| 淨重 | 3.1 kg (6.83 lb) |
|---|
| 尺寸 | 440.00 mm × 44.00 mm × 210.00 mm (17.32'' × 1.73'' × 8.27'') |
|---|
| 工作溫度 | -10 °C to 50 °C (14 °F to 122 °F) |
|---|
| 工作濕度 | 10% to 90% (no condensation) |
|---|
| 供電 | 100-240 VAC, 50/60 Hz |
|---|
| 功耗 | 17 W |
|---|
| MAC 位址表 | 8K |
|---|
| Ports | 24 × 1 Gigabit PoE port,4 × 1 Gigabit combo Whole-Device Performance: 336 Gbps Port Performance: 336 Gbps Whole-Device Performance: 51 Mpps Port Performance: 51 Mpps |
|---|
| PoE 標準 | IEEE 802.3af,IEEE 802.3at |
|---|
| PoE 供電腳位 | 1/2 (+), 3/6 (-) |
|---|
| PoE 功率預算 | 370 W Support IEEE 802.1Q (VLAN), 4096 VLAN IDs Support GVRP Support QinQ Support VLAN based on MAC/protocol/IP subnet/policy/port Support Private VLAN Support 1:1 and N:1 VLAN mapping functions Support Diff-Serv QoS Support 802.1p/DSCP priority mapping Support queue scheduling including SP, WRR, WFQ, SP+WRR, SP+WFQ |
|---|
| Support | priority marking and remarking Support traffic shaping Support congestion avoidance, Tail-Drop and WRED Support 802.1p, TOS, DSCP, and EXP priority mapping Support port/flow-based rate limiting Support Console, Telnet, SSH Support web, http, https Support FTP, TFTP, Xmodem, SFTP Support SNMP V1/V2c/V3 Support RMON Support NTP Support 802.1X authentication, MAC authentication, MAC bypass authentica |
|---|
| 安全 | Support binding of IP, MAC, port and VLAN Support MAC authentication Support MAC address filtering Support broadcast/multicast/unknown-unicast storm control Support IGMP v1/v2/v3 Snooping Support IGMP V1/V2/V3 Multicast Support MLD Snooping v1/v2 Support MLD v1/v2 FCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC |
|---|
| EMC | 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 24) |
|---|
| Safety | UL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2034) |
|---|
| Chemistry | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2023) |
|---|
