| 尺寸 | 228.5mm×128.8mm×170.8mm(With antenna size） |
|---|
| Package Dimensions (W × H × D) | 247mm×225mm×55mm |
|---|
| 淨重 | 0.237kg |
|---|
| 毛重 | 0.526kg 1200Mbps Wi-Fi5 Router x 1 Power Supply Adaptor × 1 |
|---|
| 包裝清單 | CAT5e Network Cable × 1 Quick Start Guide × 1 Regulatory Compliance and Safety Information × 1 |
|---|
| 包裝方式 | Single pack |
|---|
| 工作溫度 | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉ ) |
|---|
| 工作濕度 | 10% to 90% RH non-condensing |
|---|
| 儲存溫度 | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉ ) |
|---|
| Storage Humidity | 5% to 95% RH non-condensing |
|---|
| 安裝方式 | Desktop installation ≤ 1200 Mbps 5GHz: 866Mbps 2.4GHz: 300Mbps IEEE 802.11a/n/ac @5GHz |
|---|
| IEEE 802.11b/g/n | @2.4GHz |
|---|
| 工作頻段 | 2.4 GHz，5 GHz Up to1080 ft²/100 m² （Recommend coverage for home use, actual Wi -Fi range varies depending on the layout and wall materials ） |
|---|
| Max. Connections | 128 |
|---|
| Recommended Connections | 40 CE： |
|---|
| 發射功率 | ＜20 dBm(2.4GHz) ＜23 dBm(5GHz) Dual Band Supported MU-MIMO supported Beamforming supported OFDMA supported 5GHz: -88dBm@11AC80-MCS0 -63dBm@11AC80-MCS9 2.4GHz: -90dBm@HT40-MCS0 -71dBm@HT40-MCS7 |
|---|
| 天線增益 | 4 high gain antennas |
|---|
| Antenna | 5dBi 1 × 10/100/1000 Mbps WAN Port 3× 10/100/1000 Mbps LAN Ports Power WAN LAN 2.4 GHz Wi-Fi 5 GHz Wi-Fi WPS |
|---|
| 按鈕 | Reset button, WPS Button |
|---|
| RAM | 128MB DDR2 |
|---|
| ROM | 128MB ( 1G ) NAND |
|---|
| Power Supply Method | Power Supply Adapter |
|---|
| Power Specifications | DC 12 V, 1 A |
|---|
| 最大功耗 | ≤10 W Router Mode |
|---|
| Operating Mode | Wireless Extender Mode Access Point Mode DHCP |
|---|
| WAN Mode | Static IP PPPOE DHCP Client List DHCP Server |
|---|
| Parental Control | Speed Limit,Internet Access Period,Filter URL IPv4 IPv6 |
|---|
| Firewall | Forbid TCP SYNC flood attack,Forbid ICMP flood attack |
|---|
| DDNS | Oray Port Mapping |
|---|
| NAT Forwarding | DMZ UPnP |
|---|
| Others | VLAN/IPTV,Quick Diagnosis,Guest Wi-Fi |
|---|
| 加密模式 | WPA2-PSK,WPA/WPA2-PSK supported Web Control: PC, mobile |
|---|
| 管理方式 | App Control: HPP, HC TR069(TR098/TR181) Support hiding wireless network name Support controlling terminal network connection Support firewalls |
|---|
| 安全機制 | Login Authentication VPN Client Port Mapping DMZ UPNP Web Upgarde |
|---|
| 升級方式 | App Cloud Upgrade Auto Upgrade |
|---|
| 系統日誌 | System log PPTP Client VPN |
|---|
| L2TP | Client |
|---|
