions (WxH) | Ø160.0 x 118.5mm (Ø6.3" x 4.67") No guarantee is given against damage (including passive damage). Weight 970g (2.14 lb) 28-12-2015 ⓒ 2015 Hanwha TECHWIN CO., LTD. ALL RIGHTS RESERVED. |
|---|
