| Input Channel | 1CH BNC 1.0 Vp-p / 75Ω composite NTSC/PAL |
|---|
| Input Signal & Resolution | CVBS, AHD (1, 2&4MP), CVI (1 & 2MP), TVI (1 & 2MP) Auto / Manual Detection |
|---|
| Motion Detection | Off / On (4ea rectangular) |
|---|
| Privacy Masking | Off / On (4ea rectangular zones) |
|---|
| De-Interlacing | Support |
|---|
| Alarm Trigger | Motion Detection, Video Loss, Tampering |
|---|
| Alarm Events | File Upload Via FTP, E-mail |
|---|
| Remote Control Interface | 1ea RS-485 / 422 |
|---|
| RS-485 Protocol | SAMSUNG-T, PELCO-P / D NTSC / PAL : Pelco-C (Coaxitron) AHD : ACP (AHD Coax Protocol) |
|---|
| Ethernet | 1 RJ-45 10/100 Base-T |
|---|
| Video Compression Format | H.264 (MPEG-4 Part 10/AVC) : Main / Baseline / High, MJPEG 4MP, 1920 x 1080, 1280 x 720, 928 x 480(N), 704 x 480(N), 704 x 240(N), 352 x 240(N), 640 x 360, 928 x 576(P), 704 x 576(P), 704 x 288(P), 352 x 288(P) - Main Stream 4MP : 15fps/CH, 1080p/720p/WD1/4CIF/CIF : 30fps/CH(N), 25fps/CH(P) |
|---|
| Max. Framerate | - Sub Stream WD1/4CIF : 12fps/CH, 2CIF/CIF/QVGA/QCIF : 30fps/CH(N), 25fps/CH(P) - MJPEG : 2fps @ 1920x1080, 1280x720, 960H, D1 H.264 : CBR or VBR MJPEG : CBR |
|---|
| Streaming Capability | Dual Streaming (Up to 3 Profiles per channel) |
|---|
| IP | IPv4, IPv6 TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, |
|---|
| Protocol | FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, ONVIF, Bonjour HTTPS (SSL) Login Authentication, Digest Login Authentication IP Address Filtering, User Access Log, 802.1X Authentication (EAP-TLS, EAP-LEAP) |
|---|
| Streaming Method | Unicast / Multicast |
|---|
| Max. User Access | 6 users at Unicast Mode English, French, German, Spanish, Italian, Russian, Turkish, Polish, Dutch, Swedish, Portuguese, Czech , Korean, Chinese, Japanese, Hungarian, Greek Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Supported Browser : Google Chrome 63, MS Edge 41, Mozilla Firefox 57 (Windows 64bit only), Apple Safari 11 (Mac OS X only), Microsoft IE11 ONVIF profile S, SUNAPI |
|---|
| SPE-110N | SPE-110P -10°C ~ +50°C / 20% ~ 80% RH |
|---|
| Input Voltage / Current | DC12V, PoE(IEEE 802.3af ) |
|---|
| 功耗 | Max. 3.6W (DC 12V), Max. 4.0W (PoE) |
|---|
| Color / Material | White (Plastic), Silver (Metal) |
|---|
| Dimension (WxHxD) | 43.0 x 29.2 x 94.15mm (1.693” x 1.150” x 3.706”) |
|---|
| 重量 | 104g (0.229 lb) FIRST EDITION 06-2019 © 2019 Hanwha Techwin Co., Ltd. All rights reserved. |
|---|
