| Sensor Type | 1/3" Progressive Scan CMOS |
|---|
| 最大解像度 | 1280 × 1024 Color: 0.019 Lux @ (F2.0, AGC OFF) B/W: 0.011 Lux @ (F2.0, AGC OFF) |
|---|
| 日夜模式 | Supported Max 3 |
|---|
| Shutter | 1 to 1/100,000 s 2.8 mm 4 mm 2.8 mm：F2.0 4 mm：F2.0 2.8 mm, horizontal FoV: 113°, vertical FoV: 62°, diagonal FoV: 120°, 4 mm, horizontal FoV: 88.6°, vertical FoV: 46.9°, diagonal FoV: 106.8° |
|---|
| 對焦 | Fixed Brightness, contrast, saturation, white balance, and gain can be adjusted via client or IE browser. |
|---|
| Backlight Compensation | Supported. Areas can be selected. |
|---|
| WDR | 140db |
|---|
| 除霧 | supported |
|---|
| 主碼流 | 50 Hz: 25 fps (1280 × 1024, 1280 × 720) |
|---|
| 子碼流 | 50 Hz: 25 fps (1280 × 1024, 1280 × 720, 704 × 576, 640 × 480) Saturation, brightness, contrast, white balance, and gain are adjustable by client,software or web browser. |
|---|
| WDR Switch | On, Time, Brightness |
|---|
| Frame Rate | 25fps |
|---|
| ROI | 8 regions respectively for main stream and sub-stream, 6 levels for each region. |
|---|
| 視頻壓縮 | H.265/H264/MJPEG Low profile |
|---|
| H.264 類型 | Medium profile High Profile |
|---|
| 視頻碼率 | 32 Kbps to 16 Mbps |
|---|
| Bit Rate Type | Constant, Variable |
|---|
| SVC 分級編碼 | MJPEG , H.265 and H.264 encoding |
|---|
| Image Format | JPEG |
|---|
| Capture Resolution | 2560 x 1440 (default)2688 × 1520, 1920 × 1080, 1280 × 720 vehicle entering/exiting parking space status, parking spacestatus detection,Intelligent Detection Direction, etc NAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported |
|---|
| Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNSDDNS,RT,RTSP,RTCP,NTP,SNMP，OTAP |
|---|
| API | ONVIF(PROFILE S,PROFILE G), ISAPI, SDK |
|---|
| 客戶端 | HikCentral,SDKdemo,DS-TPM400 Plug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
|---|
| 安全 | One-key restoration, password protection, watermark |
|---|
| Smart Functions | Built-in AI deep-learning algorithm, supporting ANPR and parking space detection. TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS (SIP, SRTP, and IPv6 optional) |
|---|
| Indicator Interface | 3*LED lamp interface |
|---|
| 網絡接口 | 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface |
|---|
| 供電 | Hikvision PoE, or 12 to 24 VDC wide-range voltage |
|---|
| Working Temperature and | -20 °C to 70 °C (-4 °F to 158 °F) |
|---|
| Humidity | 5% to 95% @ 40°C (non-condensing) |
|---|
| Working Environment | 90% or less (non-condensing) |
|---|
| Storage Temperature and | Temperature: -20 °C to 70 °C (- 4°F to 158 °F) |
|---|
| 功耗 | Max. 6.5 W |
|---|
| 重量 | 0.525 kg (1.2 lb.) |
|---|
| 尺寸 | 170 × 121 × 105 mm (6.7 × 4.8 × 4.2 inch) |
|---|
| Weight (with Package) | 1 kg (2.2 lb.) |
|---|
| Dimensions (with Package) | 275 * 205 * 175 mm(10.8 * 8.1 * 6.9 inch) Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, S |
|---|
