Hanwha SNV-7084 為3Megapixel Vandal-Resistant Network Dome Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SNV-7084 香港價格連安裝報價。
| Imaging Device | 1/2.8" 3.2M CMOS |
|---|---|
| Total Pixels | 2,065(H) x 1,565(V) |
| Effective Pixels | 2,065(H) x 1,553(V) |
| Scanning System | Progressive |
| 最低照度 | Color : 0.1Lux (F1.2, 50IRE), 0.06Lux (F1.2, 30IRE), 0.0017Lux (2sec, F1.2, 30IRE) B/W : 0.01Lux (F1.2, 50IRE), 0.006Lux (F1.2, 30IRE), 0.00017Lux (2sec, F1.2, 50IRE) |
| S / N Ratio | 50dB |
| Video Output | CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type |
| Focal Length (Zoom Ratio) | Min focal length 3mm (Zoom ratio 2.85x) motorized varifocal |
| Max. Aperture Ratio | F1.2 |
| Angular Field of View | H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele) |
| Min. Object Distance | 0.5m (1.64ft) |
| Focus Control | Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
| Lens Type / Mount Type | DC auto iris, P-Iris / Board-in type Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range | 0° ~ 354° / 0° ~ 67° / 0° ~ 355° Operational |
| Camera Title | Off / On (Displayed up to 45 characters) |
| 日夜切換 | Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation | Off / BLC / WDR |
| 寬動態 WDR | 120dB |
| Contrast Enhancement | SSDR (Samsung Super Dynamic Range) (Off / On) |
| Digital Noise Reduction | SSNRIII (2D+3D noise filter) (Off / On) |
| Digital Image Stabilization | Off / On |
| 除霧 | Off / Auto / Manual |
| Motion Detection | Off / On (4 zones with 4-sided polygon) |
| Privacy Masking | Off / On (32 zones with 4-sided polygon) |
| Gain Control | Off / Low / Middle / High |
| Key Features | White Balance ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec) |
| Flip / Mirror | Off / On |
| • Max. 3M (2048 x 1536) resolution | Intelligent Video Analytics Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection with metadata Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input File upload via FTP and E-mail, Notification via E-mail, |
| • Simple focus (Motorized VF), P-Iris | Alarm Events Local storage (SD/SDHC/SDXC) or NAS recording at Event, External output |
| • Day & Night (ICR), Enhanced DIS, Defog | Ethernet RJ-45 (10/100BASE-T) |
| Video Compression Format | H.264 (MPEG-4 part 10/AVC), MJPEG |
| • 3M real-time WDR (Max. 120dB) | 2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, Resolution 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| • Multi-crop streaming, Heater by PoE | H.264 : Max. 30fps@2048 x 1536, 1600 x 1200, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536 |
| • micro SD/SDHC/SDXC memory slot | Max. Framerate Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Video Quality Adjustment | H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method | H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability | Multiple streaming (Up to 10 profiles) |
| 音訊輸入 | Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| 尺寸 | Unit : mm (inch) Audio Out Line out (3.5mm mono jack), Max output level : 1 Vrms |
| Audio Compression Format | G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Audio Communication | Bi-directional audio |
| IP | IPv4, IPv6 |
| Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| 安全 | HTTPS(SSL) login authentication, Digest login authentication 118.5 (4.67") IP address filtering, User access log, 802.1x authentication (4.67") |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 15 users at unicast mode 118.5 micro SD/SDHC/SDXC |
| Edge Storage | Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded NAS (Network Attached Storage) Application Programming Interface ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, |
| Ø100.0 | (3.94") |
| Ø100.0 (3.94") | Ø160.0 (6.3") Ø160.0 (6.3") |
| Webpage Language | Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11 ~ 8) |
| Web Viewer | Mozilla Firefox (Ver. 19 ~9) * Windows only Google Chrome (Ver. 25 ~ 15) * Windows only Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
| Accessories (Optional) | Central Management Software SmartViewer, SSM Environmental |
| Operating Temperature / | -40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH |
| Humidity | *Start up should be done at above -35°C (-31°F ) Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| SBP-300B | SBP-300PM |
| 防護等級 | IP66 |
| Vandal Resistance | IK10 Electrical |
| Input Voltage / Current | 24V AC, 12V DC, PoE (IEEE802.3af class 3) |
| 功耗 | Max. 9.0W / 11.5W (12V DC, Heater off / on), Max. 10.0W / 12.5W (PoE, Heater off / on) Max. 11.0W / 13.0W (24V AC, Heater off / on) |
| SHD-3000F1 | SBP-300HM6 SBP-300LM SBP-300CM SBP-300WM1 SBP-300WM SBP-300KM |
| Color / Material | Ivory / Aluminum mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur Weight 960g (2.12 lb) when a memory card reaches end of life, which varies according to operational conditions. * The latest product information / specification can be found at www.samsungsecurity.com No guarantee is given against damage (including passive damage). REVISED 01-2016 |
* 規格以原廠最新 Datasheet 為準。
規格書連結更新中，如需完整PDF請WhatsApp查詢
Unit : mm (inch) Audio Out Line out (3.5mm mono jack), Max output level : 1 Vrms｜Unit: mm
SNV-7084 SNV-7084亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，SNV-7084 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 官方 App 可隨時遠程實時監看及回放，無需固定 IP。
兩者屬同系列產品，實際應該邊個型號更適合，需視乎現場環境同需求而定。歡迎直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 SNV-7084 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
