HANWHA SRD-440 CCTV攝影機安裝・保養

Name: HANWHA SRD-440 SRD-440-KOR-2P-DATASHEET
Brand: Hanwha
SKU: SRD-440

產品簡介

Hanwha SRD-440 為4CH CIF H.264 Digital Video Recorder，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SRD-440 香港價格連安裝報價。

Inputs：4 Composite video 0.5-1 Vpp, 75 ohm
解像度：NTSC : 704 x 480 / PAL : 704 x 576
Frame Rate：NTSC : 120fps / PAL : 100fps
Live：Resolution NTSC : 704 x 480 / PAL : 704 x 576
Multi Screen Display：1 / 4 / SEQUENCE / PIP PERFORMANCE

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

Inputs	4 Composite video 0.5-1 Vpp, 75 ohm
解像度	NTSC : 704 x 480 / PAL : 704 x 576
Frame Rate	NTSC : 120fps / PAL : 100fps
Live	Resolution NTSC : 704 x 480 / PAL : 704 x 576
Multi Screen Display	1 / 4 / SEQUENCE / PIP PERFORMANCE
Operating System Embedded	Linux
Compression	H.264 NTSC : Up to 30fps@704 x 480 / PAL : Up to 25fps@704 x 576
Record Rate	NTSC : Up to 60fps@704 x 240 / PAL : Up to 50fps@704 x 288 NTSC : Up to 120fps@352 x 240 / PAL : Up to 100fps@352 x 288 Recording
Mode	Manual, Schedule (Continuous / Event), Event (Pre / Post)
Overwrite Modes	Continuous
H.264	120fps(N) Pre-alarm Up to 5sec (1, 2, 3, 4, 5sec) 4CH 100fps(P) Post-alarm Up to 6 hour (5,10, 20, 30sec,1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
Search Mode	Date/Time, Event, Back up, Motion
Search &	Fast forward / backward (2x, 4x, 8x, 16x, 32x, 64x) Backward play with I-frame only Playback Playback Function Slow forward / backward (1/2x, 1/4x, 1/8x) Step forward / backward (2x, 4x, 8x, 16x, 32x, 64x) Backward play with I-frame only Transmission Speed CIF 120/100fps
Key Features	Bandwidth Up to 4Mbps, Unlimited (4M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
• 4CH CIF real-time DVR	Network Bandwidth Control Automatic
Stream	H.264 (CIF) (IPv4)
Protocol Support	TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP (4CIF recording available) Monitoring Webviewer
Smart Phone	Android, i-Phone (iPad included)
• Smart phone support	Transmission Speed CIF Max. 15fps (Single channel) / CIF Max. 2fps (Quad channel) Max. Remote Users Live 1
Internal HDD	Up to 1 SATA HDD
Storage	USB (Back up) 2 USB ports File Format (Back up) BU (DVR player), EXE (Include player) Password Protection 1 Admin, 10 Group, 10 User per 1 group Security Data Authentication Watermark
VGA	1 VGA (1024 x 768) *Main composite selectable Monitors
Main Composite	1 BNC (1 Vp-p, 75 ohm) / Analog spot (1 BNC, 1 Vp-p, 75 ohm) selectable
Inputs / Output	1CH line in / 1CH line out
Audio	Compression G.711 ULAW (8KHz, 16Bit)
取樣率	8KHz Terminal 4 inputs (NO/NC) / Terminal 1 relay outputs (NO/NC), 215.27 (8.48") 203.5 (8.01") Inputs / Output
警報	Rating : 24V DC / 1A, 125V AC / 0.5A Remote Notification Notification via e-mail
Ethernet	1 RJ-45 10/100 Base-T
尺寸	Unit : mm (inch)
Serial Interface	RS-485 (Half) for PTZ, System keyboard *Support for POS interface (VSI-Pro)
USB	USB 2.0, 2 ports (Front / Rear) Connections Application Support Mouse, Remote controller 255.0 (10.04") Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD, Protocol Support DIAMOND, ERNA, GE, VCL TP, Vicon, ELMO Input Voltage / Current 12V DC adaptor, 4A,100 ~ 250V AC, 50/60Hz, 48watt Electrical Power Consumption Max. 10W (with 1x HDD) 215.27 (8.48") 203.5 (8.01") Environmental Operating Temperature
語言	Polish, Czech, Turkish, Netherlands, Portuguese, Swedish, Danish, Thai, 255.0 (10.04") Rumanian, Serbian, Croatian, Hungarian, Greek (22 Language)
FIRST EDITION 01-2012	121 4.0 (1.73") 0.0 (1.97")
