| Screen Dimensions | 21.5 inch |
|---|
| 解像度 | 1080p |
|---|
| Panel Brightness | MAX: 1500 cd/m² |
|---|
| 鏡頭類型 | 3.1 to 6 mm varifocal lens, motor-driven lens |
|---|
| Barrier Housing Material | Cold rolled steel plate |
|---|
| Barrier Housing Thickness | 2 mm 3m octagonal pole Rising Speed: 0.9S(Default) Adjustable 0.9S, 1.2S, 2S Falling Speed: 3S(Default) Adjustable 1.5S, 2S, 3S 4m octagonal pole Rising Speed: 1.5S(Default) Adjustable 1.5S, 2S, 2.5S Falling Speed: 3.5S(Default) Adjustable 2.5S, 3S, 3.5S |
|---|
| Boom Pole Direction | Left/right direction |
|---|
| 補光類型 | IR Light, Warm White Light |
|---|
| LED Light Bead | 9 |
|---|
| Color Temperature | Warm White Light 3000 K |
|---|
| Image Format | JPEG with configurable quality |
|---|
| Smart Recognition | ANPR, vehicle type recognition, vehicle logo recognition, sub-brand recognition Saturation, brightness, contrast, white balance, AGC, and 3D noise reduction can be adjusted via the web browser. |
|---|
| Frame Rate | 25 fps @ (2688 × 1520) TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP picture upload, ONVIF(PROFILE S, PROFILE G, PROFILE T, PROFILE M) |
|---|
| 安全 | Heartbeat, password protection, NTP |
|---|
| Running Noise | ≤ 65 dB (A) |
|---|
| Boom Pole Length | 3m/4m |
|---|
| 最大解像度 | 2688 × 1520 |
|---|
| Sensor Type | 1/3" Progressive Scan CMOS Color: 0.022 Lux @ (F2.0, AGC ON) B/W: 0.011 Lux @ (F2.0, AGC ON) |
|---|
| Shutter | 1/30 s to 1/100,000 s |
|---|
| 日夜模式 | Supported |
|---|
| IR Cut Filter | Supported |
|---|
| 警報輸入 | 3-ch triggered/alarm inputs |
|---|
| 警報輸出 | 2-ch relay outputs, supporting rising/falling of barrier gate boom pole |
|---|
| 網絡接口 | 2 RJ45 10M/100M self-adaptive Ethernet interfaces |
|---|
| Serial Port | 1 built-in RS-485 serial port, 1 built-in RS-232 serial port |
|---|
| Supplement Light Control | Control according to brightness or time Working Temperature and -30 °C to 70 °C (-22 °F to 158 °F); 90% or less (non-condensing) Humidity |
|---|
| 供電 | 220 V, 50 Hz |
|---|
| 功耗 | 350 W, 220 VAC |
|---|
| 重量 | 95 kg (209.4 lb.) |
|---|
| Remote Control Distance | ≤ 30 m |
|---|
| Weight (with Package) | 96.9 kg (213.6 lb.) |
|---|
| Lifespan | 5,000,000 Key Component |
|---|
